HIK VISION DS-3E0105P-E Manuel utilisateur

DS-3E0105P-E/M Switch

User Manual

UD.6L0103D0392A01

User Manual

Any and all information, including, among others, wordings, pictures, graphs are the properties

of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to

be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be

reproduced, changed, translated, or distributed, partially or wholly, by any means, without the

prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any

warranties, guarantees or representations, express or implied, regarding to the Manual.

About this Manual

This Manual is applicable to DS-3E0105P-E/M.

The Manual includes instructions for using and managing the product. Pictures, charts, images

and all other information hereinafter are for description and explanation only. The information

contained in the Manual is subject to change, without notice, due to firmware updates or other

reasons. Please find the latest version in the company website

(http://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in

various jurisdictions. Other trademarks and logos mentioned below are the properties of their

respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BYAPPLICABLE LAW, THE PRODUCT

DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS

IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,

SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND

NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILLHIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FORANY

SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING,

AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH

THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNETACCESS, THE USE OF PRODUCT

SHALL BE WHOLLYAT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY

RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER

DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS

INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL

PROVIDE TIMELYTECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT

LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO

ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL

NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE

PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUALAND THE

APPLICABLE LAW, THE LATER PREVAILS.

Safety Instruction

These instructions are intended to ensure that user can user the product correctly to avoid danger

or property loss.

The precaution measure is divided into “Warning” and “Caution”.

Warning: Serious injury or death may occur if any of the warning is neglected.

Caution: Injury or equipment damage may occur if any of the caution is neglected.

Warning Follow these safeguards

to prevent serious injury or death.

Caution Follow these precautions

to prevent potential injury or

material damage.

Warning

Proper configuration of all passwords and other security settings is the responsibility of the

installer and/or end-user.

In the use of the product, you must be in strict compliance with the electrical safety

regulations of the nation and region. Refer to technical specifications for detailed

information.

Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited

Power Source with 100-240 VAC or 12 V DC according to the IEC60950-1 standard. Refer

to technical specifications for detailed information.

Do not connect several devices to one power adapter as adapter overload may cause

over-heating or a fire hazard.

Make sure that the plug is firmly connected to the power socket.

If smoke, odor or noise rise from the device, turn off the power at once and unplug the power

cable, and then contact the service center.

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

Ensure unit is installed in a well-ventilated, dust-free environment.

Unit is designed for indoor use only.

Keep all liquids away from the device.

Ensure environmental conditions meet factory specifications.

Ensure unit is properly secured to a subrack or shelf.

Major shocks or jolts to the unit as a result of dropping it may cause damage to the sensitive

electronics within the unit.

Use the device in conjunction with an UPS if possible.

Power down the unit before connecting and disconnecting accessories and peripherals.

Afactory recommended HDD should be used for this device.

Improper use or replacement of the battery may result in hazard of explosion. Replace with

the same or equivalent type only. Dispose of used batteries according to the instructions

provided by the battery manufacturer.

Thank you for purchasing our product. If there is any question or request, please do not hesitate

to contact dealer.

The figures in the manual are for reference only.

This manual is applicable to DS-3E0105P-E/M.

Contents

Chapter 1 Product Overview..................................................................................................1

1.1 Overview ....................................................................................................................1

1.2 Packing List................................................................................................................1

1.3 Appearance .................................................................................................................1

Chapter 2 Device Installation.................................................................................................5

2.1 Installation Notes ........................................................................................................5

2.2 Installation..................................................................................................................6

2.3 Grounding...................................................................................................................6

Chapter 3 Physical Connection..............................................................................................9

RJ45 Port Connection .......................................................................................................9

Checking ........................................................................................................................10

Power Supply..................................................................................................................10

Appendix Technical Specifications.......................................................................................11

Unmanaged PoE Switch/User Manual

Chapter 1 Product Overview

1.1 Overview

Hikvision DS-3E0105P-E/M is an unmanaged PoE switch providing 5 * 10/100 Mbps RJ45

ports. Ports 1-4 can power up devices compliant with IEEE 802.3af PoE (a maximum of 15.4 W

of each port) standard. The power output totals 35 W. In EXTEND ON mode, ports 1-4 support

up to 250 meters of data transmission and power supply.

1.2 Packing List

PoE switch * 1

Power adapter * 1

User Manual * 1

If any item is missing, or damaged, please keep the original package and contact the local

reseller or distributor immediately.

1.3 Appearance

Front Panel

See the following figure.

Unmanaged PoE Switch/User Manual

LED Indicators

Specific description of the LED indicators is shown as follows:

LED

State

Description

Power

Solid on

The switch is connected to a power supply

properly.

Off

The switch is connected to a power supply

improperly or not connected to a power

supply.

PoE

(on the upper right

corner of ports 1-4)

Solid on

The port is supplying power to the device

connected to it properly.

Off

The port is not supplying power or not

connected to a powered device.

Link/Act

(on the upper left corner

of ports 1-5)

Solid on

The port is connected properly.

Blinking

Data is being transmitted over the port.

Off

The port is connected improperly or not

connected to a device.

Link/Act LED

Power LED

PoE port

Uplink port

PoE LED

Link/Act LED

Unmanaged PoE Switch/User Manual

RJ45 Port

DS-3E0105P-E/M provides 5 * 10/100 Mbps auto-negotiation RJ45 ports. Ports 1-4 are

downlink ports compliant with IEEE 802.3af, and port 5 is the uplink port.

Note

Ports 1-2 have high priorities. Devices used for transmission of important data or playbacks of

videos are recommended to connect to these ports.

Power supply priority function of PoE ports safeguards your PoE switch in overload situation.

When the total power output of all powered devices exceeds 35 W, ports with lower priority

(port1 > port2 > port3 > port4) will have power of devices connected cut off to ensure no more

than 35 W power output.

For example, ports 1, 2 and 4 are supplying power properly with a total power output 26.2 W. If

port 3 is connected to a 9 W device, port 4 stops supplying power to the device connected to it.

Rear Panel

EXTEND mode switch

Grounding terminal

Power jack

Unmanaged PoE Switch/User Manual

EXTEND Mode Switch

State

Description

EXTEND OFF

The switch works in this mode by default. Port 1 to 4 offer a data

rate of as high as 100 Mbps.

EXTEND ON

Ports 1 to 4 offer a data rate of 10 Mbps with a transmission distance

up to 250 meters.

Note

For better performance of EXTEND ON mode, you are recommended to use Cat 5e Ethernet

cable or better and set WAN speed of the peer device to auto negotiation.

Power Jack

The power jack is used to connect the switch to a power supply using the included power

adapter.

Grounding Terminal

It is used to connect to a grounding cable for lightning protection. For details, see section 2.3

Grounding.
