Preface

Applicable Models

This manual is applicable to smart managed switches.

About Defaults

●Default administrator account: admin

●Super IP address: 10.180.190.200

Note

●The default user name admin needs to be acvated for rst-

me login.

●The default IP address of the switch is dynamically assigned.

●The super IP address cannot be modied. If the switch is

directly connected to a PC, the super IP address can be used to

access the switch for device management.

iii

Symbol Convenons

The symbols that may be found in this document are dened as

follows.

Symbol Descripon

Danger Indicates a hazardous situaon which, if not avoided,

will or could result in death or serious injury.

Cauon

Indicates a potenally hazardous situaon which, if

not avoided, could result in equipment damage, data

loss, performance degradaon, or unexpected

results.

Note Provides addional informaon to emphasize or

supplement important points of the main text.

Contents

1 Introducon ............................................................. 1

2 Acvaon and Login ................................................. 1

3 Device Informaon ................................................... 3

3.1 Device Overview ................................................... 3

3.2 Port Status ............................................................ 4

3.3 Network Status ..................................................... 5

4 Network Conguraon ............................................. 7

5 Device Conguraon ................................................ 8

5.1 Port Conguraon ................................................ 8

5.1.1 Congure Port Aributes ............................. 8

5.1.2 Congure Link Aggregaon .......................... 9

5.1.3 Congure Long-Range Mode ..................... 10

5.1.4 Congure Port Isolaon ............................. 10

5.1.5 Congure Port Mirroring ........................... 11

5.1.6 Congure High-Priority Port ...................... 12

5.2 STP Conguraon ............................................... 12

5.3 LLDP Conguraon ............................................. 14

5.4 VLAN Conguraon ............................................ 14

5.4.1 Add VLAN ................................................... 14

5.4.2 Congure Port VLAN .................................. 15

5.5 PoE Management ................................................ 16

6 System Management .............................................. 16

6.1 Time Synchronizaon .......................................... 16

6.2 System Maintenance .......................................... 17

1 Introducon

Smart managed switches support management via web,

supporng funcons such as acvaon and login, device

overview, network conguraon, device conguraon, and

system maintenance.

Note

The funcons supported vary with device models. If there are

dierences between the gures shown in this manual and the

actual interfaces of your device, the laer prevails.

2 Acvaon and Login

If you use the switch for the rst me, you need to acvate it and

congure the password.

Before You Start

Ensure that your computer and switch are on the same network

segment.

Steps

Note

All gures in this manual are for illustraon purpose only.

1. Enter the default IP address of the switch in the address bar of

a web browser, and press Enter.

Figure 2-1 Acvaon

Note

●You can obtain the default IP address of the switch using the

SADP tool.

●You are recommended to use the following web browsers:

Microso Edge 89 or later, Google Chrome 89 or later, and

Firefox 78 or later.

2. Set a password and conrm the password.

Note

The password should contain 8 to 16 characters, including at

least two types of the following categories: uppercase leers,

lowercase leers, digits, and special characters.

3. Oponal: Check Cloud Management.

The Hik-Connect service is enabled.

4. Click OK.

The network conguraon page is displayed.

5. Oponal: Modify the network conguraons.

1) Go to System → Network Conguraon → Network

Conguraon .

Figure 2-2 Network Conguraon

2) Modify the IPv4 address, IPv4 subnet mask, default IPv4

gateway, preferred DNS address, and alternate DNS address

as required, or enable DHCP for automac IP address

assignment.

Note

You are recommended to modify the network conguraons

to beer manage your switch.

3) Log in to the switch web again with the new IP address aer

modicaon.

Figure 2-3 Login

3 Device Informaon

Aer logging in to the switch web, you can obtain detailed

informaon about the switch, including the device overview

informaon, port status informaon, and network status

informaon.

3.1 Device Overview

You can view or edit the device overview informaon on the

Overview page.

Basic Device Informaon

You can view the device model, soware version, serial No., IP

address, and MAC address of the switch in the lower right corner

of the Overview page.

Figure 3-1 Basic Device Informaon

Device Name

You can view the current device name or click next to it to

customize the device name on the Overview page.

Figure 3-2 Device Name

Device Running Time

You can also view the running me of the current device in the

upper right corner of the Overview page.

Figure 3-3 Device Running Time

VLANs Added

You can quickly view the number of VLANs that have been added,

or click to go to the VLAN Management page for VLAN

conguraon.

Figure 3-4 Number of VLANs Added

Cloud Plaorm Connecon Status

Figure 3-5 Cloud Plaorm Connecon Status

The Cloud Plaorm module shows whether the device is

connected to Hik-Connect.

●If the cloud plaorm is connected, scan the QR code to add the

device to Hik-Partner Pro app for remote management.

●If the cloud plaorm is disconnected, click Refresh to

reconnect, or click Diagnose to nd out the cause of the

connecon failure and go to the cloud plaorm conguraon

page as prompted for cloud plaorm conguraon.

3.2 Port Status

The Overview page provides a visual representaon of the

physical ports and shows the connecon or power supply status

of each port, making it easier for users to manage switch ports.

Port Panel

The Port Panel module displays the connecon and power supply

status of each port. When you hover the mouse over a port, the

port name, connecon status, rate/duplex, ow control status,

and packet receiving/sending rate are displayed. If the port is a

PoE port, you can view the PoE power of the port.

Figure 3-6 Port Panel

Port Details

The Port Details module lists the status parameters of each port.

You can also congure the port status, rate/duplex, and ow

control of each port, and view the port name, connecon status,

and actual rate/duplex of each port.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HIK VISION Changer

HIK VISION

HIK VISION DS-3E0318P-E Manuel utilisateur

HIK VISION

HIK VISION 0500P Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E0509 Manuel utilisateur

HIK VISION

HIK VISION DS-3D2228P Instructions de montage

HIK VISION

HIK VISION DS-PDEB-EG2-WE Manuel utilisateur

HIK VISION

HIK VISION DS-3E05 Series Manuel utilisateur

HIK VISION

HIK VISION DS-3T1310P-SI/HS Manuel utilisateur

HIK VISION

HIK VISION DS-3TXX06HP-E Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E15 Series Manuel utilisateur

HIK VISION

HIK VISION DS-3T3512P Manuel utilisateur

HIK VISION

HIK VISION DS-3E1326P-EI Manuel utilisateur

HIK VISION

HIK VISION DS-3E0524-E Manuel utilisateur

HIK VISION

HIK VISION DS-3E0108P-E Manuel utilisateur

HIK VISION

HIK VISION DS-3E2300P-H Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E15 P Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E1 P Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E2300P Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E0105P-E Manuel utilisateur

HIK VISION

HIK VISION DS-KAD606-P Manuel utilisateur

HIK VISION

HIK VISION DS-3E2528B Manuel utilisateur

HIK VISION

HIK VISION DS-3E1510P Manuel utilisateur

HIK VISION

HIK VISION DS-3E0109P-E Manuel utilisateur

HIK VISION

HIK VISION DS-3E13XXP-SI Series Manuel utilisateur

HIK VISION

HIK VISION DS-3E1 P Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
