Projector

CP-X9110/CP-WX9210/CP-WU9410

User's Manual (detailed)

Operating Guide

Thank you for purchasing this projector.

►Before using this product, please read all manuals for this

product. Be sure to read Safety Guide rst. After reading them, store them in a

safe place for future reference.

WARNING

NOTE

Trademark acknowledgment

Various symbols are used in this manual. The meanings of these symbols are

described below.

About this manual

WARNING

CAUTION

This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

This symbol indicates information that, if ignored, could possibly

result in personal injury or physical damage due to incorrect handling.

Please refer to the pages written following this symbol.



NOTICE This entry notices of fear of causing trouble.

• The information in this manual is subject to change without notice.

• The illustrations in this manual are for illustrative purposes. They may differ

slightly from your projector.

• The manufacturer assumes no responsibility for any errors that may appear in

this manual.

• The reproduction, transfer or copy of all or any part of this document is not

permitted without express written consent.

Contents

Introduction ...............3

Features ......................3

Checking the contents of package

....3

Part names ....................4

Projector, Control panel and Indicators,

Ports, Remote control

Setting up .................7

Installing the lens unit ............7

Arrangement ...................7

Connecting with your devices .....10

Fastening the cables

Fastening the adapter cover ......15

Using the security bar and slot ....16

Connecting to a power supply .....17

Remote control ............18

Installing the batteries ...........18

Using the REMOTE ID function ...18

Changing the frequency of remote control signal

. . 19

About the remote control signal ...19

Status Monitor ............20

Switching the display

..............21

The current status

(Warnings and Errors)

..............23

Error log

. . . . . . . . . . . . . . . . . . . . . . . 23

Lamp log

......................24

Filter log

. . . . . . . . . . . . . . . . . . . . . . . 25

Network Information ............25

Power on/off ..............26

Operating ................27

Selecting an input signal .........27

Selecting an aspect ratio .........28

Adjusting the projector's elevator

....29

Adjusting the lens ..............30

Adjusting the zoom and focus,

Adjusting the lens position, Lens memory,

Lens lock

Using the automatic adjustment feature

. . 32



Other buttons ..................33

Geometry correction ............34

Correcting the distortion,

Using the EDGE BLENDING feature, Using

the WARPING feature, Using the Camera

Feedback (BLENDING) feature,

Using the magnify feature ........42

Temporarily freezing the screen ...43

Temporarily shading the screen ...43

PbyP (Picture by Picture) /

PinP (Picture in Picture) ...44

Using the menu function .........48

Indication in OSD,

Containing items of each menu

EASY MENU. . . . . . . . . . . . . . . 51

PICTURE menu ............53

IMAGE menu ..............58

INPUT menu ..............61

SETUP menu ..............66

SCREEN menu.............74

OPTION menu .............81

NETWORK menu ...........92

SECURITY menu ...........93

Maintenance ..............99

Replacing the lamp .............99

Cleaning and replacing the air lter . 102

Replacing the

internal clock battery ...........104

Other care ...................105

Regarding the

indicator lamps ...........106

Resetting all settings ......112

Specications ............113



Introduction

• Keep the original packing materials, for future reshipment. Be sure

to use the original packing materials when moving the projector. Use special

caution for the lens.

• The projector may make a rattling sound when tilted, moved or shaken, since

a ap to control the air ow inside of the projector has moved. Be aware that

this is not a failure or malfunction.

NOTE

Introduction

The projector provides you with the broad use by the following features.

Checking the contents of package

Please see the Contents of package section in the User’s Manual (concise)

which is a book. Your projector should come with the items shown there.

Require of your dealer immediately if any items are missing.

Features

►Keep small parts away from children and pets. Take care not

to put in the mouth. If swallowed, consult a physician immediately for emergency

treatment.

WARNING

ü The HDMI/DVI-D/HDBaseT™ ports can support various image equipment

which have digital interface to get clearer pictures on a screen.

ü Equips with two COLOR WHEEL, to enhance brightness and color.

ü Some optional lens units and the wide range of lens shift feature will give

much more chances to install the product wherever you want.

Has an HDCR feature which is Hitachi's original image stabilizer for a

clearer image.

ü The wealth of I/O ports is believed to support any business scene.

Equipped with geometry correction which corresponds to aspect and

di󱐯erent kinds of screen.

