WELCOME

Thank you for purchasing Grandstream’s HT701, the affordable, feature rich Analog Telephone Adaptor.

Grandstream HandyTone 701 is a new addition to the popular HandyTone ATA product family. It features

the rich audio quality, a broad range of voice codecs, and functionality of the HT701, including one FXS

port with an independent SIP account.

This manual will help you learn how to operate and manage your HandyTone701 Analog Telephone

Adaptor and make the best use of its many upgraded features including simple and quick installation, 3-

way conferencing, direct IP-IP Calling new provisioning support among other features. This HT701 is very

easy to manage and configure, and is specifically designed to be an easy to use and affordable VoIP

solution for both the residential user and the teleworker.

Safety Compliances

The HT701 phone complies with FCC/CE and various safety standards. The HT701 power adaptor is

compliant with UL standard. Only use the universal power adapter provided with the HT701 package. The

manufacturer’s warranty does not cover damages to the phone caused by unsupported power adaptors.

Warranty

If you purchased your HT701 from a reseller, please contact the company where you purchased your

device for replacement, repair or refund. If you purchased the product directly from Grandstream, contact

your Grandstream Sales and Service Representative for a RMA (Return Materials Authorization) number

before you return the product. Grandstream reserves the right to remedy warranty policy without prior

notification.

Caution: Changes or modifications to this product not expressly approved by Grandstream, or operation

of this product in any way other than as detailed by this User Manual, could void your manufacturer

warranty. Please do not use a different power adaptor with the HT701 as it may cause damage to the

products and void the manufacturer warranty.

This document contains links to HT701 GUI Interfaces. Please download these examples from

http://www.grandstream.com/products/ht_series/ht701/documents/ht701_gui.zip for your reference.

This document is subject to change without notice. The latest electronic version of this user manual is

available for download at:

http://www.grandstream.com/products/ht_series/ht701/documents/ht701_usermanual_english.pdf

Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for

any purpose is not permitted without the express written permission of Grandstream Networks, Inc.

Grandstream Networks, Inc. HT-701 User Manual Page 5 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

CONNECT YOUR HT701

Equipment Packaging

The HT701 ATA package contains:

One HT701 Main Case

One Universal Power Adaptor

One Ethernet Cable

Connecting the HT701

The HT701 is designed for easy configuration and easy installation. Configure the HT701 following the

directions in the Configuration section of this manual.

1. Connect a standard touch-tone analog telephone to the PHONE port.

2. Insert a standard RJ11 telephone cable into the Phone1 port and connect the other end of the

telephone cable to the analog telephone.

3. Insert the Ethernet cable into the WAN port of HT701 and connect the other end of the Ethernet

cable to an uplink port (a router or a modem, etc.)

4. Insert the power adapter into the HT701 and connect it to a wall outlet.

The HT701 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed to be a total

solution for networks providing VoIP services. The HT701 VoIP features and functions are available using

a regular analog telephone.

Figure 1: Connecting the HT701

Table 1: Definitions of the HT701 Connectors

Power Cable Power adapter connection

Internet Port (RJ-45) Connect to the internal LAN network or router.

RESET Factory Reset button: Press for 7 seconds to reset factory default settings.

FXS Port (RJ-11) FXS port: to be connected to analog phones / fax machines.

HT-701

k Vi

Internet Port

(RJ-45 connector

10/100 Mbps) Reset

Phone

(RJ-11 FXS Ports)

Power

Supply

(12V)

HT-701

Display LEDs

(green)

Grandstream Networks, Inc. HT-701 User Manual Page 6 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

There are four (4) LED buttons that help you manage the status of your HandyTone.

Table 2: Basic Definitions of the HT701 LEDs Pattern

LEDs

POWER LED Indicates Power. Remains ON when power is connected

Internet LED Indicates Access to Internet. Remains ON while there is Access

Link/Activity LED Indicates if There is Activity on the Internet Port

PHONE LED Indicate status of the respective FXS Ports-PHONE on the back

panel

Unregistered – OFF

Registered and Available – ON (Solid Green)

