Harman JBL Wind 2 Manuel utilisateur

Owner´s manual

Manual do proprietário

Manual del propiet

rio

Руководство пользователя Руководство пользователя Руководство пользователя Руководство пользователя

Руководство пользователя

Product Overview

Congratulations for purchase of WIND 2! To ensure a proper use of WIND

please read this manual before you start to use. Also, please safely keep

this manual for future reference and trouble shooting.

Package Contents

1x WIND 2

1x USB charging cable

1x Aux cable

1x Carabiner

1x Bracket

1x User's manual

1x Rubber mount

Compatibility

The product is compatible with BT enabled devices, including

I phone,

Pad, I

Pod, Android Phone, tablets and etc. It is also compatible with

devices which have 3.5mm earphone jack to connect to the product.

Features

•

Wireless

and To-Go

Easy connection with your electronic devices wirelessly and use it portably.

The wireless working range is around 8-10 meters

(30 feet), no cords

and

no hassle.

•

Hand free calling on-the-go

With a built-in microphone, the unit takes on your calls just free and easy.

•

2-in-1 design for use in bicycle and backpack

(1) Handle for hanging a carabiner

(2) Play/pause (BT, aux and micro SD / TF), FM Scan and Mute (Radio)

(3) Volume + ( Long press ) - All functions

(4) Volume –( Long press ) - All functions

(5) "ON / OFF" and "Source" button (BT, aux, micro SD TF and radio)

(6) Connection for USB charging

(7) Headphone output

(8) Micro SD / TF Card

(9) AUX input

(10) LED battery charge indicator

•

Carabiner and bicycle bar mounter with bracket are provided for two uses

in carrying it over.

Product Interface

Next (Short press) - BT, micro SD / TF and radio functions

Lap (Short press) - BT, micro SD / TF and radio functions

Bluetooth connection LED indicator

(11)

12 13

Microphone

(12)

Display

(13)

Getting Started

Two easy steps to get your JBL WIND 2 ready to enjoy.

Step 1: Charging before use

Connect your WIND 2 BT Speaker to a USB power source

using the enclosed

USB charging cable.

Step 2: Connecting to play

•

Bluetooth connection

•

Direct Connection

As soon as the portable WIND 2 box is turned on, the BT indicator will blink and

signal to confirm that the unit is currently in BT pairing mode. Access the BT

settings on your phone, tablet or computer to locate the device called "JBL

WIND 2" and press to select. A signal will be issued to confirm that the device

has been satisfactorily paired in seconds. The next time you use the WIND 2

device, the product will automatically connect to your devices once pairing

has been performed. To disconnect the device, press the "Play / Pause"

button for 5 seconds and it will start pairing a new available device.

OBS.: This process needs to be performed only on first use.

region as soon as your radio is ready for use.

press the "Play / Pause" button up to start scanning th FM radios of your

When you turn on your JBL WIND 2 for the first time, after playing the radio,

Click the "+" and "-" buttons to advance and return the radios respectively.

beep, it will start playing the FM radio.

As soon as WIND 2 is turned on, press the source select button again, after the

•

FM Radio connection

The WIND 2 Portable Box can also connect to devices that have a handset

output or a line-out using the AUX cable shipped with the device.

•

Micro SD / TF card

Play your music through a micro SD / TF card. Click the "source" button to

switch between signal inputs.

Speaker Phone

After paired your mobile phone to

WIND 2 with BT, the speaker phone function

can be used.

•

Make call: Call will automatically transfer to the speakerphone. If not, tap

play/pause button;

•

Answer call: Tap play/pause button to answer the incoming call;

•

End call: Tap play/pause button during the call to end the call;

•

Reject call: Hold play/pause button to reject the incoming call;

•

Redial last number: Double tap

play/pause button to redial last number

when it is not in a call.

Charge

When the power is low, a beep will comes out from

the speaker, please charge

the speaker when you hear the beep.

