Hakko Electronics FM-2029 Manuel utilisateur

TABLE OF CONTENTS

Thank you for purchasing the HAKKO FM-2029 Hot Air Handpiece.

Please read this manual before operating the HAKKO FM-2029.

Keep this manual readily accessible for reference.

HAKKO FM-2029 can not be operated by itself.

Read the instruction manual for the HAKKO FM-206

Rework System used in conjunction with the

HAKKO FM-2029.

1. PACKING LIST AND PART NAMES

2. SPECIFICATIONS

3. COMPATIBLE STATIONS

4. WARNINGS, CAUTIONS, NOTES AND EXAMPLES

5. INITIAL SETUP

6. OPERATION

7. TROUBLE SHOOTING GUIDE

8. PARTS LIST

9. NOZZLE STYLES

SINGLEHOTAIR

Instruction Manual

CAUTION

HAKKO FM-2029 1

Handpiece holder 1

Connecting cable 1

Heat resistant pad 1

1. PACKING LIST AND PART NAMES

Please make sure that all items listed

below are included in the package.

2. SPECIFICATIONS

Power Consumption

Nozzle to Ground Resistance

Nozzle to Ground Potential

Length (w/o cord, tube)

Weight (w/o cord, tube)

*Specifications and design are subject to change without notice.

*This product is protected against electrostatic discharge.

Instruction manual in the language of Japanese, English, Chinse, French, German and Korean

can be downloaded from the HAKKO Document Portal.

(Please note that some languages may not be available depending on the product.)

●HAKKO FM-2029

Use the HAKKO FM-2029 with the HAKKO FM-206 soldering station.

3. COMPATIBLE STATIONS

140W (24V)

< 2 Ω

< 2m V

232 mm (9.1 in.) with nozzle ø4.0 mm

50 g (0.11 lb.) with nozzle ø4.0 mm

*Nozzle is not included.

*Use a suitable nozzle.

HAKKO FM-2029

Handpiece holder

Heat resistant pad

Connecting cable

Hot Air button

4. WARNINGS, CAUTIONS, NOTES AND EXAMPLES

CAUTION

When the power is ON, the temperature of the hot air and the nozzle ranges from 100 to 550℃.

To avoid injury to personnel or damage to items in the work area, observe the following:

Do not touch the metal parts near the nozzle.

Do not use the product near combustible gasses or flammable materials.

Do not direct the hot air toward personnel.

Inform others in the area that the unit is hot and should not be touched.

Turn the power off when not in use, or left unattended.

Turn the power off when changing parts or storing the HAKKO FM-2029.

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Do not strike the handpiece against hard objects. This will damage the handpiece.

Do not modify the unit.

Use only genuine HAKKO replacement parts.

Do not allow the HAKKO FM-2029 to become wet, or use it when hands are wet.

Since smoke is produced when using the HAKKO FM-2029, be sure the work area is well ventilated.

While using HAKKO FM-2029, do not do anything which may cause bodily harm or physical damage.

●

5. INITIAL SETUP

Connection

The nozzle may be hot. Avoid holding the hot nozzle for a long time

even if using the heat resistant pad. Otherwise burns may result.

●

A. Insert the nozzle

1. Insert the nozzle into the HAKKO FM-2029 until it stops. (Fig.1)

●

(Fig.1)

NOTE:

Do not loosen the nipple.

5. INITIAL SETUP

When connecting or disconnecting the

cord assembly, hold the plug.

Be sure to turn off the power switch before connecting or

disconnecting the cord assembly for the handpiece to

and from the receptacle to avoid damaging the unit.

The HAKKO FM-2029 can be connected to channel 3 connector.

Insert the plug until it stops and try to remove it without pressing the release pin.

If it stays in the receptacle, it is properly seated.

NOTE :

Push on the plug until it stops, making sure it is securely connected.

2. Connect the tube of the handpiece to HAKKO FM-206.

(Fig.3)

3. Insert one end of the connecting cable into the jack at the back of the handpiece holder

and the other end into the jack at the back of the station to connect them. (Fig.4)

Connecting cable

When using the HAKKO FM-2029, be sure to

insert the connecting cable for the handpiece

holder into the jack for channel 3. Inserting the

connecting cable into the incorrect jack

will cause the system to not function

correctly.

