Hitachi AMS 2100/2300

Getting Started Guide

Hitachi AMS 2100/2300 Getting Started Guide

No part of this publication may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying and recording, or stored in a database or retrieval system for any

purpose without the express written permission of Hitachi, Ltd. and Hitachi Data Systems Corporation

(hereinafter referred to as “Hitachi”).

Hitachi, Ltd. and Hitachi Data Systems reserve the right to make changes to this document at any time

without notice and assume no responsibility for its use. Hitachi, Ltd. and Hitachi Data Systems products

and services can only be ordered under the terms and conditions of Hitachi Data Systems' applicable

agreements.

All of the features described in this document may not be currently available. Refer to the most recent

product announcement or contact your local Hitachi Data Systems sales office for information on feature

and product availability.

Notice: Hitachi Data Systems products and services can be ordered only under the terms and conditions

of Hitachi Data Systems’ applicable agreements. The use of Hitachi Data Systems products is governed by

the terms of your agreements with Hitachi Data Systems.

Hitachi is a registered trademark of Hitachi, Ltd. in the United States and other countries. Hitachi Data

Systems is a registered trademark and service mark of Hitachi in the United States and other countries.

All other trademarks, service marks, and company names are properties of their respective owners.

Hitachi AMS 2100/2300 Getting Started Guide

Hitachi AMS 2100/2300

Getting Started Guide

Congratulations on purchasing the Hitachi Adaptable

Modular Storage (AMS) 2100 or AMS 2300 storage system.

Before using your storage system, some steps are required to

install and configure it and prepare your host server. The

instructions in this guide are designed to get your storage system

up and running quickly. If you prefer detailed instructions, please

refer to the following:

•AMS 2100/2300 Storage System Hardware Guide (MK-

97DF8010) on the CD supplied with the storage system.

•Storage Navigator Modular User’s Guide (MK-97DF8008) on

the CD supplied with the storage system.

• Storage Navigator Modular 2 storage management software

(hereinafter referred to as Navigator 2). To access the help,

either:

• Install the Navigator 2 software using the instructions in

this guide, then click Help on the current screen being

viewed

• Click Help > Help in the main menu

Hitachi AMS 2100/2300 Getting Started Guide

Installation & configuration checklist

The following checklist identifies the steps for getting your AMS 2100 or

2300 storage system up and running. Please check each step as you

complete it and record your settings on page 49.

Preparing for the installation

1. Unpack items (page 3)

2. User-supplied items (page 4)

3. Identify your configuration (page 7)

Installing the storage system

4. Install the base and expansion units (page 8)

5. Install drives (page 8)

6. Attach the front bezel (page 9)

7. Attach expansion units (optional) (page 10)

8. Connect cables to the base unit (page 13)

9. Connect to a Modular 2U SAS Expansion Unit (optional) (page 16)

10. Power-up the base unit

Configuring the storage system

11. Set Java Runtime parameters if necessary

12. Install and log in to Navigator 2 (page 21)

13. Add storage systems (page 22)

14. Perform the initial setup (page 25)

15. Add the newly configured storage system to Navigator 2

(page 46)

Please read the Release Notes before installing or using this product. They

may contain requirements and restrictions not fully described in this

document, along with updates and corrections to this document.

Hitachi AMS 2100/2300 Getting Started Guide

Preparing for installation

1. Unpack items

1. Inspect all shipping cartons for signs of damage. If you see damage,

contact the shipper.

2. Loosen the band around the cartons and open all cartons.

3. Remove all accessory boxes, packing materials, and envelopes from the

cartons.

4. Have at least three people remove the base unit and any expansion

units.

5. Open and remove the bag in which the base unit is enclosed. Repeat this

step for any expansion units you may have ordered.

6. Compare the items received to the packing list. If any items are missing

or damaged, contact the shipper immediately.

7. Each base unit has a key for locking and unlocking the front bezel. Place

the keys in a safe place.

8. Please keep all packing materials and cartons in case you need to

transport or ship the base or expansion unit.

