Hach EZ Series Manuel rapide

DOC023.97.90633

EZ-series

12/2022, Edition 7

Basic User Manual

Manuel d'utilisation de base

Manual básico del usuario

Manual básico do usuário

基本用户手册

基本取扱説明書

기본 사용 설명서

คู่มือผู้ ใช้เบื�องต้น

Table of Contents

English..............................................................................................................................3

Français......................................................................................................................... 37

Español.......................................................................................................................... 72

Português.................................................................................................................... 107

中文............................................................................................................................... 142

日本語........................................................................................................................... 173

한국어........................................................................................................................... 206

.................................................................................................................................. 239

Table of Contents

1 Legal information on page 3

2 Specifications on page 3

3 Online user manual on page 4

4 General information on page 5

5 Installation on page 10

6 User interface and navigation on page 22

7 Startup on page 22

8 Operation on page 25

9 Maintenance on page 25

10 Troubleshooting on page 34

11 Replacement parts and accessories on page 36

Section 1 Legal information

Manufacturer: AppliTek NV/SA

Distributor: Hach Lange GmbH

The translation of the manual is approved by the manufacturer.

Section 2 Specifications

Specifications are subject to change without notice.

Table 1 General specifications

Specification Details

Dimensions (W x H x D) 460 × 688 × 340 mm (18.11 × 27.09 × 13.39 in.)

Enclosure Enclosure rating: IP44; indoor use only

Enclosure material: ABS, PMMA and coated steel

Weight 25 to 40 kg (55 to 88 lb) (based on analyzer model)

Power requirements 110–240 VAC ±10%, 50/60 Hz1

Power consumption 150 VA maximum1

Installation category II

Pollution degree 2

Operating temperature 10 to 30 °C (50 to 86 °F); 5 to 95% relative humidity, non-condensing, non-corrosive

Storage temperature -20 to 60 °C (-4 to 140 °F), ≤ 95% relative humidity, non-condensing

Instrument air feed Dry and oil free according to ISA-S7.0.01-1996 quality standard for instrument air

Minimum pressure: 6 bar (600 kPa or 87 PSI)

Demineralized water For rinsing and/or dilution

Drain Atmospheric pressure, vented, minimum Ø 64 mm

Earth connection Dry and clean grounding pole with low impedance (< 1 Ω) with an earth cable of >

2.5 mm2 (13 AWG)

Analog inputs Electrodes, temperature, conductivity, colorimeter

Analog outputs Two to four 4–20 mA; maximum load: 500 Ω, galvanically isolated2

Digital inputs Four digital inputs: remote start/stop (potential-free contact) (optional)

Digital outputs Four potential-free digital outputs (FCT) to control internal valves/pumps; 24 VDC

Four powered digital outputs to control external vavles/pumps; 24 VDC, 500 mA

1Power requirements and consumption are based on the analyzer model, refer to the analyzer

serial number plate for detailed information.

2Optional modules are available to add a maximum of 10 analog outputs to the analyzer.

English 3

Table 1 General specifications (continued)

Specification Details

Communication USB port for data transfer

Optional: Ethernet, Modbus

Relay Five power relays (PCT), contact loading maximum 24 VDC, 0.5 A (resistive load)

Five potential free contact (FCT), maximum loading 24 VDC, 0.5 A (resistive load)

Ethernet connection Controller: Intel 82551ER

Transfer rate: 10/100 Mbps

Connector: RJ45 twisted pair (10 Base T / 100 Base T)

Cables: S/STP (category 5)

Alarms Malfunctioning alarm (potential free contact)

User interface IP65 flat color TFT touch screen (5.7 in.)

Ethernet 10 M (RJ45) NE 2000 compatible, Compact flash slot

System clock Battery life 4 years (approximately)

Certifications CE, ETL certified to UL and CSA safety standards, UKCA

Warranty USA: 1 year, EU: 2 years

Table 2 Ethernet configuration (optional)

Specification Description

Connection Remote TCP/IP server

IP address 192.168.10.1803

Service port 502

Modbus point type 40001–...

Read/write protocol Holding register

Table 3 RS232/485 configuration (optional)

Specification Description

Baud rate 9600

Parity None

Data bits 8 (word length)

Stop bits 1

Protocol None

Modbus point type 40001–40100 (holding register)

Transmission mode RTU

Device ID (default) 1

Section 3 Online user manual

This Basic User Manual contains less information than the User Manual, which is available on the

manufacturer's website.

3Standard value, user-programmable

4 English

Section 4 General information

In no event will the manufacturer be liable for damages resulting from any improper use of product or

failure to comply with the instructions in the manual. The manufacturer reserves the right to make

changes in this manual and the products it describes at any time, without notice or obligation.

Revised editions are found on the manufacturer’s website.

