No. S1008

4 channel HoTT 2.4 GHz transmitter

X-8E

Manual

2 / 48 S1008_X-8E_jh_V1

3 / 48

S1008_X-8E_jh_V1

Index

Introduction..........................................................................5

Service Center .....................................................................5

Intended Use........................................................................6

Package Content.................................................................6

Technical Data .....................................................................7

Declaration of Conformity ..................................................7

Symbols Explication............................................................8

Safety Notes.........................................................................8

For your safety by handling the battery................................9

Control Elements and Connections.................................11

Buttons and Switches Layout ..........................................11

Commissioning..................................................................12

Battery connection............................................................12

Battery charging................................................................12

Transmitter power switch ..................................................12

Tension Spring Adjustment ..............................................13

Adjusting Steering Wheel Position ..................................13

Converting the Steering Wheel for Left-Handers...........14

Installing the Steering Wheel Adapter.............................15

RF SET................................................................................16

Binding .............................................................................16

Channel features (CH FUNCTION).....................................17

Range test ........................................................................18

Start Display.......................................................................19

Main Menu..........................................................................21

H/W SET .............................................................................21

TELE. (Telemetry Menu) ....................................................22

Setting & Data View ..........................................................22

RF Status View..................................................................22

Voice Trigger .....................................................................23

Device Management .........................................................23

Secret Mode.......................................................................24

Announcements (Voice Update) ........................................24

Language change .............................................................24

Steering wheel and throttle lever calibration.......................25

Interface (BT SPEED) ........................................................25

4 / 48 S1008_X-8E_jh_V1

Display Warnings...............................................................26

Voltage Display Calibration ..............................................26

Change the Values in an Input Field ................................27

M-SEL (Model Selection) ..................................................27

REVERSE (Servo Reverse)................................................27

TRIM ...................................................................................27

TRA ADJ (E.P.A.) ................................................................28

DR/EXP (Dual Rate/Exponential) .....................................28

B.R.A...................................................................................29

B-MIX..................................................................................30

TH RESP (Throttle Response) ..........................................30

IDLEUP (Pumping).............................................................30

PROFILE .............................................................................31

S/SPEED.............................................................................32

START .................................................................................32

TIMER .................................................................................33

SW SET...............................................................................34

FAIL SAFE...........................................................................36

SERVO (S View)..................................................................36

P/MIX ..................................................................................37

AUX .....................................................................................38

S/MODE..............................................................................38

A.B.S ...................................................................................40

Operating Receiver GR-8..................................................41

GR-8 Receiver Telemetry Menu .......................................42

Firmware Update - Transmitter........................................43

Firmware Update - Receiver ............................................44

Battery Disposal ................................................................45

Care and Maintenance......................................................45

Warranty .............................................................................45

5 / 48

S1008_X-8E_jh_V1

Introduction

Thank you for purchasing the Graupner X-8E HoTT radio. This

radio will transform the way you have been experiencing surface

radios and add a new level of user experience between you and

your model. The X-8E is easy to use and setup using the TFT

color and touch screen. The voice notifications will even further

enhance your user experience.

You can get more out of your X-8E using our wide selection of

telemetry speed controllers and telemetry ESC’s. All HoTT com-

patible products can be setup and programmed directly wire-

less from the X-8E. No need for computers or programming

boxes!

Check us out regularly on the web for new changes and revi-

sions of our manuals and firmware at www.graupnerusa.com.

This product complies with national and European legal require-

ments.

To maintain product condition and to ensure safe operation, you must

read and follow this user manual and the safety notes before use!

Note

This operating manual is part of the product. It contains important

information concerning operation and handling. Keep these instruc-

tions for future reference. Please pass this on to future owners or

third parties.

Service Center

Graupner USA – OPENHOBBY LLC

3941 Park Dr., Suite 20-571

El Dorado Hills, CA 95762

United States

Phone: (855) 572-4746 x2

Hours: Mon – Fri 9:00am – 4:00pm PST

Email: [email protected]

Online Support: www.graupnerusa.com

Graupner Online For service centers, downloads, upgrades and product list, visit

our web site at www.graupnerusa.com.

