Electric Airless Sprayer

OWNERS MANUAL

X5, X7, ProX17, ProX19, ProX21

3A3208B

IMPORTANT SAFETY INSTRUCTIONS

Read all warnings and instructions in this manual and related manuals. Be familiar with the

controls and the proper usage of the equipment. Save these instructions.

Not approved for use in explosive atmospheres or hazardous locations.

For portable airless spraying of architectural paints and coatings.

3A3208B

Not approved for use in explosive atmospheres or hazardous locations.

For portable airless spraying of architectural paints and coatings.

Important Safety Instructions

Read all warnings and instructions in this manual, related manuals, and on the unit.

Be familiar with the controls and the proper usage of the equipment. Save these

instructions.

FIRE AND EXPLOSION HAZARD

X5/X7 Models:

•Use only non-flammable or water-based materials, or non-flammable paint thinners. Do not use

materials having flash points lower than 100° F (38° C). This includes, but is not limited to, acetone,

xylene, toluene, or naphtha. For more information about your material, request Safety Data Sheet

(SDS) from the supplier.

•Spraying flammable or combustible materials in a factory or fixed location must comply with NFPA

33 and OSHA 1910.94(c) requirements in the USA and with all similar local regulations in other

countries.

Before You Spray

23A3208B

Before You Spray

Review Warnings for Important Safety Information

Important! Read carefully and practice good safety habits.

Review Manual & Watch Videos

Scan QR code for Operational Video or go to

magnum.graco.com/magop

Related Manuals

Gun: 312830 (SG)

ProXChange™ Pump: 3A3172 (ProX only)

Models

3000 psi (207 bar, 20.7 MPa) Maximum Working Pressure

VAC Model Stand (Series) Cart (Series)

120

USA

X5 262800 (E)

17K437 (A)

X7 262805 (D)

ProX17 17G177 (A)

17K438 (A) 17G178 (A)

ProX19 17G179 (A) 17G180 (A)

17K439 (A)

ProX21 17G181 (A) 17G182 (A)

110474

Certified to

CAN/CSA

C22.2 No. 68

Conforms to

UL 1450

Warnings

43A3208B

Warnings

The following warnings are for the setup, use, grounding, maintenance, and repair of this

equipment. The exclamation point symbol alerts you to a general warning and the hazard

symbols refer to procedure-specific risks. When these symbols appear in the body of this

manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols

and warnings not covered in this section may appear throughout the body of this manual

where applicable.

GROUNDING

This product must be grounded. In the event of an electrical short circuit, grounding reduces

the risk of electric shock by providing an escape wire for the electric current. This product is

equipped with a cord having a grounding wire with an appropriate grounding plug. The plug

must be plugged into an outlet that is properly installed and grounded in accordance with all

local codes and ordinances.

•Improper installation of the grounding plug is able to result in a risk of electric shock.

•When repair or replacement of the cord or plug is required, do not connect the grounding

wire to either flat blade terminal.

•Thewirewithinsulation having an outer surface that is greenwithor without yellow stripes

is the grounding wire.

•Check with a qualified electrician or serviceman when the grounding instructions are not

completely understood, or when in doubt as to whether the product is properly grounded.

•Do not modify the plug provided; if it does not fit the outlet, have the proper outlet installed

by a qualified electrician.

•This product is for use on a nominal 120V circuit and has a grounding plug similar to the

plugs illustrated below.

•Only connect the product to an outlet having the same configuration as the plug.

•Do not use an adapter with this product.

Extension Cords:

•Useonlya3-wireextensioncordthathasagroundingplugandagroundingreceptaclethat

accepts the plug on the product.

•Make sure your extension cord is not damaged. If an extension cord is necessary use 12

AWG (2.5mm2) minimum to carry the current that the product draws.

•An undersized cord results in a drop in line voltage and loss of power and overheating.

ti3509b

Conductor Size Length

AWG (American Wire Gauge) Metric Maximum

16 1.5 mm225 ft. (8 m)

12 2.5 mm250 ft. (15 m)

Warnings

3A3208B 5

FIRE AND EXPLOSION HAZARD

Flammablefumes,suchassolventandpaintfumes,inworkareacanigniteorexplode.Tohelp

prevent fire and explosion:

X5/X7 Models:

•Donotsprayorcleanwithmaterialshavingflashpointslowerthan100°F(38°C).Useonly

non-flammable or water-based materials, or non-flammable paint thinners. For complete

information about your material, request the Safety Data Sheet (SDS) from the material

distributor or retailer.

