HAI Zigbee Manuel utilisateur

Home Automation, Inc.

Zigbee Module

User (Operational) Manual

This document contains the intellectual property of Home Automation, Inc. (HAI). HAI authorizes

the use of this information for the sole purpose of developing software and systems to work with

the Zigbee Module. The specifications in this document are subject to change without notice.

Document Number 65R10-1

June, 2009

Page 1

INTRODUCTION

This document describes the wireless communications of the Zigbee Module. The Zigbee Module is a

portable device that allows for wireless communication between multiple Host devices. This document

describes the installation process, electrical connections, electrical specifications, and the FCC statements

for compliance.

INSTALLATION

1.) Begin by installing the Zigbee Module in the back of the Host device.

2.) After screwing the Zigbee to the back of the Host device, power the Host.

3.) Consult the Host User Manual for network details.

ELECTRICAL CONNECTIONS

The expansion board should connect to the thermostat using the 8 pin dual row J10 header on the read side

(side opposite of LCD). This header consists of a 5V supply, GND, and SPI full-duplex communication or

I/O Connections.

8 pin expansion module pin out.

ELECTRICAL SPECIFICATIONS

Min Typical Max

Voltage Level: 4.5V 5.0V 5.5V

Current: - - 90ma

SPI TX High 2.8V 3.3V 3.6V

SPI RX High 2.64V - 5.5V

SPI Baud - - 100khz

Page 2

Page 3

FCC STATEMENTS OF COMPLIANCE

Compliance Statement (Part 15.19)

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received,

including interference that may cause undesired operation.

Warning (Part 15.21)

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to

operate the equipment.

FCC Interference Statement (Part 15.105 (b))

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for

help.

FCC/IC RF Exposure

To comply with FCC/IC RF exposure limits for general population /

uncontrolled exposure, the antenna(s) used for this transmitter

must not be co-located or operating in conjunction with any

other antenna or transmitter.

RF Exposure (OET Bulletin 65)

To comply with FCC/IC RF exposure requirements for

mobile transmitting devices, this transmitter should only

used or installed at locations where there is at least 20cm

separation distance between the antenna and all persons.



Page 4

OEM Responsibility

OEM Responsibility to the FCC Rules and Regulations

The Zigbee Module has been certified per FCC Part 15 rules for integration into products

without further testing or certification. To fulfill the FCC certification requirements the OEM of

the Zigbee Module must ensure that the information provided on the Zigbee Label is placed on

the outside of the final product.

The Zigbee Module is labeled with its own FCC ID Number. If the FCC ID is not visible when the

module is installed inside another device, then the outside of the device into which the module

is installed must also display a label referring to the enclosed module. This exterior label can

use wording such as the following:

“Contains Transmitter Module FCC ID: HHC-65A10”

“Contains FCC ID: HHC-65A10”

The OEM of the Zigbee Module must only use the approved antenna, which has been certified

with this module.

The OEM of the Zigbee Module must test their final product configuration to comply with

Unintentional Radiator Limits before declaring FCC compliance per Part 15 of the FCC rules.

Section 7.1.5 of RSS-GEN

Operation is subject to the following two conditions:

1) this device may not cause interference, and

2) this device must accept any interference,

including interference that may cause undesired operation of the device.
