Grandview Motorised Rising Screen Manuel utilisateur

Grandview Motorised Rising Screen

User’s Manual

Imported and Distributed in Australia by

Herma Technologies

Factory 4A, 6 Albert St

Preston, VIC 3072

For more information please go to

www.grandviewscreens.com.au

or call 1300 730 025

Aug 2008 v1

Protecting your Screen:

• To ensure long lasting veiwing enjoyment, always

keep the screen rolled up when not in use.

• Keep away from direct sunlight or

high temperatures.

• Examine both the front and back surfaces before

retracting into the case to make sure it is free of

dust, dirt, insects or other foreign matter.

• Use a soft brush or cloth to lightly remove any

foreign particles.

Cleaning your Screen:

• Do not use any solvents, chemicals or abrasive

cleaners on the screen surface.

• Use a mild detergent with warm water to remove

any marks on the surface or screen case.

• Always immediately dab the screen with a soft

cloth to avoid soap marks.

• Do not scrub the surface.

Warranty: 12 Months

Lie the screen flat on the floor as shown.

Step 1

To the Owner:

Congratulations on purchasing a Grandview

Motorised Rising Screen, designed to produce the

sharpest, most pleasing pictures with maximum

convenience.

Important Notes:

• Please read this instruction manual before use

• Please do not attempt to adjust or repair

the product. You will void the warranty

• Please retain this Instruction manual for

future reference

• Ensure the screen is always set up on

even surface

• Never store the screen vertically

• Never operate with anything on top of the screen

Supplied

IR Remote

IR ReceiverPowercord

Step 3

Connect the screen to the power using

the power cord

Step 4

Using IR Remote

Your remote control comes with batteries installed.

To operate your remote:

Press to lift the screen

Press to stop the screen

Press to lower the screen

The Micro switch is used for

retracting or lowering screen in small increments.

Alternatively you may also use the external IR

receiver cable and sensor.

Plug the IR receiver cable into the IR Port on

the casing and mount the sensor in line of

sight with the remote.

Remove the components from the left hand side

compartment as shown below.

(Push the remote to release it from the compartment)

Step 2

Operational Instructions

Infrared Port
