GRAUPNER S8446 Manuel utilisateur

Manual

Voltage module +SBEC

S8446

2 / 2

3 / 12

S8446_jh_V1

Index

Introduction ...........................................................................4

Service Centre.......................................................................4

Intended use ........................................................................5

Package content ...................................................................5

Technical data .......................................................................5

Declaration of conformity .......................................................5

Symbols explication...............................................................6

Safety notes ..........................................................................6

Montage and connections .....................................................7

Programming the alarm threshold..........................................7

Programming the User Setup ................................................9

Indication in the transmitter telemetry display.........................9

Notes on environmental protection ......................................10

Care and maintenance ........................................................10

Warranty certificate..............................................................10

4 / 12 S8446_jh_V1

Introduction

Thank you very much for purchasing the Graupner Voltagemodul

+SBEC . This Voltage module is extremely versatile.

Read this manual carefully to achieve the best results with your

Voltage module +SBEC and first of all to safely control your models.

If you experience any trouble during operation, take the instruc-

tions to help or ask your dealer or Graupner Service Centre.

Due to technical changes, the information may be changed in

this manual without prior notice. Be always updated by checking

periodically on our website, www.graupner.de to be always upto-

date with the products and firmwares.

This product complies with national and European legal require-

ments.

To maintain this condition and to ensure safe operation, you must

read and follow this user manual and the safety notes before using

the product!

NOTICE

This manual is part of that product. It contains important infor-

mation concerning operation and handling. Keep these instruc-

tions for future reference and give it to third person in case you

gave the product.

Service Centre

Graupner Central Service

Graupner/SJ GmbH

Henriettenstrasse 96

D-73230 Kirchheim / Teck

Servicehotline

(+49) (0)7021/722-130

Monday - Thursday

9:15 am - 5:00 pm

Friday

9:15 am - 1:00 pm

Graupner USA

OPENHHBBY LLC

3245 University Ave

Suite 1520

San Diego, CA 92104

Website: www.graupnerusa.

com

Phone: +1 855-572-4746

Email:[email protected]

Graupner in Internet For the service centers outside Germany please refer to our web

site www.graupner.de

5 / 12

S8446_jh_V1

Intended use

The Voltage module is used to monitor the LiXX battery through

HoTT telemetry and as BEC power supply for receiver. The bat-

tery will be connected to the module through the plus and minus

cable. The voltage is permanently monitored and though the

programmable acoustic alarm the user can be informed in case

the voltage is lower than the programmed threashold. Other

uses are not allowed. For any improper use no warranty or lia-

bility is accepted.

Read through this entire manual before you attempt to install or

use the Voltage module.

Graupner/SJ constantly works on the development of all pro-

ducts; we reserve the right to change the item, its technology

and equipment.

Target group

The product is not a toy. It is not suitable for children under 14

years. The installation and operation of the Voltage module must

be performed by experienced modellers. If you do not have suf-

ficient knowledge about dealing with radio-controlled models,

please contact an experienced modeller or a model club.

Package content

Voltage module

Manual

Technical Data

Operational voltage - 7,4 to 22,2 V

BEC voltage - 4,5 to 8V

Dimensions - 35x17x7 mm

Weight - 8 grams

Declaration of conformity

S8446 Voltagemodul + SBEC

Graupner declares that the product is conform to EU norms.

EMC 2004/108/EC:

EN 61000-6-3: 2007+A1:2011

EN 61000-6-1:2007

6 / 12 S8446_jh_V1

Symbols explication

Always observe the information indicated by this warning sign.

Particularly those which are additionally marked with the CAU-

TION or WARNING. The signal word WARNING indicates the poten-

tial for serious injury, the signal word CAUTION indicates possibi-

lity of lighter injuries.

The signal words Note and Caution indicate potential damages

to objects.

Safety notes

General

These safety instructions are intended not only to protect the

product, but also for your own and other people’s safety. The-

refore please read this section very carefully before using the

product!

Do not carelessly leave the packaging material lying around,

since it might become a dangerous toy for children.

Persons, including children, with reduced physical, sensory

or mental capabilities, or lack of experience or knowledge,

or not capable to use safely the Voltage module must not use

the Voltage module without supervision or instruction by a

responsible person.