Hitachi AMS 2100/2300 Getting Started Guide

2. User-supplied items

To complete your installation, you need the following items.

Requirements for all installations

• A personal computer (PC) that will act as a management console (see

Requirements for management on page 5).

• A host server configured as described under Host server requirements

on page 6

• Internet access and a supported browser, with pop-up blockers disabled

(see Requirements for management on page 5)

•Optional: A standard 19-inch rack, mounting hardware, and rack-

mounting documentation if the storage system is to be rack mounted

1 Gbps iSCSI installation requirements

• An IP address, subnet mask, gateway (if applicable), and 5e or

category 6 Ethernet cable for each 1Gbps iSCSI data port that will

connect to your storage network.

• A host server that contains at least one iSCSI host bus adapter (HBA)

or network-interface card (NIC), and a supported iSCSI initiator (see

Host server requirements on page 6)

•Optional: a Gigabit Ethernet LAN switch for switch configurations

10 Gbps iSCSI installation requirements

• An IP address, subnet mask, gateway (if applicable), and a 50/125µm

multimode OM2 or OM3 cable for each 10 Gbps iSCSI data port that will

connect to your storage network

• A host server that contains at least one iSCSI host bus adapter (HBA)

or network-interface card (NIC), and a supported iSCSI initiator (see

Host server requirements on page 6)

•Optional: a 10 Gbps Ethernet LAN switch for switch configurations

Fibre Channel installation requirements

• A multimode fiber-optic cable for each Fibre Channel port that will

connect to your storage network (see Table 1-1 on page 1-5)

• A host server that contains at least one Fibre Channel host bus adapter

(HBA) (see Host server requirements on page 6)

•Optional: a Fibre Channel switch for switch configurations

Hitachi AMS 2100/2300 Getting Started Guide

Requirements for management

• An IP address for each storage system management port

• A PC that will act as a management console and meets the following

requirements:

Processor: 1 GHz (2.4 GHz recommended)

Random Access Memory: 1 GB (2 GB recommended)

Disk space: 1.5 GB or more

Video resolution: 800 x 600 dots per inch (1024 x 768 or higher

recommended), 256 colors or more

A network-interface card (NIC)

An Ethernet LAN cable to attach the management console to the

storage system’s management ports. The management ports

support Auto-MDI/MDIX technology, allowing you to use either

standard (straight-through) or crossover Ethernet cables.

• One of the following operating systems:

Microsoft Windows XP (Service Packs 2 and 3)

Microsoft Windows 2003 (Service Packs 1 and 2) – x86 only

Microsoft Windows 2003 R2 (no Service Pack, Service Packs 1 and 2)

– x86 and x64

Microsoft Windows Vista (Service Pack 1) ß – 86 only

Microsoft Windows Server 2008 (Service Pack 2) – x64 and x86

Microsoft Windows 7, x64 and x86 (no Service Pack)

Microsoft Windows Server 2008 R2 (no Service Pack)

Red Hat Enterprise Linux 4 (Update 1) – x86 only

Red Hat Enterprise Linux 4 (Update 5) –x86 only

Red Hat Enterprise Linux 5 (Update 3) – x86 only

Table 1-1: Supported Fiber-Optic Cables and Distances

Cable Length

Distance

LPe1150

(@ 4Gb/s) LPe1250

(@ 8Gb/s)

Max 50/125multimode fibre cable

(2000MHz*km bandwidth)

OM3 (limiting optical receiver, 800-M5E-SN-I)

1246.71 feet

(380 m) 492.12 feet

(150 m)

50/125µm (500MHz*km bandwidth)

OM2 (limiting optical receiver, 800-M5-SN-S) 492.12 feet

(150 m) 164.04 feet

(50 m)

62.5/125µm (200MHz*km bandwidth)

OM1 (limiting optical receiver, 800-M6-SN-S) 229.65 feet

(70 m) 68.89 feet

(21 m)

TIP:For an optimum experience with Navigator 2, we recommend that your

management console be a new or dedicated PC.

