Electric

Dryer

User Manual-

Guide de l’Utilisateur-

Manual del Usuario-

Model #

Modèle

Para Modelo de

HLF11E

Sèche-Linge

Électrique

Secador-Eléctrico

Electric

Dryer

User Manual-

Guide de l’Utilisateur-

Manual del Usuario-

Model #

Modèle

Para Modelo de

HLF11E

Sèche-Linge

Électrique

Secador-Eléctrico

IMPORTANT SAFETY INSTRUCTIONS

Warning –

To reduce the risk of fire, electric shock, or injury

to persons when using your appliance, follow basic

precautions, including the following:

1. Read all instructions before using the appliance.

2. Do not dry articles that have been previously cleaned in, washed in,

soaked in, or spotted with gasoline, dry-cleaning solvents, or other

flammable or explosive substances, as they give off vapors that

could ignite or explode.

3. Do not allow children to play on or in the appliance. Close supervision

of children is necessary when the appliance is used near children.

4. Before the appliance is removed from service or discarded, remove the

door to the drying compartment.

5. Do not reach into the appliance if the drum is moving.

6. Do not install or store this appliance where it will be exposed to water

and/or to the weather.

7. Do not tamper with controls.

8. Do not repair or replace any part of the appliance or attempt any

servicing unless specifically recommended in the user-maintenance

instructions or in published user-repair instructions that you understand

and have skills to carry out.

9. Do not use fabric softeners or products to eliminate static unless

recommended by the manufacturer of the fabric softener or product.

10. Do not use heat to dry articles containing foam rubber or similarly

textured rubber-like materials.

11. Clean lint screen before or after each load.

12. Keep area around the exhaust opening and adjacent surrounding

areas free from the accumulation of lint, dust and dirt.

13. The interior of the appliance and the exhaust duct should be cleaned

periodically by qualified service personnel.

14. Do not place items exposed to cooking oils in your dryer. Items

contaminated with cooking oils may contribute to a chemical

reaction that could cause a load to catch fire.

15. If material has been used with any flammable liquids or solids it should

not be used in the dryer until all traces of the flammable liquids and its

fumes have been removed.

English

16. This dryer must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions

in the installation section.

17. Proper grounding must be ensured to reduce the risk of electric shock

and fire. Check with a qualified electrician or service personnel if you

are in doubt as to whether the dryer is properly grounded.

18. Use the dryer only for its intended purpose, drying clothes.

19. Always disconnect dryer from electrical supply before attempting any

service. Disconnect power cord by grasping the plug, not the cord.

20. Replace worn power cords and/or loose plugs.

21. To reduce the risk of electric shock or fire, do not use extension cords or

adapters to connect dryer to electrical power source.

SAVE THESE INSTRUCTIONS

For Future Use

English

As dry cleaning solvents, gasoline, vegetable and cooking oils are highly

hazardous materials, items soaked in or spotted with such should not be used in

the dryer. Items may still contain a substantial amount of the hazardous material

after being washed. When such items are exposed to heat they could ignite. As

clothes are stacked and piled up in the dryer the heat cannot escape. Due to this,

items become hot enough to possibly ignite. Washing in hot water with extra

detergent would reduce but not eliminate the risk of fire.

WARNING

Thank you for using our Haier

product. This easy-to-use manual will

guide you in getting the best use of

your dryer.

Remember to record the model and

serial number. They are on a label in

back of the dryer.

Model number

Serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain

warranty service.

DANGER

Risk of child entrapment. Before you throw away your old

dryer, take off the door so that children may

not easily get trapped inside.

Table Of Contents

PAGE

Safety Instructions............................................................................1

OPERATING INSTRUCTIONS............................................................5

Features ................................................................................................5

Other Features ......................................................................................7

Operations ............................................................................................8

Normal Operating Sounds ......................................................................9

Tips ......................................................................................................9

Care and Cleaning Guide ............................................................10

Troubleshooting..............................................................................11

INSTALLATION INSTRUCTIONS ....................................................12

Tools and Materials Required ................................................................12

Electrical Requirements ........................................................................12

Unpacking Your Dryer ..........................................................................12

Exhaust System Connections ......................................................13

Requirements and Instructions ..............................................................13

Materials ............................................................................................14

Location of Your Dryer..........................................................................16

Installation in Mobile Home ..................................................................17

Electrical Connections ....................................................................18

Requirements and Instructions ..............................................................18

3-Wire Cord Connections ....................................................................19

4-Wire Cord Connections ....................................................................20

Warranty ........................................................................................22

English

Features

Control Knob:

1. Dry Timer: Lets you set the time to dry your clothes, depending on the

fabric type and depending on the load size. This is designed for you to

set the number of minutes needed to dry the clothes. This cycle provides

up to 100 minutes of drying time at the temperature selection of your

choice. Drying time varies depending on size and dampness of the

load, weight and fabric type. Room temperature, humidity, type of

installation and electric voltage can also affect drying time.

2. Auto Dry: Lets you set the dryer to a preset dry cycle. This is designed

for the casual cottons. E.g. Jeans, etc. This cycle is best for regular and

permanent press items that can be tumble-dried. Drying time is

determined automatically at the temperature selection of your choice.

Here the cycle works better when items of similar fabric, weight and

construction are dried together.

OPERATING INSTRUCTIONS

WARNING: To reduce the risk of of fire, electric shock or injury to persons, read

the IMPORTANT SAFETY INSTRUCTIONS before operating this dryer.

English

Temperature Knob:

Temperature Setting Control: To set the heat drying temperature, of the

dryer load, depending on the fabric type.

• Low Heat: for knitted and delicate clothes.

• Med. Heat: for permanent press, synthetic clothes.

• High Heat: for regular clothes.

Always follow directions on fabric care labels.To avoid fire do not use

heat to dry items containing feathers, foam rubber or similar textured

rubber-like material.

Start Knob:

Start Button / Power On: Push Start button for 2 seconds to power on the

Dryer after loading. Unit will automatically stop once the dryer door is

opened. The start button must be once again pushed to resume operation

once the door is closed.