The Voltage module should never be in touch with water. Pro-

tect the module from dust, dirty, humidity and other small

parts. Avoid abnormal mechanical stress. Risk of fire!

Do not connect the Voltage module with reversed polarity.

Use polarity-safe plug-in systems. Avoid short-circuits. Risk

of fire!

Follow the safety instructions included with the batteries.

Use the Voltage module only within the indicated voltage

range, sirk of fire!

The Voltage module is conceived to be used only with Lithium

batteries, the Voltage module should not be used with other

types of batteries, like NiMH or NiCd. Risk of fire!

Changes and modification on the module are not allowed

because of safety and conformity (CE) reasons.

For all questions that are not answered in this manual, please

contact our Customer Service.

7 / 12

S8446_jh_V1

Montage and connections

Install the VOltage module in a proper place inside the model

where it is protected from vibrations. Connect the 3 poles cable

to the telemetry port of the receiver. The connectors are reverse

polarity protected: note the small chamfers on the sides. Never

use force – the connectors should engage easily. The socket is

labelled accordingly:

Brown cable (-), red cable (+) and orange cable (T).

The single red and black cables have to be connected to the

battery. (Red = + / black = -)

The update port allows the reciver update even with connected

module. To update the module please read the instruction of the

"Firmware_upgrade_studio“ on www.graupner.de. Moreover the

BEC voltage can be used to power for example an FPV camera.

Programming the alarm threshold

The alarm thresholds are displayed in the telemetry menu of the

transmitter. (Please read the manual of your transmitter how to

view the telemetry menu and how to navigate it)

The first page of the Voltage module in the telemetry menu is

only a display page.

In the next pages the alarm thresholds can be set. It is possible

to set up to 3 alarm thresholds for minimum battery voltage.

Min Voltage: The first alarm threshold can be used for the normal

minimum voltage, e. g. to allow a safe return flight.

Sensor 1: The second aarm threshold can be set a little lower

than the first one. So you can for example set a "coming home

function".

Sensor 2: The third threshold is normally set a little lower e. g. to

set a self landing function before the battery is completely empty.

Voltagemodul

LiPo 2-6 S

Receiver

Update connector

 

   

 

   

8 / 12 S8446_jh_V1

The following parameters can be set separately for all displays:

Warning Time: here you can set for each display if and how long

the alarm should be active for a specific value.

Repeat Time: here you can set how often an alarm should be

active when a specific value is reached.

Signal Tone: sets the signal tone melody. The warning sounds are

combined with the warnings on the display and the voice out-

put. Therefore, they may not be changed.

Page 1

Save Sensor: yes/no

After every setting in the pages "Page 1 - 5" the data must be

transferred to the Voltage module. Select "yes" and push "Enter".

If you do not proceed as described, the new data will not be

saved.

Factory set

A factory reset will be done if you select "yes" and push "Enter".

Page 2

Min Power Voltage

Here you can set the alarm threshold for minimum voltage.

The alarm threshold can be set between 0 and 25.0 V in steps

of 0,1 V.

Factory setting: 11.0 V, Signal Tone: P

Page 3

Sensor 1 Voltage

Here you can set the first alarm threshold for voltage.

The alarm threshold can be set between 0 and 25.0 V in steps

of 0,1 V.

Factory setting: 10.8 V, Signal Tone: R

Page 4

Sensor 2 Voltage

Here you can set a second alarm threshold for voltage.

The alarm threshold can be set between 0 and 25.0 V in steps

of 0,1 V.

Factory setting: 10.5 V, Signal Tone: S

 

  

    

  

  

  

   

   

    

   

   

  

  

   

   

    

   

   

   

  

   

   

   

  

   

   

9 / 12

S8446_jh_V1

Page 5

Max Power Voltage

Here you can set the alarm threshold for maximum voltage.

The alarm threshold can be set between 0 and 25.0 V in steps

of 0,1 V.

Factory setting: 17.5 V, Signal Tone: X

Programming the User Setup

Page 1

In the "User Setup“ the BEC voltage produced by the VOltage

module is set.

Save Sensor: yes/no

After every setting in the page "Page 2" the data must be trans-

ferred to the Voltage module. Select "yes" and push "Enter". If

you do not proceed as described, the new data will not be

saved.

