Harbor Breeze LP8221LCH Manuel utilisateur

Español p. 15

ITEM #0232646

MODEL #LP8221LCH

BLUE HILL CEILING FAN

Harbor Breeze® is a registered trademark

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-888-567-2055, 8 a.m. - 5 p.m., EST, Monday - Friday.

ATTACH YOUR RECEIPT HERE

Serial Number Purchase Date

Lowes.com/harborbreeze

EB13235

Lowes.com/harborbreeze

TABLE OF CONTENTS

Package Contents .........................................................................................................................

Hardware Contents .......................................................................................................................

Safety Information .........................................................................................................................

Preparation ...................................................................................................................................

Assembly Instructions ...................................................................................................................

Wiring Instructions ........................................................................................................................

Final Assembly Instructions ..........................................................................................................

Operating Instructions ....................................................................................................................

Care and Maintenance .................................................................................................................

Troubleshooting ............................................................................................................................

Warranty .......................................................................................................................................

Replacement Parts List ................................................................................................................

Lowes.com/harborbreeze

PACKAGE CONTENTS

PART DESCRIPTION QUANTITY

Motor Assembly

Blade

Remote

Receiver (preassembled to Motor

Assembly (A))

HARDWARE CONTENTS (shown actual size)

Wire

Connector

Qty. 4

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install

the product.

• Before you begin installing the fan, disconnect the power by removing fuses or turning off circuit

breakers.

• Make sure all electrical connections comply with local codes, ordinances, or the National

Electrical code. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are

unfamiliar with installing electrical wiring.

•Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades

to the floor and at least 30 in. from the ends of the blades to any obstruction.

•If you are mounting the fan to a ceiling outlet box, use a METAL octagonal outlet box.

Secure the box directly to the building structure. The outlet box and its support must be able to

support the moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.

• After you install the fan, make sure all connections are secure to prevent the fan from falling.

• For supply connections, if the conductor of a fan is identified as a grounded conductor, then it

should be connected to a grounded conductor power supply. If the conductor of a fan is identified

as an ungrounded conductor, then it should be connected to an ungrounded conductor power

supply. If the conductor of a fan is identified for equipment grounding, then it should be connected

to an equipment-grounding conductor.

• This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses

Flat

Washer

Qty. 13

Lowes.com/harborbreeze

Serrated Head

Screw

Qty. 13

Nylon

Lock Nut

Qty. 5

SAFETY INFORMATION

• The net weight of this fan is: 16.42 lbs.

PREPARATION

and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Lowes.com/harborbreeze

WARNING

• Do not install or use fan if any part is damaged or missing.

• To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this

fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If

your house wire is larger than 12-gauge or there is more than one house wire to connect to the

two fan lead wires, consult an electrician for the proper size wire connectors to use. Before

cutting, drilling or hammering, verify their location. If needed, contact your electrician, plumber

or service person.

• To reduce the risk of fire, electric shock, or personal injury, do not bend the blade arms when

installing them, balancing the blades, or cleaning the fan. Do not insert foreign objects between

the rotating fan blades. Mount to outlet box marked “ACCEPTABLE FOR FAN SUPPORT” and

use mounting screws provided with the outlet box. Most outlet boxes commonly used for the

support of lighting fixtures are not acceptable for fan support and may need to be replaced.

Consult a qualified electrician if in doubt.

• This fan is to be used in dry locations only.

• Read all instructions and safety information before installing the new fan. Review accompanying

assembly diagrams.

CAUTION

Before beginning assembly of product, make sure all parts are present. Compare parts with

package contents list and hardware contents list. If any part is missing or damaged, do not

attempt to assemble the product.

Estimated Assembly Time: 60 minutes

Tools Required for Assembly (not included): Phillips screwdriver, 1/4 in. flathead screwdriver,

wire stripper and step ladder.

Helpful Tools (not included): AC tester light, do-it-yourself wiring handbook and wire cutters.

• Do not operate this fan with a variable (Rheostat) wall controller or dimmer switch. Doing so could

result in damage to the ceiling fan's remote control unit.

ASSEMBLY INSTRUCTIONS

1. Secure metal octagonal outlet box (not included)

directly to the building structure.

Lowes.com/harborbreeze

NOTE: Supply wires omitted for clarity.

To avoid possible electrical shock, be sure electricity

is turned off at the main fuse box before assembly.

WARNING

3. Securely attach the ceiling plate to the outlet

box with screws and washers (not included). 3

2. Remove the two preassembled screws from

ceiling plate in motor assembly (A). 2

ASSEMBLY INSTRUCTIONS

Lowes.com/harborbreeze

White Wire

from Fan

Black Wire

from Fan

White Wire

from Supply

Black Wire

from Supply

Green Wire (Ground)

from Supply

Green Wire

(Ground)

from Ceiling Plate

WIRING INSTRUCTIONS

NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as

it must be grounded for safe operation.

Hardware Used

DD x 3

Wire

Connector

To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.

WARNING

1. Connect the green grounding lead from

the ceiling plate to the supply grounding

conductor (this may be a bare wire or wire with

green colored insulation). Securely connect

wires with wire connector (DD). Securely

connect the white fan motor wire to the white

supply (neutral) wire using wire connector (DD).

Securely connect the black fan motor wire to

the black supply wire using wire connector (DD).

2. After connections have been made, turn leads

upward and carefully push leads into the

recessed portion of the ceiling plate with the

white and green leads to one side and the

black leads to the other side.