6 / 48 S1008_X-8E_jh_V1

Intended use

The X-8E HoTT transmitter is an ergonomically and technically

modern 8 function radio control system in 2.4GHzHoTT tech-

nology for ambitious and professional RC car and speedboat

drivers.

The X-8E HoTT transmitter is designed exclusively to be used in

battery-powered, unmanned radio controlled models; any other

use is not allowed. For any improper use no warranty or liability

is accepted.

Read through this entire manual before you attempt to use the

X-8E HoTT transmitter.

Graupner/SJ constantly works on the development of all prod-

ucts; we reserve the right to change the item, its technology and

equipment.

The product is not a toy. It is not suitable for children under

14 years. The operation of the X-8E HoTT transmitter must be per-

formed by experienced modelers. If you do not have sufficient

knowledge about dealing with radio-controlled models, please

contact an experienced model builder or a model club.

Package content

X-8E transmitter

GR-8 Receiver

LiPo battery 1S 5000 mAh

USB update cable set (No.S8500, 7168.S)

Micro SD card

Steering wheel adapter 10 degree and cover

Manual

7 / 48

S1008_X-8E_jh_V1

Technical Data

X-8E transmitter data

Operating voltage 3.4 to 6 V

Frequency 2.4 Ghz

Weight 1.44 lb (657 g)

Modulation FHSS

Range 1640 ft (500 m)

Control functions 4

Power consumption max. 600 mA

Temperature range 14° to 130°F (-10 to +55 °C)

Antenna type Patch antenna

Dimensions 8.6 x 7.3 x 5.5 in

GR-8 receiver data

Operating voltage 3.6 to 8.4 V

Frequency 2.4 Ghz

Weight 0.24 oz (6.9 g)

Modulation FHSS

Range 1640 ft (500 m)

Control functions 4

Power consumption 80 mA

Temperature range 14° to 130°F (-10 to +55 °C)

Aerial length 4.3 in (110 mm)

Dimensions 1.18 x 0.82 x 0.56 in

Declaration of conformity

S1008 / X-8E

Graupner/SJ declares that the product is conform to EU norms.

EN 301 489-1 V1.9.2

EN 301 489-17 V2.2.1

EN 300 328 V1.8.1

EN 60950-1:2006 + A11:2009 + A1:2010 + A2:2013

EN 62311:2008

8 / 48

Symbols explication

Always observe the information indicated by this warning sign.

Particularly those which are additionally marked with the signal

words CAUTION or WARNING.

WARNING indicates the potential for serious injury.

CAUTION indicates possibility of lighter injuries.

Note indicates potential malfunctions.

Attention indicates potential damages to objects.

Safety notes

General

These safety instructions are intended to protect this product,

yourself and the safety of others. Please read this section very

carefully before using this product!

To avoid risk of suffocation, keep packaging materials away from

babies and small children.

Supervision by an experienced adult is required for chil-

dren, persons mentally or physically handicapped, nov-

ices, or anyone not capable of safely using this product.

Always perform a range and function test on the ground

before you use your model (hold your model tight). Repeat

the test with running motor and with short throttle bursts.

Check all relevant laws and regulations before using this

remote control model. These laws and regulations must

be observed in for the safety of yourself and others and

may vary by state, region, or country.

Special liability insurance policies are mandatory for all

device operations. If you already own a device, determine

if the respective model is covered by your insurance.

9 / 48

S1008_X-8E_jh_V1

Protect all equipment from dust, dirt, moisture, vibration and

excessive heat or cold. The models may only be operated

remotely in normal outside temperatures ranging from 14° to

130°F (-10°C to 55°C).

Maintain frequent updates of your HoTT components with

the latest firmware version.

For additional questions or support, contact the Graupner

USA Service Center, or an experienced user.

Battery Safety

CAUTION

Protect batteries from dust, moisture, heat and vibrations.

For use in dry locations only.

