Hitachi HDC-1491EP Manuel utilisateur

QSG-1

GETTING TO KNOW YOUR CAMERA

Front View

Rear View

Item Function

Capture Mode Video Mode Playback Mode

1. Shutter button Record button Still image: to capture mode

Video clip: to capture mode

2. :Zooms out :Zooms in :Zooms out :Zooms in :Zooms out :Zooms in

3. Switches to:

Video mode >capture mode

Switches to:

capture mode >Video mode

Still image: to capture mode

Video clip: to capture mode

4. Focus Focus Next 10th image

5. Flash -- Next image

6. If any scene mode is set:

switches to scene mode

selection screen --

Still image: to display image

Records voice memo ( if

“Voice Memo” is “On”).

Video clip: to play video clip

7. Self-timer Self-timer Previous 10th image

8. Compensations>P-- Previous image

9. Playback Mode Playback Mode Still image: to capture mode

Video clip: to capture mode

10. Capture menu Video menu Playback menu

1. Shutter button

2. ON/OFF Power button

3. Flash

4. Self-timer LED

5. Microphone

6. USB terminal

7. Lens

a. LCD monitor

b. Status LED

c. Strap holder

d. Battery / Memory card cover

e. Tripod socket

Helpline Number: 08704460806

QSG-2

GETTING STARTED

Preparation

1. Attach the camera strap.

2. Open the battery/memory card cover.

3. Insert the supplied batteries with correct orientation as

shown.

4. Insert an SD/SDHC memory card (Optional).

The camera has 32MB internal memory (23MB

available for image storage), but you can load an SD/

SDHC memory card to expand the camera’s memory

capacity.

Be sure to format the memory card with this camera

before its initial usage.

5. Close the battery/memory card cover and make sure it is

locked securely.

QSG-3

CAPTURE MODE

Capturing Images

Your camera is equipped with a 2.7" full colour TFT LCD monitor to help you compose

images, playback recorded images/video clips or adjust menu settings.

1. Press the ON/OFF button to turn the power on.

2. Press the MODE button, and set the camera mode to [ ].

3. Compose your image in the LCD monitor.

Turn the zoom lever to side to zoom in on the subject, and enlarges the

subject on the LCD monitor.

Turn the zoom lever to side to zoom out on the subject, and provides a wider

angle image.

4. Press the shutter button.

Pressing the shutter button down

halfway automatically focuses and

adjusts the exposure, and pressing the

shutter button down fully captures the

image.

The focus area frame turns green when

the camera is in focus and the exposure

is calculated.

When the focus is not suitable, the frame

of the focus area turns red.

QSG-4

PLAYBACK MODE

Playing Back Still Images

You can play back the still images on the LCD monitor.

1. Press the 7button.

The last image appears on the screen.

2. The images can be displayed in forward or

reverse sequence with the e/ fbuttons.

To view the previous image, press the e

button.

To view the next image, press the fbutton.

Turn the zoom lever to side enlarges the

image.

To return to normal magnification, turn the

zoom lever to side.

QSG-5

VIDEO MODE

Recording Video Clips

This mode allows you to record video clips at a resolution of 320 x 240 / 640 x 480/

720p pixels.

1. Press the MODE button, and set the camera mode to

[].

2. Compose the image.

3. Press the shutter button.

The recording of the video clip will start.

Pressing the shutter button one more time will end the

recording of the video clip.

The recording time depends on the storage size and

the subject of the image to be recorded.

The zoom function cannot be used during video recording.

Playing Back Video Clips

You can play back recorded video clips on the camera.

1. Press the 7button.

The last image appears on the screen.

2. Select the desired video clip with the e/ fbuttons.

3. Press the SET button.

A press of the f/ ebuttons during playback allows fast forward play / fast

reverse play.

To stop video playback, press the dbutton.

This stops playback and returns to the start of the video clip.

To pause video playback, press the SET button.

This pauses video playback.

To cancel pause, press the SET button again.

QSG-6

Erasing Images

Erasing in Photography Mode (Quick Delete Function)

The quick delete function enables you to delete

the last captured image during capture.

1. Press the 7button.

The last image appears on the screen.

2. Select the image you want to erase with the e/

fbuttons.

3. Press the MENU button.

4. Select [Delete] with the c/ dbuttons, and

press the SET button.

5. Select [Single] or [All] with the e/ fbuttons,

and press the SET button.

[Single]: Erases the selected image or the

last image.

[All]: Erases all of the images except for the

protected images.

6. Select [Execute] with the e/ fbuttons, and

press the SET button.

To not erase, select [Cancel], and press the

SET button.

7. To exit from the menu, press the MENU button.

MENU SET

;;

QSG-7

TRANSFERRING FILES TO YOUR

COMPUTER

System Requirement

Downloading Your Files

1. Connect one end of the USB cable to an available

USB port on your computer.