4.1 Safety information

The manufacturer is not responsible for any damages due to misapplication or misuse of this product

including, without limitation, direct, incidental and consequential damages, and disclaims such

damages to the full extent permitted under applicable law. The user is soley responsible to identify

critical application risks and install appropriate mechanisms to protect processes during a possible

equipment malfunction.

Please read this entire manual before unpacking, setting up or operating this equipment. Pay

attention to all danger and caution statements. Failure to do so could result in serious injury to the

operator or damage to the equipment.

Make sure that the protection provided by this equipment is not impaired. Do not use or install this

equipment in any manner other than that specified in this manual.

4.1.1 Use of hazard information

D A N G E R

Indicates a potentially or imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or serious

injury.

CAUTION

Indicates a potentially hazardous situation that may result in minor or moderate injury.

N O T I C E

Indicates a situation which, if not avoided, may cause damage to the instrument. Information that requires special

emphasis.

4.1.2 Precautionary labels

Read all labels and tags attached to the instrument. Personal injury or damage to the instrument

could occur if not observed. A symbol on the instrument is referenced in the manual with a

precautionary statement.

This is the safety alert symbol. Obey all safety messages that follow this symbol to avoid potential

injury. If on the instrument, refer to the instruction manual for operation or safety information.

This symbol indicates the need for protective eye wear.

This symbol indicates the need for protective gloves.

This symbol indicates the need for safety footwear.

English 5

This symbol indicates the need for protective clothing.

This symbol identifies a risk of chemical harm and indicates that only individuals qualified and trained

to work with chemicals should handle chemicals or perform maintenance on chemical delivery

systems associated with the equipment.

This symbol indicates that a risk of electrical shock and/or electrocution exists.

This symbol indicates that the marked item can be hot and should not be touched without care.

This symbol indicates that a risk of fire is present.

This symbol identifies the presence of a strong corrosive or other hazardous substance and a risk of

chemical harm. Only individuals qualified and trained to work with chemicals should handle chemicals

or perform maintenance on chemical delivery systems associated with the equipment.

This symbol indicates the presence of a harmful irritant.

This symbol indicates that the marked item should not be opened during operation.

This symbol indicates that the marked item should not be touched.

This symbol indicates a potential pinch hazard.

This symbol indicates that the object is heavy.

This symbol indicates the presence of devices sensitive to Electro-static Discharge (ESD) and

indicates that care must be taken to prevent damage with the equipment.

6 English

This symbol indicates that the marked item requires a protective earth connection. If the instrument is

not supplied with a ground plug on a cord, make the protective earth connection to the protective

conductor terminal.

Electrical equipment marked with this symbol may not be disposed of in European domestic or public

disposal systems. Return old or end-of-life equipment to the manufacturer for disposal at no charge to

the user.

4.1.3 Icons used in illustrations

Manufacturer

supplied parts

User supplied

parts Look Do steps in

reverse order Use fingers only Use two people

4.1.4 Chemical and biological safety

D A N G E R

Chemical or biological hazards. If this instrument is used to monitor a treatment process and/or

chemical feed system for which there are regulatory limits and monitoring requirements related to

public health, public safety, food or beverage manufacture or processing, it is the responsibility of the

user of this instrument to know and abide by any applicable regulation and to have sufficient and

appropriate mechanisms in place for compliance with applicable regulations in the event of

malfunction of the instrument.

4.1.5 Ozone precautions

CAUTION

Ozone inhalation hazard. This instrument produces ozone that is contained within the equipment,

specifically within the internal plumbing. The ozone could be released under fault conditions.

It is recommended to plumb the exhaust gas port to a fume hood or to the building exterior in

accordance with local, regional and national requirements.

Exposure to even low concentrations of ozone can damage delicate nasal, bronchial and pulmonary

membrane. In sufficient concentration, ozone can cause headaches, coughing, eye, nose and throat

irritation. Immediately, move the victim to uncontaminated air and seek first aid.

The type and harshness of symptoms are based on the concentration and exposure time (n). Ozone

poisoning includes one or more of the symptoms that follow.

• Irritation or burning of the eyes, nose or throat

• Lassitude

• Frontal headache

• Sensation of sub-sternal pressure

• Constriction or oppression

• Acid taste in mouth

• Asthma

In case of more severe ozone poisoning, the symptoms can include dyspnea, cough, choking

sensation, tachycardia, vertigo, lowering of blood pressure, cramping, chest pain, and generalized

body pain. Ozone can cause a pulmonary oedema one or more hours after exposure.

English 7

4.2 Intended use

The Hach EZ-series analyzers are intended for use by individuals who measure multiple water

quality parameters in samples from industrial and environmental applications. The Hach EZ-series

analyzers do not treat or alter water and are not used to control procedures.

4.3 Product overview

The Hach EZ-series analyzers are on-line analyzers that measure one or multiple parameters in

water samples from industrial and environmental applications. Refer to Figure 1.