Hitachi AMS 2100/2300 Getting Started Guide

Red Hat Enterprise Linux 5 (Update 4) – x86 and x64

Solaris v8, v9, and v10 – SPARC only, Solaris 10 x64 (AMD64)

• One of the following Web browsers, with pop-up blockers disabled and

Java Runtime Environment (JRE) v6.0 installed (JRE v6.0 can be

downloaded from http://java.com/en/download/ and installed by

following the on-screen prompts):

Internet Explorer 6 for Microsoft Windows 2000, XP, and 2003

Internet Explorer 7 for Microsoft Windows XP, 2003, 2008, Vista

Mozilla 1.7 for Red Hat Enterprise Linux 4 Update 1, Update 5, 5.0

Update 3 and 4

Mozilla 1.7 for Solaris v8, v9, and v10

Firefox2 for Solaris 10

Host server requirements

A host server equipped as follows:

• A supported Fibre Channel HBA for Fibre Channel installations, or an

iSCSI HBA, NIC, and iSCSI initiator for iSCSI installations

• One of the following host operating systems:

Apple Macintosh OS10 (Fibre Channel only)

Asianux

HP-UX

IBM AIX v5.1, v5.2, v5.3, v6.1, and v7.1

Microsoft Windows 2000 (Service Packs 3 and 4)

Microsoft Windows 2003 and 2003 Server (Service Pack 1)

Microsoft Windows 2008 (Service Pack 2)

Microsoft Windows XP (Service Pack 2)

NetWare v6.5 Service Packs 6 and 7 (Fibre Channel only)

Red Hat Enterprise Linux 4 (Update 1)

Red Hat Enterprise Linux 4 (Update 5)

Red Hat Enterprise Linux 5 (Update 3)

Red Hat Enterprise Linux 5 (Update 4)

Sun™ Solaris™ v8, v9, and v10

SuSE Linux

NOTE: The Navigator 2 command-line interface also supports the following

operating systems: HP-UX 11.0, 11i,11i v2.0, and 11i v3.0; IBM AIX 5.1,

5.2, and 6.1; and IRIX 5.

NOTE: For Windows 2008, server R2 and Windows 7, use Internet Explorer

Hitachi AMS 2100/2300 Getting Started Guide

3. Identify your configuration

The base unit can be used in a direct-connect point-to-point or switch

configuration.

Figure 1-1: Example of a Direct-Connect Configuration

Figure 1-2: Example of a Switch Configuration

Installing the storage systems

The following sections describe how to install your storage system. AMS

2100 and 2300 storage systems are delivered in a pretested configuration,

with the trays positioned in a certain location. When the site team installs

the storage system, the team should arrange the trays as they were tested

(a piece of paper supplied with the storage systems shows the tested tray

locations). If the trays are not installed in the proper location, they generate

HDD identification error messages I6G100 at power up. However, if the site

team performs an installation from scratch using maintenance mode (soft

reset) from the Web, it does not matter how the trays are arranged.

Modular deployments require configuration attention to ensure that the

storage infrastructure and ecosystem components interoperate correctly

with Hitachi AMS storage systems and software. There are many component

variations, and the Hitachi compatibility and interoperability matrix can be

used as a reference when constructing configurations that are supported

end to end by Hitachi AMS storage systems. To view the matrix, please

visit: http://www.hds.com/products/interoperability/?_p=v.

Servers Hitachi AMS 2100 and

2300 Family Base Unit Management

Console

Servers Switch

Hitachi AMS 2100 and

2300 Family Base Unit

Management

Console

Switch

Servers

Hitachi AMS 2100/2300 Getting Started Guide

4. Install the base and expansion units

1. Select an appropriate location. Refer to the AMS 2100/2300 Storage

System Hardware Guide (MK-97DF8010).

2. Base and expansion units ordered with the Hitachi Global 19-inch rack

are delivered preinstalled in the rack. If you use a different rack, refer

to and follow all safety precautions in the documentation for the rack.

5. Install drives

Drives are preinstalled. To install additional drives:

1. Wear an anti-static wrist strap connected to the chassis of the base or

expansion unit.

