Lighted Wireless

Push Button Accessory

The Heath®/Zenith Wireless Push Button Accessory works with existing

Heath®/Zenith jumper or dip switch systems.

• Battery powered push button - No wires to run.

• 128 selectable codes allow more than one chime system in the same

house.

• LED lighted push bar (see Lighted Push Bar Feature).

(Style may vary from illustration)

Lighted Push Bar Feature

This Heath®/Zenith wireless push button contains a LED (Light Emitting

Diode) that will illuminate in dark conditions so the push button will be

more visible for your guests.This (patent pending) technology and built-in

photocontrol will allow the light intensity of the push button LED to in-

crease as the outdoor light conditions around the push button decreases.

The actual time and intensity that the LED is visible will depend on the

speciﬁc mounting environment of the push button. In nominal conditions

the batteries will typically last 2 years.

-2- 598-1137-02

1. Install two lithium type CR2032 3 volt bat-

teries (included). Remove back of case by

pushing in tab on bottom with a small screw-

driver. Make sure battery is oriented properly

(see page 5).

2. Set the push button jumpers to match the

chime receiver code. See “Code and Tune Setting” section.

3. Test range. Temporarily position push button where you want it

mounted. Press push button to verify chime and push button work

properly. If chime does not sound, see Troubleshooting.

4. Mount push button. Use either screws or double sided tape to mount

push button.

• To mount with screws, remove back of case by pushing in tab on

bottom with a small screwdriver. Attach back of case to door jamb

or wall. Snap front of push button on.

• When attaching push button using double sided tape, make sure

the surface of the door jamb or wall is clean.

-3-

598-1137-02

Code and Tune Settings

Code Settings

Note: Most installations will not require you to change any

jumpers on your chime and push button.

WARNING: Disconnect chime unit from power source before

opening code access door. Close door and replace screw

before reconnecting to power.

The push button and chime communicate by using a code that can be

changed by removing and/or adding jumpers on both the push button and

chime. The code is factory set; however, there are 128 selectable codes

that allow you to expand your system and prevent outside interference.

Other wireless products may cause interference and the system may not

function properly. Follow the instructions below for setting a new code.

1. Unplug wireless chime (if applicable).

2. Open the cases and locate the jumpers on both the push button and

chime (See illustration on page 5).

3. The push button and chime both have eight different jumper locations.

The jumper positions 1 through 7 are used for setting the code.

4. To change the code, add and/or remove jumpers as needed. It is

recommended to only change one jumper at a time and then check

to see if system is functioning properly. Note: Jumpers in positions

1 through 7 must be exactly the same for both the push button and

chime for this system to function.

-4- 598-1137-02

Tune Settings

Your Heath®/Zenith wireless chime has different selectable tunes: Ding

(one note), Ding-Dong (two note), or Westminster (eight note) (Available

on selected Heath®/Zenith chimes). The factory setting is for the Ding-

Dong tune (or Westminster, when available). This tune can be changed

by following the instructions below.

• Ding (one note tune)

Push button: Add a jumper to location 8.

• Ding-Dong (two note tune)

Push button: Remove jumper from location 8.

Chime: Remove jumper from location 8.

• Westminster (Eight note tune) (Available on selected Heath®/Zenith

chimes)

Push button: Remove jumper from location 8.

Chime: Add a jumper to location 8.

Note: All models have both front and back door tune capabilities.You may

purchase any Heath®/Zenith wireless push button for a second entrance.

We recommend the back door use the Ding tune and the front door

use the Ding-Dong tune (or Westminster tune, available on selected

Heath®/Zenith chimes). Models that include two push buttons will come

factory set for front and back doors. Decals on the rear of the push button

will indicate its setting.

-5-

598-1137-02

12345678

Inside Push

Button

Replacing Push Button Batteries

Install two lithium type CR2032 3 volt batteries.

Insert Batteries (+) Positive Side Up.

* Code Settings 1-7

Must Match Both

Push Button and

Chime

Remove screw to

open access door

Tune Setting (Not used on

all models)

Back of

Chime

Tune Setting

Note: Some models might require the use of

tweezers to remove and replace the jumpers.