2. Connect the other end of the USB cable to the

USB terminal on the camera.

3. Turn on your camera.

4. Select [PC] using the c/ dbuttons and press the

SET button.

5. From the Windows desktop, double click on “My

Computer”.

6. Look for a new “removable disk” icon.

This “removable disk” is actually the memory (or memory card) in your camera.

Typically, the camera will be assigned drive letter “e” or higher.

7. Double click on the removable disk and locate the DCIM folder.

8. Double click on the DCIM folder to open it to find more folders.

Your recorded images and video clips will be inside these folders.

9. Copy & Paste or Drag-N-Drop image and video files to a folder on your computer.

Mac users: Double-click the “untitled” or “unlabeled” disk drive icon on your desktop.

iPhoto may automatically launch.

This symbol mark [crossed-out wheeled bin] indicates separate collec-

tion of waste batteries in the EU countries. The batteries provided with

this product shall not be treated as household waste. Please use the

return and collection systems available in your country for the disposal

of the waste batteries.

If a chemical symbol is printed beneath the symbol mark, this chemical

symbol means that the batteries contains a heavy metal at a certain

concentration. It is indicated as follows:

Hg: mercury, Cd: cadmium, Pb: lead.

Windows Macintosh

Pentium III 1GHz or equivalent

Windows XP/Vista/7

512MB RAM

150MB available hard disk space

CD-ROM drive

Available USB port

PowerPC G3/G4/G5

OS 10.3.9 or later

256MB RAM (512 MB recommended)

128MB available hard disk space

CD-ROM drive

Available USB port

EN-1

FCC STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

Note:

This equipment has been tested and found to comply with the limits for Class B digital

devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.This

equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15

of the FCC rules.

Do not make any changes or modifications to the equipment unless otherwise

specified in the manual. If such changes or modifications should be made, you could

be required to stop operation of the equipment.

Notice

If static electricity or electromagnetism causes data transfer to discontinue midway

(fail), restart the application or disconnect and connect the communication cable

(USB, etc.) again.

EN-2

READ THIS FIRST

Trademark Information



Microsoft®and Windows®are U.S. registered trademarks of Microsoft Corporation.

Pentium®is a registered trademark of Intel Corporation.

Macintosh is a trademark of Apple Inc.

SD™ is a trademark.

SDHC™ is a trademark.

Other names and products may be trademarks or registered trademarks of their

respective owners.

Product Information

Product design and specifications are subject to change without notice. This

includes primary product specifications, software, software drivers, and user’s

manual. This User Manual is a general reference guide for the product.

The product and accessories that come with your camera may be different from

those described in this manual. This is due to the fact that different retailers often

specify slightly different product inclusions and accessories to suit their market

requirements, customer demographics, and geographical preferences. Products

very often vary between retailers especially with accessories such as batteries,

chargers, AC adapters, memory cards, cables, pouches, and language support.

Occasionally a retailer will specify a unique product colour, appearance, and

internal memory capacity. Contact your dealer for precise product definition and

included accessories.

The illustrations in this manual are for the purpose of explanation and may differ

from the actual design of your camera.

The manufacturer assumes no liability for any errors or discrepancies in this user

manual.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hitachi Appareil photo numérique

Hitachi

Hitachi V-21W Manuel utilisateur

Hitachi

Hitachi HDC-1205E Manuel utilisateur

Hitachi

Hitachi HDC-530E Manuel utilisateur

Hitachi

Hitachi HDC-1296ER Manuel utilisateur

Hitachi

Hitachi KP-M1E/K Manuel utilisateur

Hitachi

Hitachi VME535LE Manuel utilisateur

Hitachi

Hitachi HDC-887E Manuel utilisateur

Hitachi

Hitachi KP-HD20A Manuel utilisateur

Hitachi

Hitachi HDC-1087E Manuel utilisateur

Hitachi

Hitachi HDC-88WE Manuel utilisateur

Hitachi

Hitachi SK-HD1300-S1 Manuel utilisateur

Hitachi

Hitachi GigE Manuel utilisateur

Hitachi

Hitachi HDC-401EX Manuel utilisateur

Hitachi

Hitachi VM-H80E Manuel utilisateur

Hitachi

Hitachi HDC-561E Manuel utilisateur

Hitachi

Hitachi HV-F22GV Manuel utilisateur

Hitachi

Hitachi HDC-881E Manuel utilisateur

Hitachi

Hitachi KP-FM200WCL Manuel utilisateur

Hitachi

Hitachi HDC-1097E Manuel utilisateur

Hitachi

Hitachi VZ-HD4000A Manuel utilisateur

Hitachi

Hitachi MPEGCAM MP-EG1A Manuel utilisateur

Hitachi

Hitachi VZ-HD3600A Manuel utilisateur

Hitachi

Hitachi HDC-401EX Manuel utilisateur

Hitachi

Hitachi DZ-HD90 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
