Module Door Staon
Quick Start Guide
Legal Informaon
Quick Start Guide
©2019 Hangzhou Hikvision Digital Technology Co., Ltd.
About this Manual
This Manual is subject to domesc and internaonal copyright protecon.
Hangzhou Hikvision Digital Technology Co., Ltd. ("Hikvision") reserves all
rights to this manual. This manual cannot be reproduced, changed,
translated, or distributed, parally or wholly, by any means, without the
prior wrien permission of Hikvision.
Please use this user manual under the guidance of professionals.
Trademarks
and other Hikvision marks are the property of
Hikvision and are registered trademarks or the subject of applicaons for
the same by Hikvision and/or its aliates. Other trademarks menoned in
this manual are the properes of their respecve owners. No right of license
is given to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION
MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL. HIKVISION DOES
NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING
THE USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR
RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF THIS
MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE WHOLLY AT YOUR
OWN RISK AND RESPONSIBILITY.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT
Module Door Staon Quick Start Guide
i
TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT
LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO
ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION
SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH
ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Module Door Staon Quick Start Guide
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note Provides addional informaon to emphasize or
supplement important points of the main text.
Module Door Staon Quick Start Guide
iii
Contents
1 Appearance ................................................................................................ 1
2 Terminal and Wiring ................................................................................... 5
2.1 Terminal Descripon ......................................................................................... 5
2.2 Door Lock Wiring ............................................................................................... 7
2.3 Door Magnec Wiring ....................................................................................... 7
2.4 Exit Buon Wiring ............................................................................................. 8
3 Installaon ................................................................................................ 10
3.1 Congure Sub Module Address ....................................................................... 10
3.2 Two-Module Installaon ................................................................................. 11
3.2.1 Two-Module Surface Mounng .............................................................. 11
3.2.2 Two-Module Flush Mounng ................................................................. 16
3.3 Three-Module Installaon .............................................................................. 20
3.3.1 Three-Module Surface Installaon ......................................................... 20
3.3.2 Three-Module Flush Mounng ............................................................... 26
3.4 More-Than-Three Module Installaon ............................................................ 30
3.4.1 More-Than-Three Module Surface Mounng ........................................ 30
3.4.2 More-Than-Three Module Flush Mounng ............................................ 36
4 Remote Operaon .................................................................................... 44
4.1 Acvate Device ................................................................................................ 44
4.2 Edit Network Parameters ................................................................................ 45
4.3 Add Device ...................................................................................................... 46
4.4 Call Resident .................................................................................................... 47
Module Door Staon Quick Start Guide
iv
1 Appearance
Main Unit
Figure 1-1 Main Unit Appearance
Table 1-1 Appearance Descripon
No. Descripon
1 Microphone
2 Low Illuminaon IR Supplement Light
3 Built-in Camera
4 Loudspeaker
5 Call Buon
6 Nametag
7 TAMPER
8 Network Interface
9Module-Connecng Interface (output)
10 Terminals
Module Door Staon Quick Start Guide
1
Note
•Nametag area supports insert customized name card. The suggested
card size is: 58 (L) x 11.7(W) mm.
•The module connecng interface is used to connect other funcon
module, such as nametag module, keypad module, card reader module,
etc. All these modules are known as sub module.
Nametag Module
Figure 1-2 Nametag Module Appearance
Table 1-2 Appearance Descripon
No. Descripon
1 Call Buon
2 Nametag
3Module-Connecng Interface (output)
4Module-Connecng Interface (input)
5 Debug Port
Module Door Staon Quick Start Guide
2
Keypad Module
Figure 1-3 Keypad Module Appearance
Table 1-3 Appearance Descripon
No. Descripon
1Buon
2Module-Connecng Interface (output)
3Module-Connecng Interface (input)
4 Debug Port
Card Reader Module
Figure 1-4 Card Reader Module
Module Door Staon Quick Start Guide
3
Table 1-4 Appearance Descripon
No. Descripon
1 Card Reading Area
2Module-connecng Interface (output)
3Module-connecng Interface(input)
4 Debug Port
Module Door Staon Quick Start Guide
4