Introduction

Projector

(1) Dust protector

(2) Remote sensors(19)

(3) Elevator feet (x2) (29)

(4) AC (AC inlet) (17)

(5) Holes for Cable Tie(14)

(6) Security slot (16)

(7) Security bar (16)

(8) Control panel (5)

(9) Status Monitor(20)

(10) Ports (5)

(11) Indicators (5)

(12) Intake vents (102)

(13) Exhaust vents(102)

(14) LAMP - 1 lamp cover (99)

(15) LAMP - 2 lamp cover (99)

(16) Battery cover

The internal clock battery is

inside (104).

(1)

(3) (2)

(4)

(5)

(6)

(7)

(8)

(9) (10) (11) (12)

(11)

(13)

(14)

(15)

(16)

►Do not open or remove any portion of the product, unless the

manuals direct it.

►Do not subject the projector to unstable conditions.

►Do not apply a shock or pressure to this product. Remove all the attachments

including the power cord and cables, from the projector when carrying the

projector.

►Do not look into the lens and the openings on the projector while the lamp is

on.

►Do not touch around the lamp cover and the exhaust vents during use

or just after use, since it is too hot.

WARNING

►Do not attach anything onto the lens, it could damage the

lens, such as melting the lens.

CAUTION

Part names

Control panel and Indicators

(1) STANDBY/ON button (26)

(2) INPUT button (27)

(3) MENU button (48)

(4) LENS SHIFT button (30)

(5) ZOOM button (30)

(6) FOCUS - / + buttons (30)

(7) SHUTTER button (43)

(8) FUNCTION button (30, 31)

(9) FILTER indicator (110, 112)

(10) SHUTTER indicator (111)

(11) SECURITY indicator (111)

(12) LAMP-2 indicator (109)

(13) LAMP-1 indicator (109)

(14) TEMP indicator (107 to 111)

(15) POWER indicator (106 to 107)

(16) LAMP-2 indicator (109)

(17) LAMP-1 indicator (109)

Ports

Introduction

Part names (continued)

(continued on next page)

(1) MONITOR OUT port

(2) COMPUTER IN1 ports

(3) HDMI 1 port

(4) HDMI 2 port

(5) DVI-D port

(6) HDBaseT™ port

(7) WIRELESS port

(8) LAN

(9) COMPUTER IN2 ports

(R/Cr/Pr, G/Y, B/Cb/Pb, H, V)

(10) CONTROL port

(11) REMOTE CONTROL IN port

(12) REMOTE CONTROL OUT port

(13) VIDEO port

SHUTTER

(5)

(8)

(1)

(3)

(4)

(6)

(2)

(7)

(2)

(1)

(3)

(9) (10) (11) (12) (13) (14) (15)

(16) (17)

(4) (5) (6) (7)

(8)

(9)

(10) (11) (12) (13)

Introduction

Part names (continued)

• Any button marked

with “*” is not

supported on this

projector (27).

• Each time you

press any button

(except ID buttons),

the ID button of

current selected ID

number will light

(18).

NOTE

Remote control

(1) STANDBY button (26)

(2) ON button (26)

(3) ID - 1 / 2 / 3 / 4 buttons (18)

(4) COMPUTER 1 button (27)

(5) COMPUTER 2 button (27)

(6) COMPUTER 3 button *

(7) LAN button (27)

(8) USB TYPE A button *

(9) USB TYPE B button *

(10) HDBaseT button (27)

(11) COMPONENT button *

(12) VIDEO button (27)

(13) HDMI 1 button (27)

(14) HDMI 2 button (27)

(15) DVI-D button (27)

(16)

FOCUS

+ / -

buttons

(30)

(17) LENS MEMORY SAVE / LOAD button (31)

(18) ZOOM + / - buttons (30)

(19) LOCK button (32)

(20) LENS SHIFT button (30)

(21) SHUTTER button (43)

(22) ENTER button (48)

(23) ▲/▼/◄/►cursor buttons

(24) FREEZE button (43)

(25) MENU button (48)

(26) HDCR button (33)

(27) ASPECT button (28)

(28) PbyP button (44)

(29) RESET button (48)

(30) C.WHEEL button (33)

(31) AUTO button (32)

(32) OSD button (33)

(33) MAGNIFY buttons (42)

(34) PICTURE button (33)

(35) KEYSTONE button (34)

(36) LAMP button (33)

(37) MY BUTTON - 1, 2, 3, 4 buttons (83)

(38) Battery cover (18)

(39) Wired remote control port (14)Back of

the remote

control

(1)

(3)

(4)

(7)

(8)

(10)

(13)

(14)

(16)

(19)

(20)

(22)

(2)

(5)

(6)

(9)

(11)

(12)

(15)

(18)

(17)

(21)

(23)

(38)

(25)

(39)

(26)

(24)

(27) (28)

(29)

(30)

(31) (32)

(33)

(34)

(35)

(36)

(37)

Setting up

Install the projector according to the environment and manner the projector will be

used in.

