Graco LDP5 Manuel utilisateur

Instructions

LDM5 (Standard) & LDP5 (Preset)

Electronic Metered Dispense Valves 312668ZAA

For metered dispense of oils and antifreeze. For professional use only.

Not approved for use in European explosive atmosphere locations.

Models: See page 2

1000 psi (7 MPa, 69 bar) Maximum Working Pressure

5 gpm (19 lpm) Maximum Flow Rate

Important Safety Instructions

Read all warnings and instructions in this manual.

Save these instructions.

NOTICE

This dispense valve:

• must be calibrated upon installation (see pages 12

and 19). Dispense amounts will vary with fluid

pressure, temperature, and type of fluid being dis-

pensed.

• is designed to dispense petroleum-based lubri-

cants and antifreeze only. Do not dispense wind-

shield washer solvent with this dispense valve.

• is designed for indoor use only.

•isnot designed for in-line installation.

• is designed for use with industrial grade batteries,

(see page 30).

LDM5 LDP5

ti12063a ti12065a

Model 256215 shown Model 256216 shown

Models

2312668ZAA

Models

Meter Model No. Extension Impact

Guard

Swivel

Cover

Inlet

Rigid Flex NPT BSPT BSPP

LDM5 255751 XX

LDM5 256215 X X X X

LDM5 258693 XXXX

LDM5 24F881 XX

LDM5 24F882 X X X X

LDM5 24F885 XXX X

LDM5 24F887 XX

LDM5 24F888 X X X X

LDM5 24F891 XXX X

LDP5 255277 XX

LDP5 256216 X X X X

LDP5 258694 XXXX

LDP5 24F883 XX

LDP5 24F884 X X X X

LDP5 24F886 XXX X

LDP5 24F889 XX

LDP5 24F890 X X X X

LDP5 24F892 XXX X

LDP5 24X465 X X X

Warnings

312668ZAA 3

Warnings

The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-

tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back

to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where

applicable.

WARNING

SKIN INJECTION HAZARD

High-pressure fluid from dispense valve, hose leaks, or ruptured components will pierce skin. This may

look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical

treatment.

• Do not point dispense valve at anyone or at any part of the body.

• Do not put your hand over the end of the dispense nozzle.

• Do not stop or deflect leaks with your hand, body, glove, or rag.

• Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning,

checking, or servicing equipment.

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

• Do not operate the unit when fatigued or under the influence of drugs or alcohol.

• Do not exceed the maximum working pressure or temperature rating of the lowest rated system

component. See Technical Data in all equipment manuals.

• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all

equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information

about your material, request MSDS forms from distributor or retailer.

• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-

facturer’s replacement parts only.

• Do not alter or modify equipment.

• Use equipment only for its intended purpose. Call your distributor for information.

• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.

• Do not kink or over bend hoses or use hoses to pull equipment.

• Keep children and animals away from work area.

• Comply with all applicable safety regulations.

FIRE AND EXPLOSION HAZARD

When flammable fluids are present in the work area, such as gasoline and windshield wiper fluid, be

aware that flammable fumes can ignite or explode. To help prevent fire and explosion:

• Use equipment only in well ventilated area.

• Eliminate all ignition sources, such as cigarettes and portable electric lamps.

• Keep work area free of debris, including rags and spilled or open containers of solvent and gasoline.

• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.

• Ground all equipment in the work area.

• Use only grounded hoses.

• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment

until you identify and correct the problem.

• Keep a working fire extinguisher in the work area.

Warnings

4312668ZAA

PERSONAL PROTECTIVE EQUIPMENT

Wear appropriate protective equipment when in the work area to help prevent serious injury, including

eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not

limited to:

• Protective eyewear, and hearing protection.

• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

CALIFORNIA PROPOSITION 65

This product contains a chemical known to the State of California to cause cancer, birth defects or other

reproductive harm. Wash hands after handling.

WARNING

Installation

312668ZAA 5

Installation

Typical Installations

FIG. 1 shows a typical hose reel installation. Dispense

valves can also be installed on a console as shown in

Fig. 2.

The typical installation shown in Fig. 1 is only a guide. It

is not a complete system design. Contact your Graco

distributor for assistance in designing a system to suit

your needs.

Mounting Bracket

Mounting bracket 196471 is available for resting dis-

pense valve on a console. See Fig. 2.

KEY DESCRIPTION

A Metered dispense valve

B Fluid shut–off valve

CHose

D Hose reel fluid inlet hose

E Hose reel

A Thermal Relief Kit (not shown) is required. The kit

will vary by pump selected. See Parts, page 28 for a

list of available kits.

FIG. 1

ti12081a

NOTICE

• Do not use this dispense valve on non-Graco con-

soles. The trigger could be inadvertently pressed

while the dispense valve is stowed.

• This dispense valve is not designed for in-line

installation. Do not install with a shut-off valve on

the outlet side of the meter which could damage

the meter housing cover.

