Physical input / output ports
Source devices connect to input ports and Target devices connect to output ports. The physical port
con gura on is independent to the transla on.
The types of port used may be independent or the same, bu ering is used to process commends where the
speeds of the interface vary.
Input Output
Serial Serial
Serial IP
IP Serial
IP IP
Serial Ports
Supported serial speeds are 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
Supported line control op ons are;
8N1 8 bits, no parity, 1 stop bit
8N2 8 bits, no parity, 2 stop bits
8E1 8 bits, even parity, 1 stop bit
8E2 8 bits, even parity, 2 stop bits
8O1 8 bits, odd parity, 1 stop bit
8O2 8 bits, odd parity, 2 stop bits
9N1 9 bits, no parity, 1 stop bit
9N2 9 bits, no parity, 2 stop bits
Serial interfaces may have hardware ow control enabled.
NOTE When serial data is received or transmi ed, the associated input/output LED will blink green.
IP Ports (Ethernet)
Source devices connect to the cmdBridge IP address and a speci ed port number, using the command.
cmdBridge will connect to a Target device IP address and port, using the command;
output
ip
add
<x.x.x.x>
<port>
NOTE When IP data is received or transmi ed, the associated input/output LED will blink blue.
NOTE When IP data is transmi ed, but a connec on to the target device is unavailable, the associated
output LED will blink red.
