HiBoost Mate Plus Series Manuel utilisateur
Boost Your Bars
User Manual
Mate Plus Series
4K Mate Plus
4K Mate Plus Pro
10K Mate Plus
10K Mate Plus Pro
（F10GTI-5S-IOT）
（F10GTI-5S-IOT.Pro）
（F15GTI-5S-IOT）
（F15GTI-5S-IOT.Pro）
Package Content
Introduction
Pre-Installation Instructions
light pattern
APP Assisted Installation
LCD Assisted Installation
Quick Troubleshooting Guide
Technical Specications
Authorized Accessories List
FCC and IC Statements
Return and Warranty Policies
01
03
04
12
13
29
43
46
47
48
51
CONTENTS
01
Package Content
HIBoost 4K/10K Mate Plus
Outdoor Antenna Outdoor Cable
49.2ft NM-SMAM SMA-Male to SMA-Female
(No drilled hole)
are all provided to protect connetctions
Outdoor Cable to Booster
16.4ft SMAF-SMAM
Booster Power Supply
Accessories for main parts Waterproof tape
Through-Window Cable
02
Package Content
NOTE: Available accessories can be purchased through HiBoost.com
Warning: Un-authorized antennas, cables, and/or coupling devices are prohibited by new FCC
rules. Please contact FCC for details: 1(888)-CALL-FCC
HiBoost 4K/10K Mate Plus Pro
Outdoor Cable to Booster
16.4ft SMAF-SMAM
Booster
Power Supply
are all provided to protect connetctions
Accessories for main parts Waterproof tape
Outdoor Antenna Outdoor Cable
49.2ft NM-SMAM
Indoor AntennaIndoor Cable
30ft NM-SMAM
SMA-Male to SMA-Female
(No drilled hole)
Through-Window Cable
03
Introduction
Thanks again for purchasing HiBoost cell Booster. The HiBoost Mate Plus/Pro series is a collection of
precision-engineered products that improve cellular reception inside of homes and businesses by
amplifying incoming and outgoing cell phone signals.
Both HiBoost Mate Plus and Mate Plus Pro have built-in antennas, so both can directly receive and send
signals through boosters. But Plus Pro has one more indoor antenna to facilitate the need to cover more
rooms.
HiBoost Mate Plus/Pro exclusive cloud-based Signal Supervisor mobile application and LCD display allow
users to monitor the live status of HiBoost Mate Plus/Pro cell phone signal boosters directly from the LCD
display or remotely from a mobile device anywhere at any time.
If there are any issues while installing a HiBoost Mate Plus/Pro cell phone signal booster, please contact
the HiBoost technical support team through the following options:
Online Support: Create a ticket or chat via Signal Supervisor App
(972) 870-5666 (M-F from 9 am – 5 pm CST)
www.hiboost.com
04
We strongly recommend you to read the user guide completely before beginning the
installation.
HiBoost 4K/10K Mate Plus/Plus Pro provide 2 options of booster installation,
APP and LCD installation ways are unique methods provided by HiBoost
1. App assisted installation,
FIRST CHOICE From Page 13~28.
It’s more convenient and many work could be done by ONE person,
and the most important is that the obtained signal can be very precise.
2. LCD assisted installation,
SECOND CHOICE From Page 29~42.
It can achieve the same precise eect as App guidance.
But it may need two people and the installation process is a little
cumbersome.
Touchable LCD meter tells how
strong the signal is
Pre-Installation Instructions
The App helps you nd the
best signal outside
05
Then why has HiBoost spent extra big eorts and costs to design APP and LCD signal
meters to help you install?
Out of the various reasons, the most important reason is that we would like you, our valuable client, to get
the maximum output power from the booster system in order to get optimal signal reception for all your
mobile devices.
As it is known and a big thanks, FCC makes signal boosters legal in 2014 so that every body can install
and benet from the signals;
But FCC regulations do limit the gain and output power of all consumer boosters to low values in
order to avoid any interference to the cell towers;
Furthermore FCC stipulates that any improper install should trigger immediately further reduction of
the booster’s already-limited gain and power to protect the towers.
Therefore, you can understand how important you need to nd the perfect outside signal from the
tower and how important to squeeze every last gain and power from the booster, even 1dB more
power is so precious when you suer from no signals.
HiBoost App & LCD signal meters will help you to ne tune the best power and get
as much cover of your spaces.
06
General Working Principle:
※Please do spend sometime to read it fully, as it is crucial to get full bars for your rooms.
Before we start any of the two ways, please allow us to spend 3 pages to make you
understand how the booster system works for you.
How HiBoost Booster works
1. Outdoor antenna receives
outside signal from the nearby
cell tower and sends it to
HiBoost Booster
2. The booster amplifies the
signal and sends to indoor
antenna(s);
3. Indoor antenna(s) receive
amplified signal and send it
throughout your rooms
Vice versa,booster(plus)/indoor antenna receices cellphone signal and sends to the booster
The booster then amplies the signal and sends it to outdoor antenna
Outdoor antenna sends signal to the cell tower
Then you can make phone calls and internet streaming.
07
Noted: applicable to 4K Mate Plus and 10K Mate Plus
Noted: applicable to 4K Mate Plus Pro and 10K Mate Plus Pro; Or 4K Mate Plus and
10K Mate Plus with purchased secondary indoor antenna.
08
Noted: applicable to 4K Mate Plus Pro and 10K Mate Plus Pro;when 3 indoor
antenna is added.