•Do not spray combustible materials near an open flame or sources of ignition such as

cigarettes, motors, and electrical equipment.

•Do not spray combustible liquids in a confined area.

ProX Models:

•Donot sprayflammableorcombustiblematerialsnearanopenflameor sourcesofignition

such as cigarettes, motors, and electrical equipment.

•Do not spray flammable or combustible liquids in a confined area.

All Models:

•Paint or solvent flowing through the equipment is able to result in static electricity. Static

electricity creates a risk of fire or explosion in the presence of paint or solvent fumes. All

parts of the spray system, including the pump, hose assembly, spray gun, and objects in

and around the spray area shall be properly grounded to protect against static discharge

andsparks.UseGraco conductive or grounded high-pressure airless paintsprayerhoses.

•Verify that all containers and collection systems are grounded to prevent static discharge.

Do not use pail liners unless they are anti-static or conductive.

•Connect to a grounded outlet and use grounded extensions cords. Do not use a 3-to-2

adapter.

•Do not use a paint or a solvent containing halogenated hydrocarbons.

•Keep spray area well-ventilated. Keep a good supply of fresh air moving through the area.

•Sprayer generates sparks. Keep pump assembly in a well ventilated area a least 20 feet

(6.1 m) from the spray area when spraying, flushing, cleaning, or servicing. Do not spray

pump assembly.

•Do not smoke in the spray area or spray where sparks or flame is present.

•Do not operate light switches, engines, or similar spark producing products in the spray

area.

•Keep area clean and free of paint or solvent containers, rags, and other flammable

materials.

•Know the contents of the paints and solvents being sprayed. Read all Safety Data Sheets

(SDSs) and container labels provided with the paints and solvents. Follow the paint and

solvents manufacturer’s safety instructions.

•Fire extinguisher equipment shall be present and working.

Warnings

63A3208B

SKIN INJECTION HAZARD

High-pressuresprayisabletoinjecttoxinsintothebodyandcauseseriousbodily injury. In the

event that injection occurs, get immediate surgical treatment.

•Do not aim the gun at, or spray any person or animal.

•Keephandsandotherbodyparts away fromthedischarge.Forexample,do not trytostop

leaks with any part of the body.

•Always use the nozzle tip guard. Do not spray without nozzle tip guard in place.

•Use Graco nozzle tips.

•Usecautionwhencleaningandchangingnozzletips.Inthecasewherethenozzletipclogs

while spraying, follow the Pressure Relief Procedure for turning off the unit and relieving

the pressure before removing the nozzle tip to clean.

•Equipment maintains pressure after power is shut off. Do not leave the equipment

energized or under pressure while unattended. Follow the Pressure Relief Procedure

when the equipment is unattended or not in use, and before servicing, cleaning, or

removing parts.

•Check hoses and parts for signs of damage. Replace any damaged hoses or parts.

•Thissystemiscapableofproducing3000psi.UseGracoreplacementpartsoraccessories

that are rated a minimum of 3000 psi.

•Always engage the trigger lock when not spraying. Verify the trigger lock is functioning

properly.

•Verify that all connections are secure before operating the unit.

•Know how to stop the unit and bleed pressure quickly. Be thoroughly familiar with the

controls.

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

•Always wear appropriate gloves, eye protection, and a respirator or mask when painting.

•Do not operate or spray near children. Keep children away from equipment at all times.

•Do not overreach or stand on an unstable support. Keep effective footing and balance at

all times.

•Stay alert and watch what you are doing.

•Do not operate the unit when fatigued or under the influence of drugs or alcohol.

•Do not kink or over-bend the hose.

•Do not expose the hose to temperatures or to pressures in excess of those specified by

Graco.

•Do not use the hose as a strength member to pull or lift the equipment.

•Do not spray with a hose shorter than 25 feet.

