Harbor Breeze PLM52CB5D Manuel utilisateur

ITEM #0295011

BAJA CEILING FAN

Questions, problems, missing parts? Before returning to your retailer, call or contact our customer

service department at 1-800-527-1292, 8:30 a.m.- 5:00 p.m., CST, Monday - Friday.

Harbor Breeze® is a registered trademark

Español p. 17

ATTACH YOUR RECEIPT HERE

Serial Number Purchase Date

MODEL #PLM52CB5D

E206035

FOR DAMP LOCATIONS

TABLE OF CONTENTS

Safety Information ………………………………………………………...……..…...............2 - 3

Package Contents ……………………………………………………..……..…..…..................4

Hardware Contents ..................

....

........................................................................................

.........

Preparation ....….…………………..……………………….…………….……………............5

Initial Installation .........……………………...………………………………………

….

......6 - 7

Normal or Angle Style Fan Mounting .......……………………………………………………........7 - 8

Wiring ....................…………………….............................................………

…..

............9 - 10

Final Installation …………….……………………….…………….……..............

.…..

..........10 - 12

Operation Instructions ..............................…………………………....................................13

Care and Maintenance ……………………………………………………………..……………........14

Troubleshooting .....………...………………………….……………..……

….

...

…...

...................14

Warranty ……………………………….…………………………………………..…..................15

Replacement Parts List .......................................................................................................

....

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

Please read and understand this entire manual before attempting to assemble, install or operate the

product. If you have any questions regarding the product, please call customer service at

1-800-527-1292, 8:30 a.m. - 5:00 p.m., CST, Monday - Friday.

• Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for

repairs, it must be shipped in its original packaging to ensure proper protection against damage that

might exceed the initial cause for return.

• Make sure that all electrical connections comply with local codes, ordinances, the National Electrical

Code and ANSI/NFPA70-1999. Hire a qualified electrician or consult a do-it-yourself wiring handbook,

available at Lowe's, if you are unfamiliar with installing electrical wiring.

• Make sure the installation site you choose allows a minimum clearance of 7 feet from the blades to

the floor and at least 30 in. from the end of the blades to any obstruction.

• After you install the fan, make sure that all connections are secure to prevent the fan from falling.

• The net weight of this fan is: 22.05 lbs. (10 kg).

To reduce the risk of fire, electrical shock, or personal injury, mount fan to an outlet box

marked "ACCEPTABLE FOR FAN SUPPORT" and use mounting screws provided with

the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are

not acceptable for fan support and may need to be replaced. Consult a qualified electrician if in

doubt. Secure the outlet box directly to the building structure. The outlet box and its support must

be able to support the moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.

To avoid personal injury, the use of gloves may be necessary while handling fan parts with

sharp edges.

To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this

fan are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your

house wire is larger than 12 gauge or there is more than one house wire to connect to the two fan

lead wires, consult an electrician for the proper size wire connectors to use.

To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed

control device or control fan speed with a full range dimmer switch.

To reduce the risk of fire, electrical shock, or personal injury, do not bend the blade arms when

installing them, balancing the blades, or cleaning the fan. Do not insert objects between the

rotating fan blades.

To reduce the risk of personal injury, use only parts provided with this fan. The use of parts

OTHER than those provided with this fan will void the warranty.

WARNINGS

CAUTIONS

Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid

electrical shock.

Read all instructions and safety information before installing your new fan. Review the

accompanying assembly diagrams.

SAFETY INFORMATION

DANGER

If using this fan in a DAMP location, this fan must be connected to a supply circuit that is protected

by a Ground Fault Circuit Interrupter (GFCI) to reduce the risk of personal injury, electrical shock

or death.

IMPORTANT REMINDER: You must

use the parts provided with this fan for

proper installation and safety.

PART DESCRIPTION QUANTITY

Motor Screw 10

(preassembled)

Lock Washer 10

(preassembled)

Canopy Mounting Screw 2

(preassembled)

Pin (preassembled) 1

Clip (preassembled) 1

O Pull Chain Extension 1

P Blade Arm 5

Q Blade Arm Screw 15

(preassembled)

PART DESCRIPTION QUANTITY

Downrod

Canopy 1

Mounting Bracket

Motor Housing

E Switch Housing 1

F Yoke Cover

G* Plastic Locking Mechanism

Blade

I Canopy Cover 1

*US Pat. No. 7351037

PACKAGE CONTENTS

HARDWARE CONTENTS (shown actual size)

E3 Wire

Connector

Qty. 4

Before beginning assembly and installation of product, make sure all parts are present. Compare

parts with package contents list and hardware contents above. If any part is missing or

damaged, do not attempt to assemble, the product. Contact customer service for replacement parts.

