Hitachi MP-WU8101W Manuel utilisateur

1QM00974-1

LCD Projector

MP-WU8101W/MP-WU8101B

User's Manual (detailed)

Instant Stack Guide

T h a n k yo u f o r p u r ch a si n g t h i s p r o j e ct o r .

WARNING ►Before using this projector, be sure to read all manuals for this

projector. After reading them, store them in a safe place for future reference.

►Follow all the instructions in the manuals or on the projector. The manufacturer

assumes no responsibility for any damage caused by mishandling that is beyond

normal usage dened in the manuals.

NOTE • The information in this manual is subject to change without notice.

•The illustrations in this manual are for illustrative purposes. They may di󰀨er

slightly from your projector.

• The manufacturer assumes no responsibility for any errors that may appear in

this manual.

• The reproduction, transfer or copy of all or any part of this document is not

permitted without express written consent.

Trademark acknowledgment

All the trademarks in this manual are the properties of their respective owners.

Various symbols are used in this manual. The meanings of these symbols are

described below.

About this manual

WARNING

CAUTION

NOTICE

This entry warns of a risk of serious personal injury or even

death.

This entry warns of a risk of personal injury or physical damage.

This entry notices of fear of causing trouble.

Refer to the pages written following this symbol.



Features

This projector can be used with another projector of the same model to project an

image on the same screen using the Instant Stack feature.

The two projectors can be operated simultaneously to make the image brighter.

Moreover, if you connect two projectors with RS-232C cross-over cable, it turns

to an intellectual stacking system. The two projectors can work alternately by

themselves, and once one projector has an accident the other voluntarily starts to

work to keep your presentation going.

These features, generically called Instant Stack, provide you with the broad use.

2QM00974-1

  

1. Introduction ........................3

1.1 Basic information

and preparations .............................3

Instant Stack ........................................3

Intellectual Stack and Simple Stack.....3

Remote control for Intellectual Stack

and Simple Stack .............................3

2. Installation ..........................5

2.1 Preparing for Intellectual Stack.....5

2.2 Installing

the rst projector (Set A) ................6

Deciding installation position ...............6

Setting up Set A...................................6

2.3 Installing

the second projector (Set B) ..........8

Deciding installation position ...............8

Connecting projectors..........................8

Setting up Set B...................................8

2.4 Conrming Main

and Sub settings............................10

2.5 Fine adjusting

image position ............................... 11

For Intellectual Stack users ............... 11

For Simple Stack users......................12

3. STACK menu settings......13

3.1 Displaying STACK menu ............13

3.2 Selecting Main, Sub or o󰀨 ..........14

3.3 Selecting the light source

operation mode ............................15

3.4 Selecting the light source

switching mode..............................17

3.5 Selecting input source for Sub. . . . 18

3.6 Exiting Intellectual Stack menu...20

STACK menu .....................................20

Dialog from STACK menu..................20

3.7 Important information

for Intellectual Stack ......................21

4. Connecting cables ...........24

4.1 Connecting an RS-232C cable. . . 24

4.2 Connecting signal cables............25

Inputting an image from Main to Sub

. . 25

Inputting an image to Sub

and Main individually ......................26

5. Setting input ports

using menu.........................27

5.1 Preparing for menu operations. . . 27

5.2 Checking the Main projector's

o p e ra tin g st a tu s .............................27

5.3 Starting up the Main projector ....28

5.4 Setting the menu ........................29

Inputting an image from Main to Sub

- Computer signal ...........................29

Inputting an image from Main to Sub

- Video signal

(either component or video) ...........30

Inputting an image to

Sub and Main individually...............30

6. Restrictions

on Schedule function ........32

7. Troubleshooting ...............34

Contents

3QM00974-1

(continued on next page)

1. Introduction

1.1 Basic information and preparations

Instant Stack

Instant Stack is a feature that allows you to superimpose images projected from

two projectors easily.

Intellectual Stack and Simple Stack

Instant Stack includes the following two features.

When two projectors are connected using an RS-232C cable with necessary

settings performed on the projectors, these two projectors automatically operate

in synchronization with each other according to the settings.