WARNING

Check to see all connections are tight, including

ground, and no bare wire is visible at the wire

connectors except for the ground wire. Do not

operate fan until the blades are in place. Noise

and motor damage could result.

4. Hook the ceiling support cable from motor

assembly (A) to the hook on the ceiling plate.

FINAL ASSEMBLY INSTRUCTIONS

Lowes.com/harborbreeze

NOTE: This step is applicable after the necessary wiring

is completed.

Hardware Used

CC x 4

Nylon

Lock Nut

2. Securely attach motor assembly (A) by twisting

clockwise onto the ceiling plate.

3. Remove the blade bushing cover from the blade

(B).

1. Assemble the motor assembly (A) to the

ceiling plate using nylon lock nuts (CC).

FINAL ASSEMBLY INSTRUCTIONS

Lowes.com/harborbreeze

OPERATING INSTRUCTIONS

1. Restore electrical power to the outlet box by

turning the electricity on at the main fuse box.

Hardware Used

Serrated Head

Screw

AA x 12

BB Flat

Washer x 12

4. Position the blades (B) onto the blade arms of

motor assembly (A) with threaded posts

showing. Make sure the blades (B) are fully

seated against the blade arms of motor

assembly (A). Install and tighten serrated head

screws (AA) with flat washers (BB) to secure

the blades (B) to the blade arms of motor

assembly (A).

IMPORTANT: Using a full range dimmer switch

(not included) to control fan speed will damage

the fan. To reduce the risk of fire or electrical shock,

do not use a full range dimmer switch to control the

fan speed.

For illustrative purposes only-not

intended to cover all types of controls

WARNING

Do not operate this fan with a variable (Rheostat)

wall controller or dimmer switch. Doing so could

result in damage to the ceiling fan's remote

control unit.

3. To make fan operational, install 12-volt battery

(included in remote control package) into the

remote (C).

If you are not expecting to use the remote for a

long period of time, remove the battery to

prevent damage to the remote. Be sure to store

the remote away from excess heat or humidity.

CAUTION

Lowes.com/harborbreeze

4. Follow the below steps to set the remote (C):

OPERATING INSTRUCTIONS

1) When powering on your fan, do not press

any button(s) before pressing the “SET”

button, otherwise it will fail the learn

procedure. If you press a button before the

“Set” button, please turn the power off then

on again, and start the process again.

2) Set the dip switches inside the battery

compartment door of the hand held

transmitter to the desired setting.

3) After installing the unit and restoring

power to your fan, press and hold the “SET”

button 1~5 seconds. You must press the

“SET” button within 60 seconds of restoring

power to the fan.

4) The fan will start to run and begin the

control setting process.

5) DO NOT press any button(s) after

pressing the SET button and while the fan is

programming or it will fail to program. The

fan will run in both directions for a total of

approximately 5 minutes.

6) When the fan stops after approximately 5

minutes the control and speed setting

process is complete.

The fan is now ready for normal use.

If you want to change the blades: turn

the off→ change the blades →turn the

power on →replay the power setting process.

NOTE

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Harbor Breeze Ventilateur

Harbor Breeze

Harbor Breeze BRADBURY BRD48BNK6LR Manuel utilisateur

Harbor Breeze

Harbor Breeze MZ44WW3LR Manuel utilisateur

Harbor Breeze

Harbor Breeze COGDELL COG60BNK7LR Manuel utilisateur

Harbor Breeze

Harbor Breeze SARATOGA Manuel utilisateur

Harbor Breeze

Harbor Breeze 40945 Manuel utilisateur

Harbor Breeze

Harbor Breeze TALAMORE TAL60BNK8LR Manuel utilisateur

Harbor Breeze

Harbor Breeze 41161 Manuel utilisateur

Harbor Breeze

Harbor Breeze 42224 Manuel utilisateur

Harbor Breeze

Harbor Breeze MARICOPA LP8013LAZ Manuel utilisateur

Harbor Breeze

Harbor Breeze L1305 Manuel utilisateur

Harbor Breeze

Harbor Breeze STONECROFT 41946 Manuel utilisateur

Harbor Breeze

Harbor Breeze CLASSIC STYLE BDB52LW5N Manuel utilisateur

Harbor Breeze

Harbor Breeze LANDON LAN52SS5L Manuel utilisateur

Harbor Breeze

Harbor Breeze CLASSIC STYLE BDB52LW5N Manuel utilisateur

Harbor Breeze

Harbor Breeze Santa Ana LP8294LBN Manuel utilisateur

Harbor Breeze

Harbor Breeze CHESHIRE II CSD52FBZ5C4S Manuel utilisateur

Harbor Breeze

Harbor Breeze ARMORY 40087 Manuel utilisateur

Harbor Breeze

Harbor Breeze BELCARRA CE-JP13BNK6RC Manuel utilisateur

Harbor Breeze

Harbor Breeze KEYPORT HUGGER 40141 Manuel utilisateur

Harbor Breeze

Harbor Breeze 40094 Manuel utilisateur

Harbor Breeze

Harbor Breeze LANSING 40198 Manuel utilisateur

Harbor Breeze

Harbor Breeze 35063 Manuel utilisateur

Harbor Breeze

Harbor Breeze MAZON MZ44BNK3LR Manuel utilisateur

Harbor Breeze

Harbor Breeze MAYFIELD BTH44AB5CS Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