Do not use damaged batteries.

Batteries not handled properly may catch fire, explode, or

cause irritation and burns. To extinguish a battery fire use

either water, CO² or sand.

Batteries should not be heated, burned, short-circuited,

incorrectly inserted, modified, soldered or welded.

Charge batteries in a room outfitted with a smoke detec-

tor, on a non-flammable, heat-resistant and non-conduc-

tive surface. Keep away from combustible or highly flam-

mable objects while charging. Always monitor batteries

during the charging process.

Do not exceed the maximum quick-charging current

specified for the respective cell type.

If a battery reaches temperatures above 140°F (60°C)

while it is being charged, immediately stop charging and

let the battery cool down to approximately 86 - 104°F (30

- 40°C).

Never charge batteries that have already been charged,

are hot or are not fully discharged. If a cell in a battery pack

heats up following a quick-charge process, this may indi-

cate a defective cell. Discard the battery immediately!

10 / 48 S1008_X-8E_jh_V1

Damaged or corroded batteries may leak an electrolyte

that is caustic and should not be touched or come into

contact with your skin or eyes. In case of emergency,

rinse thoroughly with water and seek immediate

medical attention.

Always fully recharge the battery.

Special instructions on charging LiPo batteries

To charge and discharge LiPo batteries, only use specifi-

cally designed chargers/dischargers with balancer con-

nector.

The white connector (cell count + 1 pole) is designed for

the connection to a LiPo balancer or a battery charger as

a single cell charger with a manual cell balancer. Always

charge the battery with the balancer connector.

Safety notes for stocking LiPo batteries

LiPo batteries should be stored with a voltage of about

3.8V per cell. If the cell voltage falls below 3V, then the bat-

tery must be charged. Fully discharging or storing a bat-

tery with a cell voltage < 3V renders the battery useless.

Exersize safety procautions when charging and transport-

ing your LiPo batteries. Always use a safety bag.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GRAUPNER Télécommande

GRAUPNER

GRAUPNER X-4S HoTT SJ Manuel utilisateur

GRAUPNER

GRAUPNER MZ-10 HOTT Manuel utilisateur

GRAUPNER

GRAUPNER MC-20 HoTT Manuel du propriétaire

GRAUPNER

GRAUPNER Sim-Control 6 Manuel utilisateur

GRAUPNER

GRAUPNER mx-16 ifs Manuel du propriétaire

GRAUPNER

GRAUPNER mx-16 HOTT Manuel du propriétaire

GRAUPNER

GRAUPNER mz-12PRO HoTT Manuel utilisateur

GRAUPNER

GRAUPNER mc-18 Manuel du propriétaire

GRAUPNER

GRAUPNER MX-12 - PROGRAMMATION Manuel utilisateur

GRAUPNER

GRAUPNER Rotaryselect mc-16 Manuel du propriétaire

GRAUPNER

GRAUPNER HoTT 2.4 VARIO Module 33601 Manuel utilisateur

GRAUPNER

GRAUPNER S1024 Manuel utilisateur

GRAUPNER

GRAUPNER mx-16 HOTT Manuel du propriétaire

GRAUPNER

GRAUPNER Kingpad mc-32 Edition Manuel utilisateur

GRAUPNER

GRAUPNER MX-101 HOTT Manuel du propriétaire

GRAUPNER

GRAUPNER Rotaryselect mc-16 Manuel utilisateur

GRAUPNER

GRAUPNER X-8N Manuel utilisateur

GRAUPNER

GRAUPNER mz-12 HOTT Manuel utilisateur

GRAUPNER

GRAUPNER X-8N Manuel utilisateur

GRAUPNER

GRAUPNER X-306 FM Manuel utilisateur

GRAUPNER

GRAUPNER S1038 Manuel utilisateur

GRAUPNER

GRAUPNER MX-12 - PROGRAMMATION Manuel du propriétaire

GRAUPNER

GRAUPNER 33124 Manuel utilisateur

GRAUPNER

GRAUPNER MX-16S Manuel du propriétaire

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