Estimated Assembly Time: 120 minutes

Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety

Glasses, Stepladder and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape Measure, Do-It-Yourself Wiring Handbook

(available at Lowe’s) and Wire Cutters

DANGER: When using an existing outlet box, make sure the outlet box is securely attached to

the building structure and can support the full weight of the fan. Failure to do this can result in serious

injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan

after installation is complete.

CAUTION: Be sure outlet box is properly grounded and that a ground wire (green or bare) is

present.

After opening top of carton, remove mounting hardware package from foam inserts. Remove motor

from packing and place on carpet or on foam to avoid damage to ﬁnish.

CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that they

are secured.

PREPARATION

INITIAL INSTALLATION

OFF

Turn off circuit breakers and wall switch to the fan

supply line leads. (Fig. 1)

DANGER: Failure to disconnect power supply

prior to installation may result in serious injury or

death.

Determine mounting method to use. (Fig. 2)

A. Normal mount

B. Angle mount

Important: If using the angle mount, check to

make sure the ceiling angle is not steeper than 19°.

2. 2

Check to make sure blades (H) are at least 30 in.

from any obstruction. Check downrod (A) length to

ensure blades (H) are at least 7 ft. above the floor.

(Fig. 3)

Secure mounting bracket (C) to outlet box using

screws, spring washers, and flat washers

provided with the outlet box. (Fig. 4)

*NOTE: It is very important that you use the

proper hardware when installing the mounting

bracket (C) as this will support the fan.

IMPORTANT: If using the angle mount, make

sure open end of mounting bracket (C) is installed

facing the higher point of the ceiling.

7 ft.

min.

30 in.

min.

Slip downrod (A) into housing yoke, align holes and

re-install pin (M) and clip (N). Tighten downrod set

screws and then tighten nuts. Slide yoke cover (F)

down until it rests on top of motor housing (D). (Fig. 3)

Choose downrod (A) length you wish to use.* If you

choose to use the 12 in. downrod (A), remove

hanging ball from the 6 in. downrod (A) and attach to

the 12 in. downrod (A). Insert downrod (A) through

canopy (B), canopy cover (I), and yoke cover (F).

(Fig. 2). [Note: Canopy cover (I) must be turned with

the shiny side toward the motor housing (D).] Thread

wires from motor housing (D) through downrod (A).

INITIAL INSTALLATION

Remove motor screws (J) and lock washers (K)

from underside of motor and save for bade arm

(P) attachment later on. [If there are plastic motor

blocks installed with the motor screws (J) and

lock washers (K), discard the plastic motor

blocks.] (Fig. 5)

FAN MOUNTING

Hanging

Ball

Set

Screw

Remove pin (M) and clip (N) from downrod (A). (Fig. 1A)

Partially loosen set screws in motor housing yoke at top

of motor housing (D). (Fig. 1B)

*Helpful Hint: Downrod style mounting is best suited for

ceilings 8 ft. (2.44 m) high or higher. For taller ceilings

you may want to use a longer downrod (sold separately)

than the ones provided. Angle style mounting is best

suited for angled or vaulted ceilings. A longer downrod

is sometimes necessary to ensure proper blade

clearance.

Set

Screw

1. 1A 1B

Install ball end of downrod (A) into mounting

bracket (C) opening. Align slot in ball with tab in

mounting bracket (C). (Fig. 6)

DANGER: Failure to align slot in ball with tab

may result in serious injury or death.

BBHanging

Ball Slot

Ball Tab

If you decided to cut back the lead wires in Step 3,

strip 1/2 of an inch of insulation from end of white

wire. Twist stripped ends of each strand of wire

within the insulation with pliers. (Fig. 5) Repeat

Step 4 for black, blue (if applicable) and green

wires.

Depending on the length of downrod (A) you use,

you may need to cut the lead wires back to

simplify the wiring. If you decide to cut back the

lead wires, it is suggested that you do so in the

following manner:

Take the lead wires and make sure that you have

pulled them all the way through the top of the

downrod (A). Start at the TOP of the ball on the

downrod (A) and measure 8 in. of lead wire, and

then cut the excess wire off with wire cutters.

(Fig. 4)

NOTE: If you do not cut back the lead wires,

Steps 4 and 5 are not necessary and you may

proceed to Step 6 instead.

Ball

FAN MOUNTING

WIRING

WARNING: To reduce the risk of fire,

electrical shock, or personal injury, wire connectors

provided with this fan are designed to accept only

one 12 gauge house wire and two lead wires from

the fan. If your house wire is larger than 12 gauge

or there is more than one house wire to connect to

the two fan lead wires, consult an electrician for the

proper size wire connectors to use.

CAUTION: Be sure outlet box is properly

grounded and that a ground (green or bare) wire is

present.

WARNING: If house wires are different colors

than referred to in the following steps, stop

immediately. A professional electrician is

recommended to determine wiring.