Connect the standard USB end of the supplied USB cable to a USB power

source (like PC, USB power adapter…etc.);

Connect the Micro USB jack to the USB charging port in the unit. The charging

indicator will light up while charging;

It will take about 2

hours to

fully charge the BT speaker;

The

LED indicator will stay on while charging, and goes off after fully charged.

Note: if the unit is not used longer than 7 days, please charge

the unit

for 10 minutes before turn on the unit.

Connection

Laptop / notebook / PC

As the BT versions for these types of devices vary greatly, the connection methods

will differ as well. If you cannot connect with the WIND 2 BT Speaker using the previous

method instructed, you may need to install a new version of the BT driver.

Please refer the instructions of device for details.

Technical parameters

Note: All specifications are subject to change without notice.

Product name: Wind 2

Power Supply: USB 5V, 1A

Built-in Lithium Ion battery: 3.7V

0mAh

Output power: 5W RMS

BT Profile Supported: A2DP, AVRCP

BT Version: 4.2

Working range: up to 10m

Working atmosphere: 0°C 40°C / 20% 90% RH

Memory card capacity: 64GB

SPL Max: 80dB

IPX7 (OBS.: To ensure that JBLWIND2 is waterproof, please remove

all cable connections and tightly close the cap; exposing the

JBLWIND2 to liquids without doing so may result permanent

damage to the

speaker or power source.

IPX7 waterproof is defined as the speaker can be immersed in

water up to 1m for up to 30 minutes.)

Maintenance

Please follow the

instructions below before cleaning the unit:

•

Power off the unit first before clear

•

Use a soft, dry, lint-free cloth to wipe gently

•

Do not use alcohol, benzene, thinners or other chemical detergents as

these can cause the casing to be warped or discolored

Storage

•

If the unit will not be used for an extended period of time, power off the

unit and place the unit with accessories into the package

•

Do not set the unit in a damp, high temperature or a sun point-blank

place

•

Check for other BT devices around the surroundings that may interfere

with searching and turn

devices off.

•

Power off and then power on the unit to restart the BT function of the unit

or your BT device.

•

Unplug any cables plugged into the AUX IN, restart all devices and then

attempt pairing again.

Issue: Interference or static during playback

Solution:

•

Avoid using the device

between

concrete

other

building

structures

that may interfere with the signal.

•

Please check if the battery level of the unit and the BT device

and charge if necessary.

Issue: Radios are not working well.

Solution:

•

Check that the radios have been scanned according to instructions on page 4

Safety Instructions

This product is specially designed based on the full attention to safety; in

order to make sure the accident

ree operation, please abide by

the guidelines

listed below:

•

Always position the unit on a stable and level surface. Unstable surface can

cause the unit to topple and fall, resulting in possible damage or injury;

Solution:

successfully after multiple attemptsIssue: Pairing is un

Troubleshooting

•

Check if the BT indicator light is on. If the indicator light is off, please press

the power button to turn the unit on. If the BT indicator light still doesn't come

on after pressing the power button, please charge the unit.

•

Regardless

what

reasons

cause

the

unit

damage,

have the repair

performed only by on authorized JBL dealer or service center;

•

If you want to do the cleaning, please

turn off the unit and unplug the power

cable from the outlet first;

•

Set the volume properly to prevent injury to the unit and your health;

Correct Disposal of this product. This marking indicates that this product

should not be disposed with other household wastes throughout the EU.

To prevent possible harm to the environment or human health from

uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources. To return your used device, please

use the return and collection systems or contact the retailer where the

product was purchased. They can take this product for environmental safe

recycling.

WARNING:

•

The battery (battery or batteries or battery pack) shall not be exposed to

excessive heat such as sunshine, fire or the like.

•

No naked flame sources, such as lighted candles, should be placed on

the apparatus.