Factory set

A factory reset will be done if you select "yes" and push "Enter".

Page 2

BEC Voltage

Here you set the BEC voltage.

The voltage can be set between 4,5 and 8 V.

In the following lines the BEC voltage will be shown.

Indication in the transmitter telemetry display

Select the telemetry display GENERAL.

The following displays will appear, at right the actual cell voltage

or the total voltage are alternatively shown. Under BAT1 and

SENSOR 1 will appear the actual total voltage, under BAT2 and

SENSOR 2 will appear the minimum cell voltage since the bat-

tery has been connected.

  

   

   

   

  

   

  

 

  

    

  



 

   

   

   

12.1V

AKK1

AKK2

3.9V T2 0°C

T1 0°C

LKRAF V

ZELL.V

1:4.00

2:4.10

3:4.00

4:0.00

5:0.00

6:0.00

12.1V

0°C

SENSOR 1

RX–S QUA: 100%

RX–S ST : 100%

TX–dBm: 33dBm

RX–dBm: 33dBm

RX–SPG.:4.8 TMP

V–PACK: 10ms

CH OUTPUT TYPE:ONCE

EMPFÄNGER

GENERAL

ELECT. AIR

VARIO

GPS

12.1V

AKK1

AKK2

3.9V T2 0°C

T1 0°C

LKRAF V

HÖHE

0m1

0m3

0.0A

SPANN.

12.1V

3.9V

0°C

SENSOR 2

12.1V

0.0A

0mAh

0ml

10 / 12 S8446_jh_V1

Notes on environmental protection

Disposal notes

This symbol on the product, user manual or packaging indicates

that this product must not be disposed of with other household

waste at the end of its life. It must be handed over to the appli-

cable collection point for the recycling of electrical and electronic

equipment.

The materials are recyclable as marked. By recycling, material

reusing or other forms of scrap usage you are making an import-

ant contribution to environmental protection.

Batteries and accumulators must be removed from the device

and disposed of at an appropriate collection point. Please inquire

if necessary from the local authority for the appropriate disposal

site.

Care and maintenance

Notes on care

The product does not need any maintenance, it works so as it

is without any special care. In your own interests protect it from

dust, dirt and moisture.

Clean the product only with a dry cloth (do not use detergent!)

lightly rub.

Warranty certificate

The Graupner, Henriettenstrassee 96, 73230 Kirchheim/Teck

grants from the date of purchase of this product for a period of

24 months. The warranty applies only to the material or opera-

tional defects already existing when you purchased the item.

Damage due to wear, overloading, incorrect accessories or

improper handling are excluded from the guarantee. The legal

rights and claims are not affected by this guarantee. Please

check exactly defects before a claim or send the product,

because we have to ask you to pay shipping costs if the item is

free from defects.

The present construction or user manual is for informational pur-

poses only and may be changed without prior notice. The cur-

rent version can be found on the Internet at www.graupner.de

on the relevant product page. In addition, the company Graupner

has no responsibility or liability for any errors or inaccuracies that

may appear in construction or operation manuals.

No liability can be accepted for printing errors.

Table des matières

Autres manuels GRAUPNER Unité de contrôle

GRAUPNER

GRAUPNER S8474 Manuel utilisateur

GRAUPNER

GRAUPNER 2381 Manuel utilisateur

GRAUPNER

GRAUPNER Soundswitch 2 Manuel utilisateur

GRAUPNER

GRAUPNER HOTT M-G2 Manuel utilisateur

GRAUPNER

GRAUPNER 23108 Guide de configuration

GRAUPNER

GRAUPNER 33600 Manuel utilisateur

GRAUPNER

GRAUPNER 3971 Manuel utilisateur

GRAUPNER

GRAUPNER S8351 Manuel utilisateur

GRAUPNER

GRAUPNER SXM 3971 Manuel utilisateur

GRAUPNER

GRAUPNER 3975 Manuel utilisateur

GRAUPNER

GRAUPNER 3972 Manuel utilisateur

GRAUPNER

GRAUPNER HoTT 2.4 Manuel utilisateur

GRAUPNER

GRAUPNER HoTT 2-4S EH Manuel utilisateur

GRAUPNER

GRAUPNER S1038 Manuel utilisateur

GRAUPNER

GRAUPNER 34002 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