This is known as

Intellectual Stack in this manual.

The two projectors operate individually without the RS-232C connection. This is

known as Simple Stack in this manual.

Remote control for Intellectual Stack and Simple Stack

For Intellectual Stack, one projector is set as Main and the other is set as Sub.

Only the Ma i n projector is capable of receiving the remote control signals.

O p e r a t e

the projectors from the control panel of the Main projector or with the remote control

pointing at the Main projector. For details on operating by remote control and from the

control panel, refer to 3.7 Important Information for Intellectual Stack.

For Simple Stack, both projectors can receive the remote control signals. To avoid

incorrect operations with the remote control, it is recommended to operate with

the control panel or a wired remote control. KEYLOCK or REMOTE ID function is

also available. (Operating Guide → OPTION menu)

If you require more information on Instant Stack, consult your dealer.

CAUTION ► Place the projector in a cool place with su󰀩cient ventilation.

Keep a space of 50 cm or more between a side of the projector and other

objects such as a wall. Keep a space of 50 cm or more between the two

projectors, especially if you are installing the projectors side by side. Take care

not to let the hot exhaust air from other projectors enter the intake vents of the

p r o j e ct o r .

WARNING ► Do not place projectors directly on top of other projectors.

Introduction

4QM00974-1

1.1 Basic information and preparations (continued)

NOTICE ► Intellectual Stack can be operated only in pairs of the same model

p r o j e ct o r s.

► A maximum of two projectors can be used as Intellectual Stack.

► Use the same type of lens for both projectors.

► Depending on the installation and surrounding environment, images

projected from the two projectors may not superimpose well enough. The

images cannot superimpose well enough especially when the screen is slanted,

deformed or the surface is uneven.

• Images projected immediately after turning on the projectors are unstable due

to rising internal temperature. Wait for more than 20 minutes before starting to

adjust the superimposed images.

• The image positions may shift due to temperature change, vibration, or shock

caused by hitting the projector. Install the projectors in a stable environment

when using Instant Stack. If the image positions are shifted, readjust the

images. (

6, 8, 11

)

• The image positions may shift over time due to the tension and the weight of

the connecting cables. Make sure not to impose any load on the projectors

when arranging the cables.

• When two projectors are connected using the RS-232C cable, the Main

projector can control the Sub projector. This feature is known as Intellectual

Stack. (

) When Intellectual Stack by means of RS-232C feature is used,

RS-232C communication cannot be used to control the projector. If you want

to control the projectors from a computer, use the LAN connection that is

connected to any of the projectors.

• When Intellectual Stack is used, the operations or settings of some functions

are restricted. Refer to this manual for details. (

)

5QM00974-1

Projector

For safety reasons, read 1.1 Basic information and preparations (

3, 4

) carefully

before installation. In addition, take note of the following for proper use of Instant

Stack.

● Use the same model projectors.

● Arrange the projectors side by side.

●Ma ke su r e t h e p r o j e ct i o n scr e e n i s

perpendicular to the projectors.

● Project images larger than the recommended

screen size shown in the table. The greater

the distance between the projectors, the

larger the screen size needs to be.

● To avoid incorrect operations with the remote control, it is recommended to

operate with the control panel or a wired remote control if you control one

projector with the remote control during installation. KEYLOCK or REMOTE ID

function is also available. (Operating Guide → OPTION menu)

● Images from Set A and Set B may superimpose well but the image positions

can shift over time. Readjust to superimpose the images.

2.1 Preparing for Intellectual Stack

When using Intellectual Stack via RS-232C connection, ensure the following settings are

set on the two projectors. Otherwise, the Intellectual Stack menu cannot be operated.

● STANDBY MODE i n SETUP menu: NORMAL

(Operating Guide → SETUP menu)

● COMMUNICATION TYPE under COMMUNICATION i n SERVICE menu: OFF

(Operating Guide → OPTION menu)

● STACK LOCK i n SECURITY menu: OFF

When STACK LOCK is set to on, menus related to Instant Stack cannot be operated.