NOTICE

Do not obstruct the dispense valve trigger and do not

set the unit down resting on its trigger or it might not

stop dispensing.

FIG. 2

mounting

bracket

196471

ti0274

Installation

6312668ZAA

Pressure Relief Procedure

The equipment stays pressurized until pressure is man-

ually relieved. To reduce the risk of serious injury from

pressurized fluid, accidental spray from the dispense

valve, or splashing fluid, follow this Pressure Relief

Procedure when you:

• are instructed to relieve pressure.

• check, clean, or service any system equipment.

• install or clean fluid nozzles or filter.

1. Turn off the power supply to the pump.

2. Trigger the dispense valve into a waste container to

relieve pressure.

3. Open any bleed–type master air valves and fluid

drain valves in the system.

4. Leave the drain valve open until you are ready to

pressurize the system.

Grounding

Proper grounding is an essential part of maintaining a

safe system. The movement of fluids through the dis-

pensing system generates static electricity. Static elec-

tricity can cause fumes to ignite, resulting in explosion

and fire. To reduce the risk of static sparking, ground all

system components per local and national electrical

codes. Refer to user manuals for pump and other sys-

tem components to ground the following:

•Pump: Follow manufacturer’s recommenda-

tions.

•Air and Fluid hoses: Use only grounded

hoses.

•Air compressor: Follow the manufacturer’s

recommendations.

•Fluid supply container: Follow the local code.

To maintain grounding continuity when flushing or

relieving pressure, always hold a metal part of valve

firmly to side of grounded metal pail, then trigger valve.

Pre–Installation Procedure

1. Install the battery. See Replacing the Battery on

page 30.

2. Follow the Pressure Relief Procedure.

3. Close the shut–off valve (B, FIG. 1, page 5).

4. Ground the hose and reel or console. See

Grounding.

Installation Procedure

If this is an existing installation, go to step 7. Steps 1 - 6

are the Flushing Procedure.

1. Close the fluid shutoff valve (B, FIG. 3) at each dis-

pense position.

2. Make sure:

• the main fluid outlet valve at the pump is closed,

• the air pressure to the pump motor is adjusted,

• the air valve is open.

3. Slowly open main fluid valve.

Leave a minimum of two engaged threads bare

when using PTFE tape. The bare threads ensure a

ground is maintained.

NOTICE

If this is a new installation or if there is contaminated

fluid in the lines, flush the lines before you install the

metered valve. Contaminated lines could cause the

valve to leak.

FIG. 3

ti12081a

Installation

312668ZAA 7

a. Place the hose end (with no dispense valve

connected) into a container for waste oil.

b. Secure the hose in the container so it will not

come out during flushing.

c. If you have multiple dispense positions, first

flush the dispense position farthest from the

pump, then work your way toward the pump.

5. Slowly open the shut–off valve (B, FIG. 4) at the dis-

pense position. Flush out a sufficient amount of oil

to ensure that the entire system is clean. Close the

valve.

6. Repeat step 5 at all other dispense positions.

Electronic Control Control (1) and Gasket

(2) Installation

Kits: 257350 and 257351

Connecting Hose to Meter

1. Follow the Pressure Relief Procedure, page 6.

2. Slide the swivel cover (34) onto the hose, small end

first, before connecting hose fitting to swivel (4) (FIG.

6).

3. Apply thread sealant to the male threads of the hose

fitting. Thread the hose fitting into the swivel (4) and

tighten firmly (FIG. 6).

FIG. 4

ti12081a

NOTICE

It is important to properly seat gasket (2) when install-

ing electronic control (1) to fluid section. An improp-

erly seated gasket could cause the meter to report

invalid dispense amounts because the glass reed

switches are broken.

FIG. 5

FIG. 6

Make sure you let sealant cure to the manufac-

turer’s recommendations before you let fluid into

the system.

hose

fitting

ti0269

Installation

8312668ZAA

Installing Extension and Nozzle on Meter

1. Thread the sealing nut (26c) onto the extension

(26a).

2. Thread extension into meter outlet at least three full

turns to tighten securely. (FIG. 7). (Over torquing

may cause casting meter to split)

3. Thread new nozzle (26b) onto extension. With an

open-end, adjustable wrench.Tighten it firmly.

4. Open all dispense position shut-off valves (B, FIG. 8)

and start the pump to pressurize the system. See

Operation, (LDM5 Meters - page 13; LDP5 Meters -

page 22), for proper operation of meter.

• To ensure dispensing accuracy, purge all air

from the fluid lines and dispense valve before

you use it.

• Set the system flow to the desired flow rate,

which is typically 1.5 gpm. Do not exceed a

5-gpm flow rate.

FIG. 7

NOTICE

• Do not overtighten extension to sealing nut. Over

tightening may cause meter casting to split.

• Do not use a twist/lock or manual shut-off nozzle.