2. Place a finger under the blue lever at the top of the drive tray. Then

gently pull the lever forward.

3. Holding the lever, gently pull the drive tray toward you until the tray is

about half way out of the slot.

4. Hold the top and bottom of the drive tray and remove it from the unit.

5. If the slot where the drive is to be installed has a filler, remove the filler.

6. Orient the new drive so the gold edge connectors on the rear of the drive

are at the rear of the drive tray and the label on the drive faces the right.

7. Insert the drive into the rear of the drive tray and slide the drive forward

until the 3 rectangular hooks on the drive (2 on top and 1 on the bottom)

enter the rectangular holes on the top and bottom of the drive tray.

8. Place the drive on the slot’s guide rail, then gently slide the drive into

the slot (shown by the arrow in Figure 1-3 on page 9). Stop pushing

when the blue lever at the top of the drive tray starts to rise.

9. Secure the drive tray in the unit by pushing the blue lever to the top until

the lever snaps into place.

10.To install additional drives, repeat steps 3 through 9.

CAUTION! Observe all safety guidelines in the following documents:

•AMS 2100/2300 Site Preparation Guide (MK-98DF8149)

•AMS 2100/2300 Storage System Hardware Guide (MK-97DF8010)

• The documentation for your rack

To avoid damage to the storage system or storage system components due

to electrostatic discharge (ESD), wear an anti-static wrist strap when

handling the storage system. Connect the clip to an unpainted part of the

storage system chassis frame to safely channel any static electricity

generated by your body to ground. If no wrist strap is available, ground

yourself by touching an unpainted part of the storage system chassis frame.

NOTE: Drive slots that do not have a drive must have a filler. If a slot does

not have a filler installed, insert a filler into the slot. Insert the filler slowly,

so the latch (round dent) on the filler moves to the right.

Autres manuels pour AMS 2100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hitachi Stockage

Hitachi

Hitachi Travelstar 7K100 Manuel utilisateur

Hitachi

Hitachi VSP G1000 Manuel utilisateur

Hitachi

Hitachi Travelstar HTS542516K9SA00 Manuel utilisateur

Hitachi

Hitachi Travelstar 40GN Manuel utilisateur

Hitachi

Hitachi E990 Manuel utilisateur

Hitachi

Hitachi Virtual Storage Platform E Series Manuel utilisateur

Hitachi

Hitachi TAGMASTORE MK-90RD011-25 Manuel utilisateur

Hitachi

Hitachi Virtual Storage Platform G200 Manuel utilisateur

Hitachi

Hitachi DK23DA-30F - 30 GB Hard Drive Manuel utilisateur

Hitachi

Hitachi Endurastar J4K30 Manuel utilisateur

Hitachi

Hitachi Hyper Scale-Out Instructions de montage

Hitachi

Hitachi ic35l060avv207-0 - Deskstar 60 GB Hard Drive Manuel utilisateur

Hitachi

Hitachi Travelstar 2.5 inch SATA HTS722020K9A300 Manuel utilisateur

Hitachi

Hitachi Deskstar 7K4000 Manuel utilisateur

Hitachi

Hitachi 3.5-inch Deskstar HDS722020ALA330 Manuel utilisateur

Hitachi

Hitachi Deskstar 7K1000 Manuel utilisateur

Hitachi

Hitachi Travelstar 2.5-inch HIGH-PERFORMANCE... Manuel utilisateur

Hitachi

Hitachi HUS151473VL3800 - Ultrastar 73.4 GB Hard... Manuel utilisateur

Hitachi

Hitachi Deskstar 7K1000.B Manuel utilisateur

Hitachi

Hitachi HTS541010G9AT00 - Travelstar 100 GB Hard... Manuel utilisateur

Hitachi

Hitachi Travelstar 7K60 Manuel utilisateur

Hitachi

Hitachi Deskstar P7K500 Manuel utilisateur

Hitachi

Hitachi VSP G1000 Manuel utilisateur

Hitachi

Hitachi Travelstar C4K40 Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