•Do not alter or modify equipment. Alterations or modifications may void agency approvals

and create safety hazards.

•Makesureallequipmentisrated and approvedfortheenvironmentinwhichyou are using

it.

ELECTRIC SHOCK HAZARD

This equipment must be grounded.Improper grounding, setup, or usage of the system can

cause electric shock.

•Turn off and disconnect power cord before servicing equipment.

•Connect only to grounded electrical outlets.

•Use only 3-wire extension cords.

•Ensure ground prongs are intact on power and extension cords.

•Do not expose to rain. Store indoors.

Warnings

3A3208B 7

PRESSURIZED ALUMINUM PARTS HAZARD

Useoffluidsthatareincompatiblewithaluminuminpressurizedequipment can cause serious

chemical reaction and equipment rupture. Failure to follow this warning can result in death,

serious injury, or property damage.

•Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon

solvents or fluids containing such solvents.

•Do not use chlorine bleach.

•Many other fluids may contain chemicals that can react with aluminum. Contact your

material supplier for compatibility.

MOVING PARTS HAZARD

Moving parts can pinch, cut, or amputate fingers and other body parts.

•Keep clear of moving parts.

•Do not operate equipment with protective guards or covers removed.

•Pressurized equipment can start without warning. Before checking, moving, or servicing

equipment, follow the Pressure Relief Procedure and disconnect all power sources.

TOXIC FLUID OR FUMES HAZARD

Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin,

inhaled, or swallowed.

•Read MSDSs to know the specific hazards of the fluids you are using.

•Store hazardous fluid in approved containers, and dispose of it according to applicable

guidelines.

PERSONAL PROTECTIVE EQUIPMENT

Wear appropriate protective equipment when in the work area to help prevent serious injury,

including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective

equipment includes but is not limited to:

•Protective eyewear, and hearing protection.

•Respirators, protective clothing, and gloves as recommended by the fluid and solvent

manufacturer.

CALIFORNIA PROPOSITION 65

ThisproductcontainsachemicalknowntotheStateofCaliforniatocausecancer,birthdefects

or other reproductive harm. Wash hands after handling.

ProX17: 17G177, 17K438, ProX19: 17G179

40 3A3208B

ProX17: 17G177, 17K438, ProX19: 17G179

Stand Sprayer Parts

Ref. Torque

140-160 in-lb (16-18 N•m)

30-35 in-lb (3.5-4.0 N•m)

110-120 in-lb (12-14 N•m)

45-55 in-lb (5-6 N•m)

10a

10b

15a

ti27198a

See page 48.

ProX17: 17G177, 17K438, ProX19: 17G179

3A3208B 41

17G177, 17K438, 17G179 Stand Sprayer Parts List

Ref. Part Description Qty.