You must use an automatic nozzle on the meter or

the meter could be damaged.

Only tighten nozzle with the wrench on the flats of

the nozzle bushing. Do not disassemble the

bushing from the nozzle. Disassembly will affect

the performance of the nozzle.

26c

26a

26b

FIG. 8

ti12081a

LDM5 Meter Setup and Operation Instructions

312668ZAA 9

LDM5 Meter Setup and Operation Instructions

Setup

Terms

The following terms are shown on the display and/or

used often in this instruction manual.

•R-TOTAL: Resettable Total

Shows the cumulative amount that has been dis-

pensed. Can be reset to zero.

•TOTAL: Non–Resettable Total

Shows the cumulative amount that has been dis-

pensed for the life of the unit. Cannot be reset.

•Standard Dispense Mode

Dispense mode in which display counts up from

zero or from where it recently stopped.

•ASLEEP / AWAKE Mode

Asleep is a battery–saving mode in which the dis-

play goes blank after 45 seconds of inactivity. The

display comes Awake from sleep mode when you

press any button on the keypad or squeeze the trig-

ger to dispense fluid.

Keypad Buttons (FIG. 9)

•TOTAL*

Displays the resettable total, non–resettable total,

and calibration factor.

•RESET*

Resets the displayed amount to zero or press to

enter the Standard Dispense Mode (see Terms).

* Press the hold Reset and Total

buttons simultaneously to dis-

play Setup Menus (page 10).

FIG. 9

All buttons are disabled while fluid is being

dispensed.

GAL

QTSPTS

LITERS

R-TOTAL

AUTO

Min. Dispense Volume 0.5 liter (0.13 gal)

Minimum Flow Rate 1.0 l/min. (0.26 gpm)

Maximum Flow Rate 19.0 l/min. (5.00 gpm)

Maximum Working Pressure: 70 bar (1000 PSI)

ti12043A

LDM5 Meter Setup and Operation Instructions

10 312668ZAA

Setup Menus (FIG. 10)

1. If the display is blank (asleep), wake it up by press-

ing any button on the keypad (FIG. 10).

2. Press and hold the Total and

Reset buttons simultaneously

for approximately six (6) sec-

onds to enter the Setup

Menus (FIG. 10).

There are three (3) Setup Menus available, stored in

a preset order.

a. The first screen displayed is the Resettable

Total Menu. When this menu is displayed,

R-TOTAL will blink on the screen (FIG. 11).

b. Press and hold Reset but-

ton to display Units of

Measure Menu. When

this menu is displayed the

last set Unit of Measure-

ment blinks on the screen

(FIG. 12).

c. Press and hold Reset button again to display

Calibration Menu. When this menu is displayed

CAL blinks on the screen (FIG. 13).

The total that is displayed when you leave each

menu is the total that is stored.

FIG. 10

During the first 4 seconds all segments display.

Then for 2 seconds the software version number

displays.

GAL

QTSPTS

LITERS

R-TOTAL

AUTO

Min. Dispense Volume 0.5 liter (0.13 gal)

Minimum Flow Rate 1.0 l/min. (0.26 gpm)

Maximum Flow Rate 19.0 l/min. (5.00 gpm)

Maximum Working Pressure: 70 bar (1000 PSI)

ti12044a

The following sections of this manual provide

instructions for using the Setup Menus.

Autres manuels pour LDP5

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Graco Unité de contrôle

Graco

Graco Dyna-Star 25U218 Manuel utilisateur

Graco

Graco Series A Manuel d'utilisation

Graco

Graco 242063 Fiche technique

Graco

Graco Therm-O-Flow 194485 Manuel d'utilisation

Graco

Graco ProGuard+ Manuel utilisateur

Graco

Graco PR70 Series Manuel

Graco

Graco 2K Ultra-Lite Series Manuel d'utilisation

Graco

Graco Series E Manuel d'utilisation

Graco

Graco Pulse 25D130 Manuel

Graco

Graco XM PFP Manuel d'utilisation

Graco

Graco 24J415 Manuel de la liste des pièces

Graco

Graco 77X542 Manuel utilisateur

Graco

Graco Dyna-Star 24Y408 Manuel d'utilisation et d'entretien

Graco

Graco 239850 Manuel d'utilisation

Graco

Graco 256556 Manuel d'utilisation

Graco

Graco Trabon MD Series Manuel utilisateur

Graco

Graco 26A231 Manuel de la liste des pièces

Graco

Graco Cleanshot 244162 Manuel utilisateur

Graco

Graco 222461 Manuel d'utilisation

Graco

Graco DISPENSIT 1206 Manuel utilisateur

Graco

Graco Advanjet 26B970 Instruction manuelle

Graco

Graco PD44 Mode d’emploi

Graco

Graco PM5 238513 Manuel d'utilisation

Graco

Graco Series A Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

Flyron

Flyron FN-BC04 Manuel utilisateur