Off-Hook / Busy – Blinking every second

Slow blinking FXS LEDs indicates voicemail

NOTE: All LEDs display green when ON

Table 3: Advanced Definitions of the HT701 LEDs Pattern

Patten

Number Condition LED LED Behavior

LED-01 Device has normal power Power ON

LED-02 Power Error: Power is removed from the device or power

supply with improper voltage is plugged in Power OFF

LED-03 Line X is registered normally to the sip providers network

and is ready to make a call Phone ON

LED-04 Voice mail waiting for Line X Phone 1sec ON / 3sec OFF

LED-05 Device has normal WAN connection and has obtained IP

address Internet ON

LED-06 Internet link error: Device is powered up and ready to

connect to the Internet but the WAN/INTERNET port is

down Internet OFF

LED-07 Internet DHCP Error: Device is properly connected but it is

unable to retrieve an IP address from the device it is

connected to Internet 0.25sec ON/ 0.25sec OFF

LED-08 Line Registration failed: Device is properly setup, can

connect to provider's network, but cannot register to

provider's SIP proxy (no 200 OK) Phone OFF

LED-09 Device is connected (has physical data link) but there are

incorrect network settings typically associated with PPPoE

connection failure Internet 0.25sec ON/ 0.25sec OFF

LED-10 Hazardous potential test failed: Hazardous AC or DC

voltage is present on the tip and ring or both signals of

phone line X Phone 0.25sec ON/ 0.25sec OFF

LED-11 Foreign electro Motive Force (EMF) Test fail. Foreign

voltage is present on the tip, ring or both signals of phone

line. Device has detected additional external Phone

voltage on the FXS phone line.

Phone 0.25sec ON/ 0.25sec OFF

LED-12 Resistive fault test failed. Either tip or ring is shorted to

ground or they are shorted to each other. Phone 0.25sec ON/ 0.25sec OFF

LED-13 Receiver off hook test fail. One or more phones are off

hook on phone line during test. Phone 0.25sec ON/ 0.25sec OFF

LED-14 REN test failed – high REN detected. Too many parallel

phones connected to phone line X Phone 0.25sec ON/ 0.25sec OFF

LED-15 Line is active Phone 1 sec ON/ 1 sec OFF

Grandstream Networks, Inc. HT-701 User Manual Page 7 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

LED-16 Line inactive Phone ON

LED-17 During Provisioning Stage* Internet /

Phone 0.2sec ON/ 0.2sec OFF

LED-18 During Firmware Recovery Stage* Internet /

Phone 0.4sec ON/ 0.4sec OFF

*Note: In Provisioning and Firmware Recovery Stage, the power LED is Steady ON.

Figure 2: HT701 Connection Diagram

Internet

ADSL/Cable

Modem Ethernet

LAN FXS

Fax

Cordless

Phone

Analo

Grandstream Networks, Inc. HT-701 User Manual Page 8 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

PRODUCT OVERVIEW

The HT701 is a full feature voice and fax-over IP device that offers a high-level of integration including a

10M/100Mbps network port and one FXS telephone port, market-leading sound quality, rich functionalities,

and a compact and lightweight design. The VoIP network signaling protocol supported is SIP. The HT701

fully compatible with SIP industry standard and can interoperate with many other SIP compliant devices

and software on the market. Moreover, it supports comprehensive voice codecs including G.711 (a/µ-law),

G.723, G.726-32, G.729 and iLBC.

Software Features Overview

1 SIP account & profile

Supports Voice Codecs:

G.711 (a/µ-law), G.723, G.726-32, G.729 and iLBC.

T.38 Fax

Comprehensive Dial Plan support for Outgoing calls.

G.168 Echo Cancellation

Voice Activation Detection (VAD), Comfort Noise Generation (CNG), and Packet Loss

Concealment (PLC)

Supports PSTN/PBX analog telephone sets or analog trunks

Table 4: HT701 Technical Specifications

Telephone Interfaces 1 FXS port, 1 SIP account

Network Interface 1 RJ45 for LAN, 10/100 Base-TX, Full Duplex

LED Indicators Power, INTERNET, LINK/ACTIVITY, PHONE

Reset Button Factory Reset button

Voice over Packet

Capabilities Voice Activity Detection (VAD) with CNG (comfort noise generation) and PLC (packet

loss concealment), Dynamic Jitter Buffer, Modem detection & auto-switch to G.711,

Packetized Voice Protocol Unit (supports RTP/RTCP protocol), G.168 compliant Echo

Cancellation, LEC (line echo cancellation) with NLP, Asymmetric RTP stream

Voice Compression G.711 + Annex I (PLC), Annex II (VAD/CNG format) encoder and decoder, G.723,

G.726(ADPCM), G.729, iLBC, G.726 provides proprietary VAD, CNG, and signal power

estimation, Voice Play Out unit (reordering, fixed and adaptive jitter buffer, clock

synchronization), AGC (automatic gain control), Status output, Decoder controlling via

voice packet header

Telnet Server Yes

Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax

Pass-through, Fax Datapump V.17, V.19, V.27ter, V.29 for T.38 fax relay

QoS Diffserve, TOS, 802.1 P/Q VLAN tagging

IP Transport RTP/RTCP

DTMF Method Flexible DTMF transmission method, user interface of In-audio, RFC2833, and/or SIP

Info

IP Signaling SIP (RFC 3261)

Provisioning TFTP, HTTP, HTTPS

Control TLS/SIPS , SIP over TCP/TLS

Grandstream Networks, Inc. HT-701 User Manual Page 9 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

Device Management Web interface or via secure encrypted AES or non-encrypted central configuration file

for mass deployment using Grandstream binary file or xml format. Auto/manual

provisioning system or via built-in IVR.