The sample line moves the sample into the analyzer. The analyzer uses pumps, valves and syringes

to move the sample and reagents to the measuring cell on the analytics panel. When the

measurement cycle is complete, the analyzer discards the sample through the drain line. The

analysis results shows on the display of the data processing panel. The data processing panel

controls and configures the analyzer. The data processing panel saves the analyzer data (i.e.,

trends , alarms, analysis results and data log files).

A set of reagent bottles is supplied with the analyzer to hold the reagent and solutions. Sample

preconditioning could be necessary based on the analysis technology. Optional sample

preconditioning panels are available for the sample line.

There are different analyzer series available with different measurement technology and measured

parameters:

• EZ 1000 series—On-line colorimetric analyzers for general water analysis (chemical parameters)

and nutrient analysis (i.e., nitrate, phosphate, ammonia)

• EZ 2000 series—On-line colorimetric analyzers with digestion for general water analysis (chemical

parameters) and nutrient analysis (i.e., nitrate, phosphate, ammonia)

• EZ 3000 series—On-line ion-selective (ISE) analyzers for general water analysis

• EZ 4000 series—On-line titrimetric analyzers for general water analysis (chemical parameters)

• EZ 5000 series—Multiparametric on-line titrimetric analyzers for general water analysis (chemical

parameters)

• EZ 6000 series—On-line voltammetry analyzers for heavy/trace metal analysis (e.g., Ag, As, Cr,

Hg, Pb, Se)

• EZ 7x00 serires—On-line analyzers for industrial applications (e.g, COD, TOC, Total Nitrogen,

Total Phosphorus, volatile fatty acids FOS/TAC, influent toxicity, international bitternes units,

Adenosine Triphospahte)

The EZ-analyzer has different options such as: Sample detection, level detection for reagent bottles,

remote Start/Stop, auto-validation, auto-calibration, auto-cleaning, RS232 and Modbus.

8 English

Figure 1 Product overview

1 Electrical connectors and

plumbing access ports

4 USB port for data transfer 7 Door lock for electrical

compartment

2 EZ analyzer 5 Keypad and display 8 Analysis panel cover

3 M20 cable gland for power cord 6 Analyzer door

4.4 Product components

Make sure that all components have been received. Refer to Figure 2. If any items are missing or

damaged, contact the manufacturer or a sales representative immediately.

English 9

Figure 2 Product compoments

1 EZ analyzer 4 Lock washer, M8 (4x) 7 Tube fittings and ferrules4

2 Mounting brackets (2x) 5 Flat washer, M8 (4x) 8 Key for electrical compartment

3 Hex bolt, M8 × 16 (4x) 6 Reagent and solution bottles49 Power cord

Section 5 Installation

D A N G E R

Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the

document.

5.1 Installation guidelines

WARNING

Fire hazard. The user is responsible to make sure that sufficient precautions are taken when the

equipment is used with methods that use flammable liquids. Make sure to obey correct user

precautions and safety protocols. This includes, but is not limited to, spill and leak controls, proper

ventilation, no unattended use, and that the instrument is never left unattended while power is

applied.

CAUTION

Chemical exposure hazard. Obey laboratory safety procedures and wear all of the personal protective

equipment appropriate to the chemicals that are handled. Refer to the current safety data sheets

(MSDS/SDS) for safety protocols.

4Quantity and type is based on the supplied analyzer.

10 English

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Hach Instrument de mesure

Hach

Hach 5500sc Mode d'emploi

Hach

Hach Lange APA 6000 Mode d'emploi

Hach

Hach DR 1900 Manuel rapide

Hach

Hach sensION+ EC5 Manuel utilisateur

Hach

Hach QbD1200+ Manuel utilisateur

Hach

Hach sension 4 Manuel utilisateur

Hach

Hach IntelliCAL ISENH3181 Series Manuel utilisateur

Hach

Hach sensION+ EC71 Manuel utilisateur

Hach

Hach Polymetron 9610sc SiO2 Manuel utilisateur

Hach

Hach POCKET COLORIMETER II Manuel utilisateur

Hach

Hach ORBISPHERE 3658 Manuel rapide

Hach

Hach HQ430d Manuel rapide

Hach

Hach sension1 Manuel utilisateur

Hach

Hach 500sc SiO2 Mode d’emploi

Hach

Hach Sension4 Guide de référence

Hach

Hach 9186 Manuel utilisateur

Hach

Hach DR2400 Manuel utilisateur

Hach

Hach ORBISPHERE 410 Manuel rapide

Hach

Hach polymetron 9240 Manuel utilisateur

Hach

Hach Polymetron 9582sc Manuel rapide

Hach

Hach BioTector B7000 Manuel utilisateur

Hach

Hach TL2300 Manuel rapide

Hach

Hach ORBISPHERE 6110 Manuel utilisateur

Hach

Hach LANGE DR 900 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