-6- 598-1137-02

Troubleshooting

Chime does not sound:

• Make sure push button and chime codes are the same (See pages 3,

4, and 5).

• Check orientation of push button battery (See page 5).

• Check charge of push button and chime batteries (if applicable), replace

if necessary.

Batteries seem OK, but the chime does not work when installed:

• Do not mount chime or push button on metal or near metal studs.This

reduces the transmitter range. Use 1/4" to 1/2" (6 to 13 mm) wood

shims to move chime or push button off metal surface.

• Concrete ﬂoors may reduce range. Move chime away from ﬂoor.

• Try locating chime closer to push button.

Push button light (LED) is “ON” or “OFF” all the time (see page 1).

The range of the wireless chime can vary with location, temperature and

battery condition.

-7-

598-1137-02

Regulatory Information

This device complies with Part 15 of the FCC Rules and RSS-210 of

Industry Canada. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause

undesired operation.

The user is cautioned that changes or modiﬁcations not expressly ap-

proved by the party responsible for regulatory compliance could void the

user’s authority to operate the equipment.

Technical Service

Please call 1-800-858-8501 (English speaking only)

for assistance before returning product to store.

If you experience a problem, follow this guide.You may also want to visit

our Web site at: www.hzsupport.com. If the problem persists, call* for

assistance at 1-800-858-8501, 7:30 AM to 4:30 PM CST (M-F).You may

also write* to:

HeathCo LLC

P.O. Box 90004, Bowling Green, KY 42102-9004

ATTN: Technical Service

* If contacting Technical Service, please have the following information

available: Model Number, Date of Purchase, and Place of Purchase.

No Service Parts Available for this Product

-8- 598-1137-02

FIVE YEAR LIMITED WARRANTY

This is a “Limited Warranty” which gives you speciﬁc legal rights. You may also

have other rights which vary from state to state or province to province.

For a period of ﬁve years from the date of purchase, any malfunction caused by

factory defective parts or workmanship will be corrected at no charge to you.

Not Covered - Repair service, adjustment and calibration due to misuse,

abuse or negligence, light bulbs, batteries, and other expendable items are not

covered by this warranty.Unauthorized service or modiﬁcation of the product or

of any furnished component will void this warranty in its entirety.This warranty

does not include reimbursement for inconvenience, installation, setup time,

loss of use, unauthorized service, or return shipping charges.

This warranty covers only HeathCo LLC assembled products and is not

extended to other equipment and components that a customer uses in con-

junction with our products.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY, REPRESENTATION

OR CONDITION OF MERCHANT ABILITY OR THAT THE PRODUCTS ARE FIT

FOR ANY PARTICULAR PURPOSE OR USE, AND SPECIFICALLY IN LIEU OF

ALL SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

REPAIR OR REPLACEMENT SHALL BETHE SOLE REMEDY OF THE CUS-

TOMER ANDTHERE SHALL BE NO LIABILITY ONTHE PART OF HEATHCO

LLC FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL

DAMAGES, INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS

OR PROFITS, WHETHER OR NOT FORESEEABLE. Some states or prov-

inces do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation or exclusion may not apply to you. Please

keep your dated sales receipt, it is required for all warranty requests.

HeathCo LLC reserves the right to discontinue and to change speci-

ﬁcations at any time without notice without incurring any obligation to

incorporate new features in previously sold products.

-9-

598-1137-02

Accesorio de pulsador

inalámbrico

El accesorio de pulsador inalámbrico Heath®/Zenith funciona con el

puente Heath®/Zenith o con los sistemas de interruptores.

• Pulsador alimentado con pila – No se necesitan alambres.

• Los 128 códigos elegibles permiten más de un sistema de campanas

en la misma casa.

• Barra de empuje iluminada con LED (Vea Característica barra de

empuje iluminada).

