Page 1 version 1.0

Quick installation guide

Hitachi Deskstar T7K250

Ultra ATA/133 Hard disk drive

Models:

HDS722525DLAT80

HDS722516DLAT80

System requirements for Ultra ATA/133

If you do not have the components listed below, your

drive will function but at speeds lower than 133 MB/s.

y40-pin, 80-conductor cable

yA controller card or motherboard chipset with Ultra

ATA/133 capability

yUltra ATA/133 compatible BIOS or driver

Handling precautions

ySet the drive down gently to prevent damage from

impact or vibration.

yDo not open the ESD bag containing the drive until

needed.

yHandle the drive carefully by the edges. Do not

touch the exposed printed circuit board or any

electronic components.

yDo not press on the top or bottom of the drive.

yDo not cover the drive breather hole.

yBefore handling the drive, discharge any static

electricity from yourself and your clothing. With one

hand touch an unpainted metal surface on your

computer chassis, then touch the ESD bag with the

other hand. Remain in contact with the chassis and

the bag for a minimum of two seconds.

Quick installation procedure

Note: Back up all data before installing drive!

1. Turn off the computer.

2. Unplug the computer

3. Remove the computer cover as instructed by the

computer system manual.

4. Discharge static electricity (see Handling pre-

cautions).

5. Note the mounting position of existing drives and

cables. If you are replacing a drive or any cable,

remove it now.

6. Remove the drive from the ESD bag.

7. Record the model, the part number, and the serial

number of the drive for future reference.

8. Insert the required jumpers. Refer to the jumper

block diagram below.

•If the drive is the only drive on a cable or the

master drive on a two-drive cable, leave the

jumpers as set at A-B and G-H for 16 head

logical architecture. The jumpers are factory-

set to Master-16 heads.

•If the drive is the slave drive on a two-drive

cable, set the jumpers at A-B and C-D for 16-

head logical architecture.

GEC

HFDB

Hitachi Global Storage Technologies

Page 2 version 1.0

9. Attach the IDE cable.

•If you have a 40-pin 40-conductor cable,

attach the system connector of the cable to

the IDE port on the motherboard or controller

card. The pin 1 side of the IDE cable is

marked with a stripe. The connector can only

be inserted one way.

•If you have a 40-pin 80-conductor cable,

attach the drive to the appropriate color-

coded connector. Forty-pin 80-conductor

cables are color-coded black for Master, gray

for Slave, and blue for system connectors.

10. Attach the power supply cable to the drive. Match

the connector bevels.

11. Mount the drive securely.

12. Verify all attachments.

13. Replace the computer cover.

14. Plug in the computer.

15. Turn on the computer.

16. Verify that the hard disk is recognized by the BIOS

and is reporting the full capacity of the drive.

Instructions for accessing your BIOS can be found

in the computer system manual or in the mother-

board manufacturer documentation. If the drive is

not recognized in the BIOS, set the BIOS options

of your computer system to Auto Detection and

LBA mode if available. Once the drive is

recognized correctly in the BIOS, it is ready to be

partitioned and formatted.

137GB Limitation

With the 160GB and 250GB model, you may encounter

a BIOS limitation of 137GB. Possible solutions for the

137GB limitation include operating system patches, 3rd

party hardware or BIOS upgrade. If you would like

additional information about the 137GB limitation and

possible 3rd party solutions, see the FAQ “What is the

137GB limitation” at: www.hitachigst.com/support

17. Your operating system setup utility will provide

instructions on how to partition and format your

drive before it installs the operating system. For

additional information see:

www.hitachigst.com/support

Hitachi Global Storage Technologies

5600 Cottle Road

San Jose, CA 95193

Produced in the United States

2/05

Global Storage Technologies.

Microsoft, Windows XP, and Windows are trademarks

of Microsoft Corporation in the United States, other

countries, or both.

Other product names are trademarks or registered

trademarks of their respective companies.

References in this publication to Hitachi Global Storage

Technologies products, programs or services do not

imply that Hitachi Global Storage Technologies intends

to make these available in all countries in which Hitachi

Global Storage Technologies operates.

Product information is provided for information

purposes only and does not constitute a warranty.

Information is true as of the date of publication and is

subject to change. Actual results may vary.

This publication is for general guidance only.

Photographs may show design models.

9 February 2005
