Handicare 2000 Manuel utilisateur
Handicare 2000
|QUICK REFERENCE GUIDE
VERSION 2.1
2
Contents
1. Introduction 2
2. Display codes 3
3. References 5
4. Glossary 6
5. Testing 10
6. Display 11
7. Toggle 11
8. The remotes 11
9. Safety edges 12
10. The batteries 13
11. Charging power supply 14
12. Boards 15
13. Options 16
14. Rescuing the user 18
15. Faults 19
2
1. Introduction
This guide is intended for use as a general reference by engineers
repairing faults on the Handicare 2000. The guide is structured as
follows: the first chapter provides general information about the
Handicare 2000, including how the Handicare 2000 should be tested,
where the components are located and how they react to certain
situations. The subsequent chapters deal with repairing faults.
Flow charts are used in some cases, where step-by-step choices have
to be made in order to find the cause of the fault.
There is room for improvement in every guide. If you have any tips or
suggestions, please let us know so that we can incorporate them.
We wish you the best of luck with your tasks and hope that this guide
will be of assistance.
Quick Reference Guide Handicare 2000
3
2. Display codes
Left hand
Code Meaning Page
None Power off 24
− Charging, joystick failure 23,26
0 General safety line 22
1 Requires charge 31
2 Off charge 31
3 Top track limit activated 27
4 Top safety edge activated 29
5 Bottom track limit activated 28
6 Bottom safety edge activated 30
7 Low battery voltage 31
8 UP travel direction 21
9 DOWN travel direction 21
A Hinge open 35
b Toggle switch active at power up 21
C IR address fail 32
d Relay not open 20
E Relay not closed 20
F Brake semi-conductor failed 21
G Brake not connected 20
H Relay not open (pre-delay) 20
J Hinge interlock switch fault 34
L Current limit exceeded 20
n Lift driving at half speed 38
o Default Eprom 21
r Power supply fault during charging 31
U Power supply fault when battery on float 31
y Main board hardware fault 21
.||. Overcurrent 20
4
2. Display codes
Right hand
Code Meaning Page
None Power off 24
− Charging, joystick failure 23,26
0 General safety line activated 22
1 Requires charge 31
2 Off charge 31
3 Bottom track limit activated 27
4 Bottom safety edge activated 29
5 Top track limit activated 28
6 Top safety edge activated 30
7 Low battery voltage 31
8 UP travel direction 21
9 DOWN travel direction 21
A Hinge open 35
b Toggle switch active at power up 21
C IR address fail 32
d Relay not open 20
E Relay not closed 20
F Brake semi-conductor failed 21
G Brake not connected 20
H Relay not open (pre-delay) 20
J Hinge interlock switch fault 34
L Current limit exceeded 20
n Lift driving at half speed 38
o Default Eprom 21
r Power supply fault during charging 31
U Power supply fault when battery on float 31
y Main board hardware fault 21
.||. Overcurrent 20
Quick Reference Guide Handicare 2000
5
3. References
Page
The general safetyline 22
The direction safetylines 29,30
The end limit switch 22,27,28,35
The batteries 24,31,34
The charger 31,35
The tractionmotor 21
The brake 21
The display 24
The on/off switch 24
The toggle 23,26
The armrestswitches 23,26
The hinge 33,34,35
The remotes 32
The infrared receiver 24,32
The fuse 24
The powered swivel 36
The powered footrest 37
The thermal fuse 24,32
6
4. Glossary
Version 2.1
7
4. Glossary
S13-14-15-16 Limit switch
S 17-18 Final limit switch
S10 Speed switch (lower trunnion)
S22 Hinge enable switch (top trunnion) not visible
S13
S14
S17
S18
S15
S16
S10
S13-14-15-16 Limit switch
S 17-18 Final limit switch
S10 Speed switch (lower trunnion)
S22 Hinge enable switch (top trunnion) not visible
Quick Reference Guide Handicare 2000
7
Version 2.1
8
S11-12 Front chassis edge switch
S35 Handwinderswitch
Contact charging (lower trunnion)
Contact communication hinge (upper trunion)
Safety brake
S19,S20 Overspeed governor switch
Infrared receiver
5-Amp-fuse/30-Amp-fuse
Main board P1
Motor
Brake
S11
S12
S35
S11-12 Front chassis edge switch
S35 Handwinderswitch
Contact charging (lower trunnion)
Contact communication hinge (upper trunion)
Safety brake
S19,S20 Overspeed governor switch
Infrared receiver
5-Amp-fuse/30-Amp-fuse
Main board P1
Motor
Brake