For the case of installation in a special state such as ceiling mount, the specied

mounting accessories (Specications in the User’s Manual (concise)) and

service may be required. Before installing the projector, consult your dealer about

your installation.

Arrangement

Refer to tables T-1 to T-3 at the back of User's Manual (concise) as well as the

following to determine the screen size and projection distance. The values shown

in the table are calculated for a full size screen.

Ⓗ × Ⓥ : Screen size

ⓐ : Projection distance

(from the front of the projector unit)

ⓑ,ⓒ: Screen height

(continued on next page)

Projector top

Projector bottom

Installing the lens unit

See the manual of the optional lens.

Setting up

Arrangement (continued)

WARNING

(continued on next page)

►Install the projector where you can access the power

outlet easily. If an abnormality should occur, unplug the projector urgently.

Otherwise it could cause a re or electric shock.

►Do not subject the projector to unstable conditions. If the projector falls

or topples over, it could result in injury or damage to the projector and the

surrounding things. Using a damaged projector could result in a re and an

electric shock.

• Do not place the projector in unstable places, such as an inclined surface,

places subject to vibration, on top of a wobbly table or cart, or a surface that is

smaller than the projector.

• Do not put the projector on its side, front or rear position.

• Do not attach nor place anything on the projector unless otherwise specied in

the manual.

• Do not use any mounting accessories except the accessories specied by the

manufacturer. Read and keep the manuals of the accessories used.

• For special installation such as ceiling mounting, be sure to consult your dealer

beforehand.

• It is possible to install the projector for any direction with specied mounting

accessories. Consult with your dealer about such a special installation.

• DLP chip(s) is/are precision-made parts. In rare cases, pixels may be missing

or lit, but this is not a malfunction.

• Direct high-power laser beam onto the lens surface can damage the DLP

chip(s).

• The projector is equipped with precision-made parts, handle with care while

moving. Remove all the attachments including the power cord and cables, from

the projector when carrying the projector.

►Do not install the pro

jector near thermally conductive or ammable

things. Such things when heated by the projector could result in a re and burns.

• Do not place the projector on a metal stand.

►Do not place the projector where any oils, such as cooking or machine

oil, are used. Oil may harm the product, resulting in malfunction, or falling from

the mounted position.

►Do not place the projector in a place where it may get wet. Getting the

projector wet or inserting liquid into the projector could cause a re and an

electric shock, and damage the projector.

• Do not place the projector near water, such as in a bathroom, kitchen, or

poolside.

• Do not place the projector outdoors or by the window.

• Do not place anything containing liquid near the projector.

Setting up

Arrangement (continued)

►Place the projector in a cool place with sufcient

ventilation. The projector may shutdown automatically or may malfunction if its

internal temperature is too high.

Using a damaged projector could result in a re and an electric shock.

• Do not place the projector in direct sunlight or near hot objects such as heaters.

• Do not place the projector where the air from an air conditioner or similar unit

will blow on it directly.

• Keep a space of 50 cm or more between a side of the projector and other

objects such as walls.

• Do not place the projector on carpet, cushions or bedding.

• Do not stop up, block nor cover the projector's vent holes. Do not place

anything around the projector that could be sucked in or stuck to the projector's

intake vents.

• Do not place the projector at places that are exposed to magnetic elds, doing

so can cause the cooling fans inside the projector to malfunction.

►Avoid placing the projector in smoky, humid or dusty place. Placing the

projector in such places could cause a re, an electric shock and malfunction of

the projector.

• Do not place the projector near humidiers. Especially for an ultrasonic

humidier, chlorine and minerals contained in tap water are atomized and could

be deposited in the projector causing image degradation or other problems.

• Do not place the projector in a smoking area, kitchen, passageway or by the

window.

