Hitachi CP-X8150 Manuel utilisateur

Projector

CP-X8150/CP-X8160/CP-WX8240/

CP-WX8255/CP-SX8350/CP-WU8440/

CP-WU8450/CP-WX8240A/CP-WX8255A

User's Manual (detailed)

Operating Guide

Thank you for purchasing this projector.

►Before using this product, please read all manuals for this

product. Be sure to read Safety Guide ﬁrst. After reading them, store them in a

safe place for future reference.

WARNING

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in

this manual.

• The reproduction, transfer or copy of all or any part of this document is not

permitted without express written consent.

NOTE

Trademark acknowledgment

Various symbols are used in this manual. The meanings of these symbols are

described below.

About this manual

WARNING

CAUTION

This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

This symbol indicates information that, if ignored, could possibly

result in personal injury or physical damage due to incorrect handling.

Please refer to the pages written following this symbol.



• Mac®is a registered trademark of Apple Inc.

• Windows®, DirectDraw®and Direct3D®are registered trademarks of Microsoft Corporation

in the U.S. and/or other countries.

• VESA and DDC are trademarks of the Video Electronics Standard Association.

•

HDMI

, the HDMI logo, and High-Deﬁnition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United States and other countries.

•

Trademark PJLink is a trademark applied for trademark rights in

Japan, the United States of America and other countries and areas.

• Blu-ray DiscTM and Blu-rayTM are trademarks of Blu-ray Disc Association.

• DICOM®is the registered trademark of the National Electrical Manufacturers Association

for its standards publications relating to digital communications of medical information.

All other trademarks are the properties of their respective owners.

NOTICE This entry notices of fear of causing trouble.

Contents

Introduction . ..............3

Features ......................3

Checking the contents of package

....3

Part names . ...................4

Projector, Control panel and Indicators,

Ports, Remote control

Setting up . ................7

Arrangement . ..................7

Connecting with your devices . ....10

Fastening the cables

Fastening the adapter cover . .....15

Using the security bar and slot . . . . 15

Connecting to a power supply .....16

Remote control ............17

Installing the batteries...........17

Using the REMOTE ID function ...17

Changing the frequency of remote control signal

..18

About the remote control signal ...18

Using as a simple PC mouse & keyboard

..19

Status Monitor . ...........20

<Only for CP-X8160, CP-WX8255,

CP-WX8255A and CP-WU8450>

Displaying the condition of the projector

. . 20

Displaying the log . .............22

Power on/off . .............24

Turning on the power . ..........24

Turning off the power . ..........24

Operating . ...............25

Adjusting the volume ............25

Temporarily turning off the screen and audio

..25

Selecting an input signal .........26

Selecting an aspect ratio .........27

Adjusting the projector's elevator

....28

Adjusting the lens . .............29

Adjusting the zoom and focus,

Adjusting the lens position, Lens memory

Using the automatic adjustment feature

..31

Adjusting the position ...........31

Correcting the distortion .........32

Using the magnify feature ........35

Temporarily freezing the screen . . . 36

Temporarily shading the screen . . . 36

PbyP . .......................37

<Only for CP-WX8240A, CP-WX8255A,

CP-WU8440 and CP-WU8450>

Using the menu function .........39

Indication in OSD,

Containing items of each menu



EASY MENU. . . . . . . . . . . . . . . 42

PICTURE menu . ...........44

IMAGE menu . .............47

INPUT menu . .............50

SETUP menu ..............54

AUDIO menu . .............57

SCREEN menu.............59

OPTION menu . ............65

NETWORK menu ...........76

SECURITY menu ...........87

Presentation tools . ........94

PC-LESS Presentation . .........94

Thumbnail Mode, Full Screen Mode,

Slideshow Mode, Playlist

Drawing function ..............104

Connecting the devices,

Using the Drawing function

USB Display .................109

Starting USB Display, Right-Click menu,

Floating menu, Options window

Maintenance .............113

Replacing the lamp ............ 113

Cleaning and replacing the air ﬁlter . 115

Other care................... 117

Troubleshooting . .........118

Warnings displayed on the Status Monitor

. . 118

<Only for CP-X8160, CP-WX8255,

CP-WX8255A and CP-WU8450>

Related messages . ........... 118

Regarding the indicator lamps . . . 120

Resetting all settings...........122

Phenomena that may be easy to

be mistaken for machine defects

. . 123

Speciﬁcations ............128



Introduction

• Keep the original packing materials, for future reshipment. Be sure

to use the original packing materials when moving the projector. Use special

caution for the lens.

• The projector may make a rattling sound when tilted, moved or shaken, since

a ﬂap to control the air ﬂow inside of the projector has moved. Be aware that

this is not a failure or malfunction.

NOTE

Introduction

The projector provides you with the broad use by the following features.