You must to set it to off during installation and menu setting.

(1) Use the ▲/▼/◄/► buttons to go into the following menu.

ADVANCED MENU >SECURITY (> ENTER PASSWORD) >STACK LOCK

STACK LOCK dialog appears on screen.

(Operating Guide → SECURITY menu)

(2) Use the ▲/▼ buttons to highlight OFF, and press the ►

button to complete the setting.

2. Installation

L (50 cm or more)

Screen

si ze

0 ± 10 cm

L: distance [cm] Recommended screen size [inch]

5 0 250

100 380

Installation

6QM00974-1

NOTE • Set the tilt angle of Set A to within 3 degrees from the level line.

(continued on next page)

Deciding installation position

Decide on the position of Set A and its projection angle. (User’s Manual (concise)

→Arrangement and Adjusting the projector’s elevator)

2.2 Installing the rst projector (Set A)

Setting up Set A

2. R u n t h e INSTALLATION setting if necessary as it may change the

image position. (Operating Guide →SETUP menu )

3. Adjust the image of Set A to t the screen with the Z O O M, FOCUS and LENS

SHIFT f e a t u r e s. (Operating Guide →Adjusting the lens)

Adjust the image position using KEYSTONE, PERFECT FIT or WARPING i f

necessary. (Operating Guide →EASY MENU o r SETUP menu)

NOTE • KEYSTONE, PERFECT FIT, and WARPING functions cannot be

used at the same time. Use an appropriate function.

• If using Simple Stack, go to 2.3 Installing the second projector (Set B). (

)

1. Turn on Set A.

WARNING ►

You can install the projector for any direction with specied

mounting accessories. Consult with your dealer about such a special installation.

Installation

7QM00974-1

4. Display the menu with the MENU button. (Operating Guide →Using the

menu function)

5. Use the ▲/▼/◄/► buttons to go into the following menu.

ADVANCED MENU > OPTION

> SERVICE > COMMUNICATION

> STACK

STACK menu appears on screen.

(Operating Guide →OPTION menu)

NOTE • To avoid incorrect operations with the remote control, it is

recommended to operate with the control panel or a wired remote control.

KEYLOCK or REMOTE ID function is also available.

7. After pressing the ► button, a dialog to

conrm whether or not to save the setting is

displayed.

Press the ► button to complete the setting. (

)

6. Use the ▲/▼ buttons to highlight STACK

MODE, and press the ► button to display

t h e STACK MODE dialog.

Highlight SUB pressing the ▲/▼ buttons,

and press the ► button.

2.2 Installing the rst projector (Set A) - Setting up Set A (continued)

Installation

8QM00974-1

2.3 Installing the second projector (Set B)

Connecting projectors

To use Intellectual Stack, connect an RS-232C cross cable between the CONTROL

port of Set A and Set B.

(continued on next page)

NOTE • KEYSTONE, PERFECT FIT, and WARPING functions cannot be

used at the same time. Use an appropriate function.

• R u n t h e INSTALLATION setting rst if necessary as it may change the image

p o si t i o n . (Operating Guide →SETUP menu)

Reset the adjustment of KEYSTONE, PERFECT FIT and WARPING on Set B.

(Operating Guide →EASY MENU o r SETUP menu)

1. T u r n o n Set B.

NOTE • A f t e r t u r n i n g o n Set B, make sure the image of Set Bi s n o t

signicantly tilted compared to the image of Set A. If the image is overly tilted,

rotate the elevator feet of Set B to adjust the angle such that the tilt is just

about right.

Setting up Set B

NOTE • Set the tilt angle of Set B to within 3 degrees from the level line.

Deciding installation position

Decide on the position of Set B and its projection angle. (User’s Manual (concise)

→Arrangement and Adjusting the projector’s elevator)

WARNING ►You can install the projector for any direction with specied

mounting accessories. Consult with your dealer about this installation.

Installation

9QM00974-1

8. After pressing the ► button, a dialog to

conrm whether or not to save the setting is

displayed.

Press the ► button to complete the setting.