•

Do not drop, unpack, open, beat,curve, prink and burn the unit;

•

Avoid using the unit nearby basins or sinks where it may come in

contact with water;

•

Do not place any ware with full water on the top of the unit, such as vase,

glass, pot, and please avoid placing candle on the speaker surface as well;

•

Protect the using of the unit from any overheating devices (such as radiator,

heating installation, cooking stove or other heating devices);

Warning:

WIND 2 is designed as multipurpose speaker which includes common

and casual use on a bicycle as an entertaining device. We are not liable to risk

in using WIND 2 while you ride on a bicycle for speed racing, BMX performance,

down hill riding, jumping and etc. Please always use WIND 2 on a bike in a manner

of safe riding.

Descrição Geral do Produto

Parabéns

pela

compra

caixa

portátil

WIND

para

acoplagens

múltiplas.

Para

garantir

uso

adequado

equipamento,

leia

cuidadosamente

este

manual

antes

começar

utilizá-lo.

Além

disso,

guarde

bem

este

manual

para

uma

futura

consulta

para

solucionar

problemas.

Conteúdo da embalagem

1. 1 x WIND 2

2. 1 x Cabo USB para carregamento

3. 1 x Cabo auxiliar

4. 1 x Mosquetão

5. 1 x Suporte

6. 1 x Manual do usuário

Compatibilidade

O produto é compatível com dispositivos habilitados para conexão sem fio

BT, incluindo iPhone, iPad, iPod, Android Phone, tablets etc. Também é

compatível com dispositivos que têm uma saída de fone de ouvido de

3,5mm(P2) para conectar ao produto e cartões micro SD/TF.

Características

• Wireless e To-Go

Fácil conexão com seus dispositivos eletrônicos sem fio e para uso portátil. A

faixa funcional de alcance sem fio é de aproximadamente 8 a 10 metros

sem cabos e sem complicações.

• Ligação (on-the-go) sem as mãos

Com um microfone integrado, a unidade realiza suas chamadas de forma livre

e fácil.

• Design 2-em-1 para utilizar na bicicleta, moto, mochila e onde mais quiser

São fornecidos um mosquetão e um suporte para múltiplas acoplagens.

7. 1 x Manta borracha

Table des matières

Langues :

Autres manuels Harman Intervenants

Harman

Harman harman/kardon CITATION SURROUND Manuel utilisateur

Harman

Harman JBL XTREME 4 Manuel utilisateur

Harman

Harman Harman/Kardon Allure Manuel d'instructions

Harman

Harman Harman/kardon OMNI 10+ Manuel utilisateur

Harman

Harman JBL VERTEC DP Series Fiche technique

Harman

Harman JBL PARTYBOX 1000 Manuel utilisateur

Harman

Harman JBL LINKPORTABLE Manuel utilisateur

Harman

Harman Harman/Kardon ONYX STUDIO 5 Manuel utilisateur

Harman

Harman JBL PULSE2 Manuel utilisateur

Harman

Harman JBL 7 Series Manuel utilisateur

Harman

Harman JBL CINEMA SB200 Manuel utilisateur

Harman

Harman JBL NightLife Series Manuel utilisateur

Harman

Harman JBL ARENA Series Manuel utilisateur

Harman

Harman Axys ABF-260/100W PA6 V0 Low Profile Manuel utilisateur

Harman

Harman JBL PROFESSIONAL EON ONE MK2 Manuel utilisateur

Harman

Harman JBL S4700 Manuel utilisateur

Harman

Harman JBL GO2+ Manuel utilisateur

Harman

Harman JBL BOOMBOX3 Manuel utilisateur

Harman

Harman JBL Professional EON ONE Compact Manuel utilisateur

Harman

Harman JBL PARTYBOX110 Manuel utilisateur

Harman

Harman JBL VerTec VT4889ADP Fiche technique

Harman

Harman kardon Citation 200 Manuel utilisateur

Harman

Harman JBL SU Center Manuel utilisateur

Harman

Harman JBL Stage 2 Series Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