Checking the contents of package

The HDMI ports can support various image equipment which have digital

interface to get clearer pictures on a screen.

The super bright lamp and high quality optical system can fulﬁll the demands

of professional uses.

Some optional lens units and the wide range of the lens shift feature will give

much more chances to install the product wherever you want.

The lens shade can hide your inside operations and will help your

presentation.

The wealth of I/O ports is believed to support any business scene.

Please see the Contents of package section in the User’s Manual (concise)

which is a book. Your projector should come with the items shown there. Require

of your dealer immediately if any items are missing.

Features

►Keep small parts away from children and pets. Take care not

to put in the mouth. If swallowed, consult a physician immediately for emergency

treatment.

WARNING

Introduction

Part names

Projector

(1) Lamp cover (113)

The lamp unit is inside.

(2) Speakers (x2) (25, 57)

(3) Filter cover (115)

The air ﬁlter and intake vent are inside.

(4) Elevator feet (x2) (28)

(5) Elevator buttons (x2) (28)

(6) Remote sensors (x2) (18, 71)

(7) Lens

(8) Lens cover

(9) Indicators (5)

(10) Intake vents

(11) Control panel (5)

(12) Status Monitor (20)

<Only for CP-X8160, CP-WX8255,

CP-WX8255A and CP-WU8450>

(13) AC IN (AC inlet) (16)

(14) Exhaust vents

(15) Ports (5)

(16) Security bar (15)

(17) Security slot (15)

(18) Grip (below)

(19) Safety bar (15)

►Do not open or remove any portion of the product, unless the

manuals direct it.

►Do not subject the projector to unstable conditions.

►Do not apply a shock or pressure to this product. Place

your hands on the grip on the bottom of the projector when

carrying the projector. Remove all the attachments including

the power cord and cables, from the projector when carrying

the projector.

►Do not look into the lens and the openings on the projector while the lamp is

on.

WARNING

►Do not touch around the lamp cover and the exhaust vents

during use or just after use, since it is too hot.

►Do not attach anything onto the lens except the lens cover of this

projector because it could damage the lens, such as melting the lens.

CAUTION

(continued on next page)

Grip

(10)

(3)

(5)

(4)

(9)

(2)

(7) (6)

(4)

(11)

(14)

(10)

(13) (17) (16)

(1)

(19) (18)

(6)

(8)

(15)

(5)

(12)

Control panel and Indicators

(1) STANDBY/ON button (24)

(2) INPUT button (26, 39)

(3) MENU button (39)

(4) LENS SHIFT button (29)

(5) ZOOM button (29)

(6) FOCUS - / +buttons (29)

(7) SHADE button (36)

(8) FUNCTION button (22, 29)

(9) FILTER indicator (122)

(10) SHADE indicator (36)

(11) SECURITY indicator (93)

(12) LAMP indicator (120, 121)

(13) TEMP indicator (120, 121)

(14) POWER indicator (24, 120, 121)

Ports (10 ~ 14)

(1) COMPUTER IN1 port

(2) COMPUTER IN2 ports

(G/Y, B/Cb/Pb, R/Cr/Pr, H, V)

(3) LAN port

(4) USB TYPE A ports

(5) USB TYPE B port

(6) HDMI 1 port

(7) HDMI 2 port

(8) COMPONENT ports

(Y,Cb/Pb, Cr/Pr)

(9) S-VIDEO port

(10) VIDEO port

(11) AUDIO IN1 port

(12) AUDIO IN2 port

(13) AUDIO IN3 (L, R) ports

(14) AUDIO OUT (L, R) ports

(15) MONITOR OUT port

(16) REMOTE CONTROL IN port

(17) REMOTE CONTROL OUT port

(18) CONTROL port

Introduction

Part names (continued)

(continued on next page)

(5)

(8)

(1)

(3)

(4)

(6)

(2)

(9) (10) (11) (12) (13) (14)

(7)

(1)

(2)

(4)

(3)

(18)

(5) (6) (10) (7)

(9)

(16) (14) (13) (12) (11) (15)(8)(17)

Introduction

Part names (continued)

• Any button marked with “*” is not supported on this projector (119).

• Any button marked with “○” is available only for CP-WX8240A, CP-WX8255A,

CP-WU8440 and CP-WU8450.

• Each time you press any button (except ID buttons), the ID button of current

selected ID number will light (17).