NOTE :

●

B. Connect to HAKKO FM-206

1. Connect the cord assembly of HAKKO FM-2029 to channel 3 connector for HAKKO FM-206. (Fig.2)

●

(Fig.2)

(Fig.3)

(Fig.4)

5. INITIAL SETUP

●If the handpiece holder is not connected to HAKKO FM-206, HAKKO FM-2029 will not

start cooling when placed in the handpiece holder. Handpiece holder may overheat as a result.

●Be sure to turn off the power before connecting or disconnecting the connecting cable.

Securely insert the connecting cable all the way in to the jack.

1. Adjust the air flow and temperature.

Refer to instruction manual for HAKKO FM-206.

2. Press the Hot Air button on the handpiece.

Power to the heater and air flow will start.

3. Operating

(Refer to “A. Remove component” and “B. Attach component” .)

4. Place the handpiece into the handpiece holder, or press the Hot Air button on the handpiece.

Power to the heater will be stopped.

Hot air will be stopped after cooling automatically for 15 seconds.

Do not turn the power switch OFF until cooling stops.

A. Remove component

1 Heating

Apply the hot air to the component to be removed

and melt the solder. (Fig.5)

Be careful not to touch the component with the nozzle.

2 Grab the component using tweezers.

While applying the hot air, grab the component using the tweezers.

When grabbing the sides that are not soldered, this will help to

prevent the heat from escaping.

We recommend SMD tweezers when removing components. (Fig.6)

3 Remove the component.

When the solder has melted, remove the component by lifting the tweezers.

4 Remove any remaining solder.

After removing the component, remove solder with

desoldering tool or soldering iron and wick. (Fig.7)

6. OPERATION

If the handpiece holder is not connected to HAKKO FM-206, HAKKO FM-2029 will not

start cooling when placed in the handpiece holder. Handpiece holder may overheat as a result.

If placing the HAKKO FM-2029 into the handpiece holder for a long time, press the Hot Air

button on the handpiece and stop the hot air.

(Fig.5)

(Fig.7)

(Fig.6)

Hot Air button

6. OPERATION

7. TROUBLE SHOOTING GUIDE

B. Attach component

1 Apply the solder paste.

Apply the proper quality of solder paste and attach the component.

2 Preheat the component.

3 Solder the component.

Apply the hot air to the point to be soldered and solder it.

4 Clean

Clean any residual solder or flux from the board with appropriate cleanner.

Soldering using hot air has many advantages, but it sometimes results

in inadequate soldering.

We recommend all of the conditions for soldering be considered carefully.

If you set the air flow too high, the part or the solder may be blown out of place.

Reduce the air flow level when soldering parts.

The unit does not operate when pressing

the Hot Air button.

CHECK :Is the nozzle inserted properly ?

ACTION : Insert the nozzle completely.

CHECK :Is the connection cord broken ?

ACTION :If the cord assembly is broken,

replace the HAKKO FM-2029.

CHECK :Is the heater/sensor for nozzle broken ?

ACTION : Replace the nozzle with a new one.

CHECK : Is the o-ring removed from nipple ?

ACTION : Attach the o-ring.

CHECK : Is the tube of the handpiece connected to

HAKKO FM-206 ?

ACTION : Connect the tube to HAKKO FM-206.

●

●Hot air does not blow from the nozzle.

8.PARTS LIST

φA

φB

Part No.

N4-01

N4-02

N4-03

N4-04

Shape

2.0mm

(0.08 in.)

4.0mm

(0.16 in.)

6.0mm

(0.24 in.)

8.0mm

(0.32 in.)

2.5mm

(0.1 in)

5.0mm

(0.2 in.)

7.0mm

(0.28 in.)

9.0mm

(0.35 in.)

●HAKKOFM-2029

●Handpieceholder

FM2029-01

FM2029-02

HAKKO FM-2029

24V-140W Conversion kit

24V-140W

Item No.

Part No. Part Name Specifications

C1574

Part No. Part Name Specifications

Item No.

Handpiece holder

1 2 3 4

B3253

B2300

Item No.

Part No. Part Name Specifications

Connecting cable

Heat resistant pad

9.NOZZLE STYLES

φBφA

http://www.hakko.com

2011.3

MA02254XZ110303