(El estilo puede variar de la ilustración)

Característica barra de empuje iluminada

Este pulsador inalámbrico Heath®/Zenith tiene un LED (Diodo Emisor de

Luz) que se iluminará en condiciones de oscuridad para que el pulsador

sea más visible por sus invitados. Esta tecnología (patente en trámite)

y el fotocontrol incorporado permitirán a la intensidad de luz del LED

del pulsador aumentar a medida que las condiciones exteriores de luz

alrededor del pulsador disminuyan. El tiempo y la intensidad real que el

LED es visible dependerán del entorno especíﬁco en el que se instaló

el pulsador. En condiciones nominales las baterías durarán típicamente

dos años.

-10- 598-1137-02

1. Instale las dos baterías(pilas) de litio tipo

CR2032 de 3 voltios del pulsador (inclui-

das). Extraer la parte posterior de la caja

presionando la aleta en el botón con un destor-

nillador pequeño. Asegurarse que la pila esté

orientada correctamente (ver la página 13).

2. Fije los puentes del pulsador de acuerdo al código del receptor

de campana. Vea la sección de “Programaciones del código y del

tono”.

3. Pruebe el alcance. Ponga provisionalmente el pulsador en la posición

donde lo quiera instalar. Presione el pulsador para veriﬁcar que la

campanay el pulsador funcionen apropiadamente. Si la campana no

suena, vea Análisis de Averías.

4. Instale el pulsador. Use ya sean tornillos o cinta adhesiva por ambas

caras para instalar el pulsador.

• Para montar con tornillos, quite la parte de atrás de la caja em-

pujando hacia adentro la lengüeta de abajo con un destornillador

pequeño y girando la cuchilla. Coloque la parte de atrás de la caja

contra la jamba o la pared. Encaje a presión la parte frontal del

pulsador.

• Cuando ﬁje el pulsador usando cinta adhesiva por ambas caras,

asegúrese que la superﬁcie de la pared o la del batiente de la puerta

estén limpias.

Table des matières

Langues :

Autres manuels Heath Zenith Accessoires

Heath Zenith

Heath Zenith Wireless Christmas Chime 598-1127-03 Manuel utilisateur

Heath Zenith

Heath Zenith Wireless Mechanical Chime 598-1123-02 Manuel utilisateur

Heath Zenith

Heath Zenith DUAL BRITE SL-5597 Manuel utilisateur

Heath Zenith

Heath Zenith Replacement Motion Sensor SL-5407 Manuel utilisateur

Heath Zenith

Heath Zenith Wireless Chime TR-0095-RX Manuel utilisateur

Heath Zenith

Heath Zenith Notifi Elite Manuel utilisateur

Heath Zenith

Heath Zenith SL-7464-03 Manuel utilisateur

Heath Zenith

Heath Zenith 5316 Manuel utilisateur

Heath Zenith

Heath Zenith SECUR360 9600 Manuel utilisateur

Heath Zenith

Heath Zenith Wireless Chime 598-1172-04 Manuel utilisateur

Heath Zenith

Heath Zenith 6168 Manuel utilisateur

Heath Zenith

Heath Zenith SL-6166 Manuel utilisateur

Heath Zenith

Heath Zenith notifi alert Manuel utilisateur

Heath Zenith

Heath Zenith Wireless Push Button Accessory 598-1105-05 Manuel utilisateur

Heath Zenith

Heath Zenith Hardwired Electronic Chime 598-1313-00 Manuel utilisateur

Heath Zenith

Heath Zenith Motion Sensing 3-Way Wall Switch 6107 Manuel utilisateur

Heath Zenith

Heath Zenith Decorative Wireless Chime 6180 Manuel utilisateur

Heath Zenith

Heath Zenith 598-1143-01 Manuel utilisateur

Heath Zenith

Heath Zenith 598-1112-04 Manuel utilisateur

Heath Zenith

Heath Zenith 7776 Manuel utilisateur

Heath Zenith

Heath Zenith DualBrite 5716 Manuel utilisateur

Heath Zenith

Heath Zenith 7143 Manuel utilisateur

Heath Zenith

Heath Zenith Wireless Mechanical Battery Operated Chime... Manuel utilisateur

Heath Zenith

Heath Zenith 6180 Series Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