(

)

6. Use the ▲/▼ buttons to highlight STACK

MODE, and press the ► button to display the

STACK MODE dialog.

Highlight MAIN with the ▲/▼ buttons, and

press the ◄ button to return to the previous menu.

7. Use the ▲/▼ buttons to highlight LIGHT

MODE, and press the ► button to display

t h e LIGHT MODE dialog.

Highlight DUAL with the ▲/▼ buttons, and

press the ► button.

2.3 Installing the second projector (Set B) - Setting up Set B (continued)

4. Display the menu with the MENU button. (Operating Guide →Using the

menu function)

5. Use the ▲/▼/◄/► buttons to go into the following menu.

ADVANCED MENU > OPTION

> SERVICE > COMMUNICATION

> STACK

STACK menu appears on screen.

(Operating Guide →OPTION menu)

3. Adjust the image size and position of Set B with the Z O O M, FOCUS and

LENS SHIFT features such that the image can be superimposed to the image

of Set A. (Operating Guide →Adjusting the lens)

NOTE • Fine adjustment of the image size and position afterwards with

f u n ct i o n s su ch a s KEYSTONE, PERFECT FIT and WARPING does not

increase the image size. You must have the image of Set B completely

overlapping the image of Set A.

• When controlling Set B with the remote control, Set A may also respond to

the remote control. To avoid incorrect operations with the remote control, it

is recommended to operate with the control panel or a wired remote control.

KEYLOCK or REMOTE ID function is also available.

• If using Simple Stack, go to For Simple Stack users. (

)

Installation

10 QM00974-1

2.4 Conrming Main and Sub settings

NOTE •

W h e n Intellectual Stack is in use, only Main is capable of receiving

the remote control signals. Sub does not respond to the remote control signals.

2. The following dialogs appear on the lower right screen.

Main (Set B)Sub (Set A)

3. If you press the ► button, the dialog closes and the Main (Set B) menu

appears when MAIN is highlighted.

If you press the ◄ button, the dialog closes and the menu disappears.

NOTE • If these dialogs are not displayed on screen, check the RS-232C

connection (

) and the MAIN or SUB setting in the STACK MODE dialog.

(

)

1. Press the MENU button on the remote control for Main (Set B) .

Autres manuels pour MP-WU8101W

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hitachi Projecteur

Hitachi

Hitachi IPJ-AW250N Manuel utilisateur

Hitachi

Hitachi CP-WX3015WN Manuel utilisateur

Hitachi

Hitachi X807 - CP XGA LCD Projector Mode d’emploi

Hitachi

Hitachi MC-WU5506M Manuel utilisateur

Hitachi

Hitachi CP-X3010Z series Manuel utilisateur

Hitachi

Hitachi ED-A220N Manuel utilisateur

Hitachi

Hitachi CP-WU8450 Manuel utilisateur

Hitachi

Hitachi CP-X880 Manuel utilisateur

Hitachi

Hitachi CP-X2511 Series Manuel utilisateur

Hitachi

Hitachi CP-A222WN Manuel utilisateur

Hitachi

Hitachi C-WX30LWN Manuel utilisateur

Hitachi

Hitachi CP-X251 series Manuel utilisateur

Hitachi

Hitachi ED-X3400 series Manuel utilisateur

Hitachi

Hitachi CP-X990W Manuel utilisateur

Hitachi

Hitachi IPJ-AW250N Document technique

Hitachi

Hitachi X807 - CP XGA LCD Projector Manuel utilisateur

Hitachi

Hitachi CP-WX410 Guide de démarrage rapide

Hitachi

Hitachi CP-X970W Manuel utilisateur

Hitachi

Hitachi CP-A301N Manuel utilisateur

Hitachi

Hitachi CP-D10 Series Manuel utilisateur

Hitachi

Hitachi MP-J1 Manuel utilisateur

Hitachi

Hitachi X308 - CP XGA LCD Projector Manuel utilisateur

Hitachi

Hitachi CP-DX250 guide Guide d'installation

Hitachi

Hitachi CP-A222WN Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