1 KIT, repair, motor,

120V includes 1a

17K285 ProX17 1

17F756 ProX19 1

1a 287770 FAN 1

2 17J863 KIT, gear and yoke 1

3 17J173 CORD, power 1

4 17J864 KIT, yoke 1

6 117493 SCREW, mach, hex,

washer head 1

7 17J874 KIT, pump complete 1

8 17J865 SHIELD, motor, blue

includes 9 and labels 1

9 118444 SCREW, mach, hwhd

10-24 x 0.5 in. 3

10 17J866 COVER,frontincludes

9, 10a, 10b, 12, 14 1

10a 128551 CABLE, jumper, PC 1

10b 17F262 COVER, wire 1

12 115478 SCREW, mach, Torx,

pan hd 4

13 15J803 SWITCH, bracket 1

14 17F233 COVER, pump,

locking 1

15 17J867 KIT, control board

120V includes 15a, 16 1

15a 119276 FUSE, 12.5A slow

blow 1

16 117501 SCREW, plastite 1

17 24Y329 KIT, switch, repair

includes 13 1

18 115498 SCREW, mach, slot,

hex whd 1

19 17G328 PLATE, motor mount 1

20 16D686 KIT, right leg 1

21 16D687 KIT, left leg 1

22 260212 SCREW, hwh, thread

forming 8

23 15J599 CAP, tube 2

24 276864 HANDLE, sprayer 1

25 116139 GRIP, handle 1

27 LABEL, front

17J031 ProX17 1

17J033 ProX19 1

30 247340 HOSE, cpld, 1/4 in. x

50 ft 1

31 GUN, spray, SG3

243012 Models 17G177,

17G179 1

246506 Models 17K438, 1

32 115099 WASHER, hose 1

34 244035 DEFLECTOR, barbed 1

35 115489 CLAMP, drain tube 2

36 195084 TUBE, drain 1

37 24V074 KIT, tube, suction

includes34,35,36,38,

39, 40

38 116295 CLAMP, tube 1

39 195400 CLIP, spring 2

40 288716 KIT, strainer 1

45 17H422 CUP, suction/drain 1

5617J027 LABEL, warning 1

57222385 CARD, medical alert

(not shown) 1

60 3A3526 GUIDE,Magnumquick

guide, English (not

shown)

60a 3A3528 GUIDE,Magnumquick

guide, Spanish (not

shown)

61 115648 VALVE, power flush

(not shown) 1

62 244168 FLUID, pump armor, 8

oz (not shown) 1

64 17K631 TAG, hang, tip (not

shown) 1

17L305 KIT, conversion,

lacquer, stand (sold

separate)

ReplacementDangerand Warninglabels,

tags, and cards are available at no cost.

Ref. Part Description Qty.

Autres manuels pour PROX17

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Graco Pistolet à peinture

Graco

Graco ToughTek S340e Manuel d'utilisation et d'entretien

Graco

Graco Ultra-lite 235627 Fiche technique

Graco

Graco Fusion CS Series Manuel utilisateur

Graco

Graco HYDRA-SPRAY EH 333 226-333 Manuel d'utilisation

Graco

Graco 333013B Manuel de la liste des pièces

Graco

Graco FinishPro 290 Manuel utilisateur

Graco

Graco Series A Manuel d'utilisation

Graco

Graco Series A Manuel d'utilisation

Graco

Graco XP35 Manuel utilisateur

Graco

Graco GH 130 Manuel utilisateur

Graco

Graco Magnum Pro Compact A15 258861 Manuel utilisateur

Graco

Graco Mark X Manuel utilisateur

Graco

Graco GH 130 Convertible Manuel utilisateur

Graco

Graco 223-599 Manuel utilisateur

Graco

Graco TexSpray HTX 2030 Mode d’emploi

Graco

Graco 207-945 Manuel d'utilisation

Graco

Graco HVLP Series Mode d’emploi

Graco

Graco 17P481 Manuel d'utilisation et d'entretien

Graco

Graco Series A Manuel d'utilisation

Graco

Graco 255963 Manuel de la liste des pièces

Graco

Graco 231-581 A Series Manuel d'utilisation

Graco

Graco 256569 Manuel d'utilisation

Graco

Graco 220-856 Fiche technique

Graco

Graco performance pro 395 Manuel utilisateur

Manuels Pistolet à peinture populaires d'autres marques

SNOWJOE

SNOWJOE Sunjoe 24V-GS-LTW-RM Manuel utilisateur

Binks

Binks SV100 Manuel utilisateur

Fimco

Fimco LG-4-3-1 Manuel utilisateur

AG SPRAY

AG SPRAY FS-ATV-25BL Manuel utilisateur

Nordson

Nordson MicroMax 2 Manuel utilisateur

Bonide

Bonide 051 Manuel d'utilisation

zogics

zogics Z-DAS Manuel utilisateur

KISANKRAFT

KISANKRAFT KK-KBS-165 Manuel utilisateur

Matrix

Matrix SG 650 Manuel utilisateur

Anest Iwata

Anest Iwata SGA-3 Guide de démarrage rapide

paasche

paasche VV Fiche technique

Carlisle

Carlisle DeVilbiss JGA-510 Manuel utilisateur

Gardena

Gardena 11120 Manuel utilisateur

Conrad

Conrad Hobby Airbrush K3 Manuel utilisateur

wiwa

wiwa 14025 R/F Manuel utilisateur

DeVilbiss

DeVilbiss LUNA2i Manuel utilisateur

WAGNER

WAGNER W 125 Manuel utilisateur

My Clean Buddy

My Clean Buddy PW018 Manuel utilisateur