NOTE

Back of

the remote control

Remote control

(1) STANDBY button (24)

(2) ON button (24)

(3) ID - 1 / 2/ 3/ 4buttons (17)

(4) COMPUTER 1 button (26)

(5) COMPUTER 2 button (26)

(6) COMPUTER 3 button *

(7) LAN button (26)

(8) USB TYPE A button (26)

(9) USB TYPE B button (26)

(10) COMPONENT button (26)

(11) S-VIDEO button (26)

(12) VIDEO button (26)

(13) HDMI 1 button (26)

(14) HDMI 2 button (26)

(15) DIGITAL button *

(16)

PAGE UP / PAGE DOWN buttons

(19, 96)

(17) F5 button (18, 19)

(18) ENTER button (19, 22, 39)

(19) RESET button (39)

(20) ESC button (19, 39)

(21) ▲/▼/◄/►cursor buttons

(22) MENU button (39)

(23) VOL + / -buttons (25)

(24) AV MUTE button (25)

(25) MAGNIFY ON / OFF buttons (35)

(26) FREEZE button (36)

(27) PbyP button ○ (37)

(28) ASPECT button (27)

(29) AUTO button (31)

(30) POSITION button (30, 31, 40)

(31) KEYSTONE button (32)

(32) MY BUTTON - 1, 2, 3, 4buttons (68)

(33) LENS SHIFT button (29)

(34) LENS MEMORY button (30)

(35) FOCUS + / -buttons (29)

(36) ZOOM + / -buttons (29)

(37) Battery cover (17) (38) Wired remote control port (14)

(1)

(3)

(4)

(7)

(8)

(10)

(13)

(14)

(16)

(26)

(17)

(18)

(19)

(20)

(32)

(30)

(31)

(2)

(5)

(6)

(9)

(11)

(12)

(15)

(23)

(25)

(24)

(21)

(22)

(29)

(33)

(37)

(34) (36)

(35)

(27) (28)

(38)

Setting up

Install the projector according to the environment and manner the projector will be

used in.

For the case of installation in a special state such as ceiling mount, the speciﬁed

mounting accessories (Speciﬁcations in the User’s Manual (concise)) and

service may be required. Before installing the projector, consult your dealer about

your installation.

Arrangement

Refer to tables T-1 to T-6 at the back of User's Manual (concise) as well as the

following to determine the screen size and projection distance. The values shown

in the table are calculated for a full size screen.

Ⓗ×Ⓥ : Screen size

ⓐ:

Projection distance

(from the front of the projector unit)

ⓑ,ⓒ: Screen height

(continued on next page)

Projector top

Projector bottom

Setting up

Arrangement (continued)

WARNING

(continued on next page)

►Install the projector where you can access the power

outlet easily. If an abnormality should occur, unplug the projector urgently.

Otherwise it could cause a ﬁre or electric shock.

►Do not subject the projector to unstable conditions. If the projector falls

or topples over, it could result in injury or damage to the projector and the

surrounding things. Using a damaged projector could result in a ﬁre and an

electric shock.

• Do not place the projector in unstable places, such as an inclined surface,

places subject to vibration, on top of a wobbly table or cart, or a surface that is

smaller than the projector.

• Do not put the projector on its side, front or rear position.

• Do not attach nor place anything on the projector unless otherwise speciﬁed in

the manual.

• Do not use any mounting accessories except the accessories speciﬁed by the

manufacturer. Read and keep the manuals of the accessories used.

• For special installation such as ceiling mounting, be sure to consult your dealer

beforehand.

• Only for CP-X8160, CP-WX8255, CP-WX8255A and CP-WU8450, it is possible

to install the projector for any direction with speciﬁed mounting accessories.

Consult with your dealer about such a special installation.

• Place your hands on the grip on the bottom of the projector when carrying the

projector. Remove all the attachments including the power cord and cables,

from the projector when carrying the projector.

►Do not install the pro

jector near thermally conductive or ﬂammable

things. Such things when heated by the projector could result in a ﬁre and burns.

• Do not place the projector on a metal stand.

►Do not place the projector where any oils, such as cooking or machine

oil, are used. Oil may harm the product, resulting in malfunction, or falling from

the mounted position.

►Do not place the projector in a place where it may get wet. Getting the

projector wet or inserting liquid into the projector could cause a ﬁre and an

electric shock, and damage the projector.

• Do not place the projector near water, such as in a bathroom, kitchen, or

poolside.

• Do not place the projector outdoors or by the window.

• Do not place anything containing liquid near the projector.

Setting up

Arrangement (continued)

►Place the projector in a cool place with sufﬁcient

ventilation. The projector may shutdown automatically or may malfunction if its

internal temperature is too high.

Using a damaged projector could result in a ﬁre and an electric shock.

• Do not place the projector in direct sunlight or near hot objects such as heaters.

• Do not place the projector where the air from an air conditioner or similar unit

will blow on it directly.

• Keep a space of 30 cm or more between a side of the projector and other

objects such as walls.

• Do not place the projector on carpet, cushions or bedding.

• Do not stop up, block nor cover the projector's vent holes. Do not place

anything around the projector that could be sucked in or stuck to the projector's

intake vents.

• Do not place the projector at places that are exposed to magnetic ﬁelds, doing

so can cause the cooling fans inside the projector to malfunction.