• Position the projector to prevent light from directly hitting the

projector's remote sensor.

• Do not place the product in a place where radio interference may be caused.

• Set the ALTITUDE of the SERVICE item in the OPTION menu correctly. It is

recommended to leave it at AUTO usually (84). If the projector is used with a

wrong setting, it may cause damage to the projector itself or the parts inside.

• Keep heat-sensitive things away from the projector. Otherwise, they may be

damaged by the heat from the projector.

CAUTION

NOTICE

Setting up

Connecting with your devices

Before connecting the projector to a device, consult the manual of the device to

conrm that the device is suitable for connecting with this projector and prepare

the required accessories, such as a cable in accord with the signal of the device.

Consult your dealer when the required accessory did not come with the product or

the accessory is damaged.

After making sure that the projector and the devices are turned off, perform

the connection, according to the following instructions. Refer to the gures in

subsequent pages.

Before connecting the projector to a network system, be sure to read Network

Guide too.

►Use only the appropriate accessories. Otherwise it could

cause a re or damage the projector and devices.

• Use only the accessories specied or recommended by the projector’s

manufacturer. It may be regulated under some standard.

• Neither disassemble nor modify the projector and the accessories.

• Do not use the damaged accessory. Be careful not to damage the accessories.

Route a cable so that it is neither stepped on nor pinched out.

WARNING

►For a cable with a core at only one end, connect the end

with the core to the projector. That may be required by EMI regulations.

CAUTION

• Plug-and-Play is a system composed of a computer, its operating system

and peripheral equipment (i.e. display devices). This projector is VESA DDC

2B compatible. Plug-and-Play can be used by connecting this projector to a

computer that is VESA DDC (display data channel) compatible.

- Take advantage of this feature by connecting a computer cable to the

COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work

properly if any other type of connection is attempted.

- Please use the standard drivers in your computer as this projector is a Plug-

and-Play monitor.

• Do not turn on or off the projector while connected to a device in

operation, unless that is directed in the manual of the device. Otherwise it may

cause malfunction in the device or projector.

• The function of some input ports can be selected according to your usage

requirements. Check the reference page indicated beside each port in the

following illustration.

• Be careful not to mistakenly connect a connector to a wrong port. Otherwise it

may cause malfunction in the device or projector.

- When connecting a connector to a port, make sure that the shape of the

connector ts the port.

- Tighten the screws to connect a connector equipped with screws to a port.

- Use the cables with straight plugs, not L-shaped ones, as the input ports of

the projector are recessed.

About Plug-and-Play capability

NOTE

(continued on next page)

Autres manuels pour CP-X9110

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hitachi Projecteur

Hitachi

Hitachi CP-X443 series Manuel utilisateur

Hitachi

Hitachi CP-A222WN Manuel utilisateur

Hitachi

Hitachi Innovate ED-X26 Manuel utilisateur

Hitachi

Hitachi IPJ-AW250N Manuel utilisateur

Hitachi

Hitachi CP-X4021N Manuel utilisateur

Hitachi

Hitachi CP-X4011N Manuel utilisateur

Hitachi

Hitachi Innovate CP-X2520 Manuel utilisateur

Hitachi

Hitachi CP-S210 series Manuel utilisateur

Hitachi

Hitachi CP-WX11000 Manuel utilisateur

Hitachi

Hitachi Innovate CP-RX78 Manuel utilisateur

Hitachi

Hitachi CP-X275WA Manuel utilisateur

Hitachi

Hitachi CP-X958W/E Manuel utilisateur

Hitachi

Hitachi CP X206 - XGA LCD Projector Instructions d'installation et d'entretien

Hitachi

Hitachi Innovate CP-X2520 Manuel utilisateur

Hitachi

Hitachi CP-X5022WN Manuel utilisateur

Hitachi

Hitachi CP-X995J Manuel utilisateur

Hitachi

Hitachi CP-X9 Manuel utilisateur

Hitachi

Hitachi ED-S3170 series Manuel utilisateur

Hitachi

Hitachi CP-TW2503 Manuel utilisateur

Hitachi

Hitachi CPX10WN Manuel utilisateur

Hitachi

Hitachi CP-X4021N Document technique

Hitachi

Hitachi CP-X268AWF Document technique

Hitachi

Hitachi LP-EW5002 Manuel utilisateur

Hitachi

Hitachi CP-WX625 Document technique

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
