Hioki 3910-20 Manuel utilisateur

Operation Guide

For...は専用機種。複数の場合は「/」で区切る。

不要の場合はとる。

3910-20, 3911-20, 3912-20

COMMUNICATION BASE

形名を入力。複数の場合は「/」で区切る。

COMMUNICATION UTILITY

品名を入力。

Contents

Software Installation 3

Measurement Preparations 4

Setting Measurement Conditions 5

To set 3631-20 to 3635-2X, 3641 settings 6

To set 3636-20 settings 7

To set 3637-20 settings 8

To set 3638-20 settings 9

To set 3639-20 settings 10

To set 3640-20 settings 11

To set 3645-20 settings 12

Loading Measurement Data 13

Saving Measurement Data 14

Graph Operation 15

List of Functions 22

Troubleshooting 23

Installation-Related Problems 23

Communication-Related Problems 25

_____________________________________________________________________

______________________________________________________________

The latest version of COMMUNICATION UTILITY is now

available at our web site for downloading. Visit our site at:

http://www.hioki.co.jp/

NOTE

This operation guide is to introduce the user to main operations

of 3910-20, 3911-20, 3912-20 COMMUNICATION BASE

application software COMMUNICATION UTILITY.

For details, refer to 3910-20, 3911-20, 3912-20 instruction

manual and HELP in application software.

Hereinafter, when the term "COMMUNICATION BASE" is

used, the description is commonly applicable to the 3910-20,

3911-20, and 3912-20.

This operation guide is divided into six sections.

・Software installation

・Setting measurement conditions

・Loading measurement data

・Saving measurement data

・Graph operation

・List of functions

Notation

Unless otherwise specified, "Windows" represents Windows 98, Me,

2000, XP, or Vista.

Dialog box represents a Windows dialog box.

Menus, commands, dialogs, buttons in a dialog, and other names on

the screen and the keys are indicated in brackets.

Mouse Operation

Click : Press and quickly release the left button of the mouse.

Right-click : Press and quickly release the right button of the mouse.

Double click : Quickly click the left button of the mouse twice.

Drag : While holding down the left button of the mouse, move

the mouse and then release the left button to deposit

the chosen item in the desired position.

Activate : Click on a window on the screen to activate that

window.

_____________________________________________________________________

______________________________________________________________

A USB is not necessary when the PC is used in conjunction

with the 3910-20 or 3911-20.

A COM port is not necessary when the PC is used in

conjunction with the 3912-20.

NOTE

Operating environment

Computer with Pentium 90 MHz CPU or higher

Microsoft Windows98/Me/2000/XP/Vista (32 bit version)

At least 32 MB of main memory

A display with 800 X600 dot resolution

At least 256 colors

At least 4 MB of empty space on the hard disk

USB1.1 or higher is necessary, COM port

Recommended environment

Computer with Pentium 200 MHz CPU or higher

Microsoft Windows2000/XP/Vista (32 bit version)

At least 32 MB of main memory

A display with 800 X600 dot resolution

At least 65536 colors

At least 4 MB of empty space on the hard disk

USB1.1 or higher is necessary, COM port

Registered trademarks

Windows, Visual Basic and Word are registered trademarks of

Microsoft Corporation.

Pentium is registered trademark of Intel Corporation.

_____________________________________________________________________

Software Installation

______________________________________________________________

Software Installation

Packaged application software must be installed in personal

computer to use COMMUNICATION BASE and logger series.

How to install

(1) Before installing, close all running applications on your

personal computer.

(2) Execute "X: \ ENGLISH\SETUP.EXE" from attached CD-R

to COMMUNICATION BASE to install. After executing

SETUP.EXE, follow instructions on the screen to complete

installation.

(X: is CD-ROM drive)

(3) After installation, go to [Start] from the Windows menu to

start [COMMUNICATION UTILITY].

How to uninstall

Go to [Add and delete application software] from control

paneltodelete[

COMMUNICATION UTILITY].

When upgrading version, delete older application software

before installation.

_____________________________________________________________________

Measurement Preparations

______________________________________________________________

Measurement Preparations

Before using the COMMUNICATION BASE, select its

connection port. To select a connection port, first move the

mouse pointer to [Communications] in the toolbar, and then to

[Select Communication Port].

USB and COM1 through COM6 will be displayed in the

submenu. Click on the appropriate port for your

COMMUNICATION BASE. When the 3910-20 or 3911-20 is

used, select the port number to which the 3910-20 or 3911-20

is connected from among COM1 through COM6. When the

3912-20 is used, select USB.

_____________________________________________________________________

Setting Measurement Conditions

______________________________________________________________

"Settings for COMMUNICATION BASE" allow common settings

such as current time, interval, recording method and start

control in all series.

Connect COMMUNICATION BASE and logger to set settings.

"Settings for each series" are available only when personal

computer, COMMUNICATION BASE and logger are connected.

Do not disconnect the USB cable during communication with

the COMMUNICATION BASE.

NOTE

Setting Measurement Conditions

How to set measurement conditions with COMMUNICATION

UTILITY.

Go to Windows [Start] menu and start up [COMMUNICATION

UTILITY].

Select [Communications]-[

Set Measurement Conditions]on

the menu bar.

After measurement conditions are set, select [Send] to send

measurement conditions.

_____________________________________________________________________

Setting Measurement Conditions

______________________________________________________________

Settings for 3631-20 to 3635-2X and 3641 allow comment

setting in addition to common settings such as current time,

interval, recording method and start control.

NOTE

To set 3631-20 to 3635-2X, 3641 settings

Settings for 3631-20 to 3635-2X, 3641 are available only when

personal computer, COMMUNICATION BASE and logger are

connected.

Send is disabled when logger is recording, waiting for recording

or at sleep.