For each wire connection below, use one of the wire

connectors (AA) provided, making sure to screw

wire connector (AA) on in a clockwise direction.

Connect BLACK and BLUE wire from fan to

BLACK wire from ceiling. Connect WHITE wire

from fan to WHITE wire from ceiling. Connect all

GROUND (GREEN) wires together from fan (on

downrod and mounting bracket) to BARE/GREEN

wire from ceiling. (Fig. 1)

FAN CONTROLLED BY PULL CHAINS

BLACK

WHITE

GROUND/GREEN (BARE)

WHITE

BLUE

WHITE

FROM FAN

120 V Power

FROM

CEILING

FAN

GREEN

BLACK

GREEN

DANGER: If using this fan in a DAMP location,

this fan must be connected to a supply circuit that is

protected by a Ground Fault Circuit Interrupter

(GFCI) to reduce the risk of personal injury,

electrical shock or death.

Note: Black wire is hot power for fan. Blue wire is

hot power for light kit. White wire is common for fan

and light kit. Green or bare wire is ground.

WIRING

Wrap electrical tape around each individual wire

connector (AA) down to the wire as shown in Fig. 2.

WARNING: Make sure no bare wire or wire

strands are visible after making connections. Place

green and white connections on opposite side of box

from the black and blue (if applicable) connections.

Turn spliced/taped wires upward and gently push

wires and wire connectors (AA) into outlet box.

IMPORTANT: Using a full range dimmer switch to

control fan speed will cause a loud humming noise

from fan. To reduce the risk of fire or electrical

shock, do NOT use a full range dimmer switch to

control fan speed. (Fig. 3)

AA AA

2AA

AA E3 Wire Connector x4

Dimmer

Switch Speed

Switch

For illustrative purposes only--not

intended to cover all types of controls

Hardware Used

FINAL INSTALLATION

1. Locate two canopy mounting screws (L) on

underside of mounting bracket (C) and remove

canopy mounting screw (L) closest to the open end

of the mounting bracket (C). Partially loosen the

other canopy mounting screw (L). Lift canopy (B) to

mounting bracket (C). Place rounded part of slotted

hole in canopy (B) over loosened canopy mounting

screw (L) in mounting bracket (C) and push up.

Twist canopy (B) to lock. Re-insert canopy

mounting screw (L) that was removed, and then

tighten both canopy mounting screws (L). Slide

canopy cover (I) up to canopy (B). Press up gently

but firmly on canopy cover (I) until you hear it snap

onto the bottom of the canopy (B). (Fig. 1)

Table des matières

Langues :

Autres manuels Harbor Breeze Ventilateur

Harbor Breeze

Harbor Breeze MERRIMACK 40942 Manuel

Harbor Breeze

Harbor Breeze HIVE Series Manuel utilisateur

Harbor Breeze

Harbor Breeze C-TR56BNK3D1R Manuel utilisateur

Harbor Breeze

Harbor Breeze BRADBURY BRD48BNK6LRS Manuel utilisateur

Harbor Breeze

Harbor Breeze 41107 Manuel utilisateur

Harbor Breeze

Harbor Breeze E-BDB52LABZ5BC4N Manuel utilisateur

Harbor Breeze

Harbor Breeze OCEANSIDE Manuel utilisateur

Harbor Breeze

Harbor Breeze 872 Manuel utilisateur

Harbor Breeze

Harbor Breeze 40678 Manuel utilisateur

Harbor Breeze

Harbor Breeze 41161 Manuel utilisateur

Harbor Breeze

Harbor Breeze 40959 Manuel utilisateur

Harbor Breeze

Harbor Breeze TIEMPO E-TM52BNK5CS Manuel utilisateur

Harbor Breeze

Harbor Breeze NAVIN 41555 Manuel utilisateur

Harbor Breeze

Harbor Breeze URBANIA E-AR54BNK5C1 Manuel utilisateur

Harbor Breeze

Harbor Breeze ELEVATION LP8006LBN Manuel utilisateur

Harbor Breeze

Harbor Breeze 0883783 Manuel utilisateur

Harbor Breeze

Harbor Breeze Teolo Manuel utilisateur

Harbor Breeze

Harbor Breeze CLASSIC STYLE BDB52LW5N Manuel utilisateur

Harbor Breeze

Harbor Breeze BIRCHMOUNT COVE 41554 Manuel utilisateur

Harbor Breeze

Harbor Breeze PORTES LP8293LAZ Manuel utilisateur

Harbor Breeze

Harbor Breeze WINDRISE E-TLEII44BNK5C1 Manuel utilisateur

Harbor Breeze

Harbor Breeze 40821 Manuel utilisateur

Harbor Breeze

Harbor Breeze CHESHIRE II CSD52FBZ5C4S Manuel utilisateur

Harbor Breeze

Harbor Breeze CHESHIRE II Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