NAT-friendly remote software upgrade (via TFTP/HTTP/HTTPS) for deployed devices

including behind firewall/NAT. Syslog support. Full support of TR-069 management

protocol.

Dial Plan Yes

Universal Switching

Power Adaptor Input: 100–240 VAC/50-60 Hz 0.18A Max

Output: 12VDC, 0.5A, UL certified

Environmental Operational: 32o–104oF or 0o–40oC

Storage: 10o–130oF / Humidity: 10–90% Non-condensing

Dimensions

(H x W x D) 86mm (L) x 65mm (W) x 26mm (H)

Short Haul Loop 5REN, Up to 1Km on 24 AWG wire

Call Handling Features Caller ID display or block, Call waiting caller ID, Call waiting/flash, Call transfer, hold,

forward, 3-way conferencing, message waiting, Do-Not-Disturb (DND), call-return

service

Caller ID Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID

Polarity Reversal / Wink Yes

EMC EN55022/EN55024 and FCC part15 Class B

Safety UL

Hardware Specification

The table below lists the hardware specification of HT701.

TABLE 5: HT701 HARDWARE SPECIFICATION

LAN Interface 1 RJ45 10/100Mbps

LED 4 LEDs (GREEN)

Universal Switching

Power Adaptor

Input: 100-240V AC, 50/60Hz, 0.18A Max

Output: 12V DC, 0.5A

UL certified

Dimension 86mm (L) x 65mm (W) x 25mm (H)

Weight 31 g (0.07lbs)

Temperature 32~104°F / 0~40°C

Humidity 10% - 90% (non-condensing)

Compliance

Grandstream Networks, Inc. HT-701 User Manual Page 10 of 31

Firmware Version 1.0.0.17 Last Updated: 02/2012

BASIC OPERATIONS

Understanding HT701 Voice Prompt

HT701 has a built-in voice prompt menu for simple device configuration. The IVR menu and the LED

button work with any of the FXS port. Pick up the handset and dial “***” to use the IVR menu.

Table 6: HT701 IVR Menu Definitions

Menu Voice Prompt Options

Main Menu “Enter a Menu Option” Press “*” for the next menu option

Press “#” to return to the main menu

Enter 01-05, 07,10, 13-17,47 or 99 menu options

01 “DHCP Mode”,

“Static IP Mode” Press “9” to toggle the selection

If using “Static IP Mode”, configure the IP address information using

menus 02 to 05.

If using “Dynamic IP Mode”, all IP address information comes from

the DHCP server automatically after reboot.

02 “IP Address “ + IP address The current WAN IP address is announced

If using “Static IP Mode”, enter 12 digit new IP address. You need to

reset the HT to take affect the new IP address.

03 “Subnet “ + IP address Same as menu 02

04 “Gateway “ + IP address Same as menu 02

05 “DNS Server “ + IP address Same as menu 02

07 Preferred Vocoder Press “9” to move to the next selection in the list:

PCM U / PCM A

iLBC

G-726

G-723

G-729

10 “MAC Address” Announces the Mac address of the unit.

13 Firmware Server IP

Address Announces current Firmware Server IP address. Enter 12 digit new

IP address.

14 Configuration Server IP

Address Announces current Config Server Path IP address. Enter 12 digit

new IP address.

15 Upgrade Protocol Upgrade protocol for firmware and configuration update. Press “9” to

toggle between TFTP / HTTP / HTTPS

16 Firmware Version Firmware version information.

17 Firmware Upgrade Firmware upgrade mode. Press “9” to toggle among the following

three options:

- always check

- check when pre/suffix changes

- never upgrade

47 “Direct IP Calling” Enter the target IP address to make a direct IP call, after dial tone.

(See “Make a Direct IP Call”.)

86 Voice Mail Number of Voice Mails

99 “RESET” Press “9” to reboot the device

Enter MAC address to restore factory default setting

(See Restore Factory Default Setting section)

“Invalid Entry” Automatically returns to main menu

Autres manuels pour HT701

Table des matières

Autres manuels Grandstream Networks Adaptateur

Grandstream Networks

Grandstream Networks HT701 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT812 Manuel utilisateur

Grandstream Networks

Grandstream Networks Handytone 502 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT702 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT-286 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT701 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT503 FXO Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone-801 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT802 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT701 Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone-488 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT802 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT701 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT802 Manuel

Grandstream Networks

Grandstream Networks HandyTone-386 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT-286 Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone 386 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT702 Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone-386 Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone 286 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT801 Manuel utilisateur

Grandstream Networks

Grandstream Networks HandyTone-286 Rev 3.0 Manuel utilisateur

Grandstream Networks

Grandstream Networks HT814 Mode d’emploi

Grandstream Networks

Grandstream Networks Handytone 502 Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