►Avoid placing the projector in smoky, humid or dusty place. Placing the

projector in such places could cause a ﬁre, an electric shock and malfunction of

the projector.

• Do not place the projector near humidiﬁers. Especially for an ultrasonic

humidiﬁer, chlorine and minerals contained in tap water are atomized and could

be deposited in the projector causing image degradation or other problems.

• Do not place the projector in a smoking area, kitchen, passageway or by the

window.

• Position the projector to prevent light from directly hitting the

projector's remote sensor.

• Do not place the product in a place where radio interference may be caused.

• Set the ALTITUDE of the SERVICE item in the OPTION menu correctly. It is

recommended to leave it at AUTO usually (69). If the projector is used with a

wrong setting, it may cause damage to the projector itself or the parts inside.

• Keep heat-sensitive things away from the projector. Otherwise, they may be

damaged by the heat from the projector.

CAUTION

NOTICE

Setting up

Connecting with your devices

Before connecting the projector to a device, consult the manual of the device to

conﬁrm that the device is suitable for connecting with this projector and prepare

the required accessories, such as a cable in accord with the signal of the device.

Consult your dealer when the required accessory did not come with the product or

the accessory is damaged.

After making sure that the projector and the devices are turned off, perform

the connection, according to the following instructions. Refer to the ﬁgures in

subsequent pages.

Before connecting the projector to a network system, be sure to read Network

Guide too.

►Use only the appropriate accessories. Otherwise it could

cause a ﬁre or damage the projector and devices.

• Use only the accessories speciﬁed or recommended by the projector’s

manufacturer. It may be regulated under some standard.

• Neither disassemble nor modify the projector and the accessories.

• Do not use the damaged accessory. Be careful not to damage the accessories.

Route a cable so that it is neither stepped on nor pinched out.

WARNING

►For a cable with a core at only one end, connect the end

with the core to the projector. That may be required by EMI regulations.

CAUTION

• Plug-and-Play is a system composed of a computer, its operating system

and peripheral equipment (i.e. display devices). This projector is VESA DDC

2B compatible. Plug-and-Play can be used by connecting this projector to a

computer that is VESA DDC (display data channel) compatible.

- Take advantage of this feature by connecting a computer cable to the

COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work

properly if any other type of connection is attempted.

- Please use the standard drivers in your computer as this projector is a Plug-

and-Play monitor.

• Do not turn on or off the projector while connected to a device in

operation, unless that is directed in the manual of the device. Otherwise it may

cause malfunction in the device or projector.

• The function of some input ports can be selected according to your usage

requirements. Check the reference page indicated beside each port in the

following illustration.

• Be careful not to mistakenly connect a connector to a wrong port. Otherwise it

may cause malfunction in the device or projector.

- When connecting a connector to a port, make sure that the shape of the

connector ﬁts the port.

- Tighten the screws to connect a connector equipped with screws to a port.

- Use the cables with straight plugs, not L-shaped ones, as the input ports of

the projector are recessed.

About Plug-and-Play capability

NOTE

(continued on next page)

Autres manuels pour CP-X8150

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hitachi Projecteur

Hitachi

Hitachi ED-X24 and Document technique

Hitachi

Hitachi IPJ-AW250N Document technique

Hitachi

Hitachi CP-X255 Manuel utilisateur

Hitachi

Hitachi CP-X4022WN Manuel utilisateur

Hitachi

Hitachi CP-RS57 series Manuel utilisateur

Hitachi

Hitachi CP-X880W Manuel utilisateur

Hitachi

Hitachi CP-S335 series Manuel utilisateur

Hitachi

Hitachi CP-D10 Series Manuel utilisateur

Hitachi

Hitachi Innovate ED-A101 Manuel utilisateur

Hitachi

Hitachi CP-X2 series Document technique

Hitachi

Hitachi CP-X2011N Manuel utilisateur

Hitachi

Hitachi CP-WX625 Manuel utilisateur

Hitachi

Hitachi CP-X10000 Series Manuel utilisateur

Hitachi

Hitachi LP-EU5002 Manuel utilisateur

Hitachi

Hitachi CP-DX250 guide Manuel utilisateur

Hitachi

Hitachi CP-WX1100 Manuel utilisateur

Hitachi

Hitachi CP-SX1350 Series Manuel utilisateur

Hitachi

Hitachi CP-RX61 series Manuel utilisateur

Hitachi

Hitachi CP-X885 Series Manuel utilisateur

Hitachi

Hitachi X807 - CP XGA LCD Projector Manuel utilisateur

Hitachi

Hitachi CP-EX250N Manuel utilisateur

Hitachi

Hitachi CP-WX11000 Manuel utilisateur

Hitachi

Hitachi Illumina PJ-TX10 Manuel utilisateur

Hitachi

Hitachi CP-RX70(M1-20EN) Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
