Godox LR160 Manuel utilisateur

Instruction Manual | 说明手册Chinese English Bilingual | 中英文双语

705-LR1600-00

地址/Add: 深圳市宝安区福永镇福洲大道西新和村华发工业园A4栋

Building A4, Xinhe Huafa Industrial Zone, Fuzhou RD West, Fuyong

Town, Baoan District, Shenzhen 518103, China

电话/Tel: +86-755-29609320(8062) 传真/Fax: +86-755-25723423

邮箱/E-mail: [email protected]

http://www.godox.com

深圳市神牛摄影器材有限公司

GODOX Photo Equipment Co., Ltd.

Made In China

LED Ring Light

LED环形灯

LR160

- 05 - - 06 -

5、LCD显示

亮度显示：从10% - 100%。色温显示：从3300K到8000K。

电量显示(在电池供电的情况下)。

电池电量显示（电池供电）意义/电量百分比

3格 100%

2格 75%

1格 50%

电池符 25%

电池符闪烁电量用尽，1分钟后自动关机

七、产品参数

LED环形灯

锂电池供电

Dc电源供电

功率

色温

100%光照度(LUX)

调光范围

灯珠数量

工作环境温度

产品尺寸

净重

LR160

2*7.4V锂电池(NP-F970接口)(需另购)

16V/1.5A

约18W

3300K-8000K

小于400(1 米)

10%~100%

160个

-10~50度

49.2*59*4cm

1.21Kg

Foreword

Warning

Thank you for purchasing this Godox Product!

This LED Ring Light LR160 is a continuous light with black color or pink color. Suitable

for almost all shooting occasions, which can offer lighting for live, make up, portrait

shooting, video, wedding, children photography, etc.

Features:

● High light brightness which can be freely adjusted its color temperature from 3300K-

8000K

● Stepless light brightness adjustment from 10%-100%.

Always keep this product dry. Do not use in rain or in damp conditions.

Do not disassemble. Should repairs become necessary, this product must be sent to

an authorized maintenance center.

Keep out of reach of children.

As this product do not have waterproof function, please take measures of waterproof

in rainy or damp environment.

Do not use the light unit in the presence of flammable gases, chemicals and other

similar materials. In certain circumstance, these materials may be sensitive to the

strong light emitting from this light unit and fire or electromagnetic interference may

result.

As this product has built-in lithium battery, do not disassemble, impact, squeeze or

put it into fire. If serious bulge occurs, please do not use. Do not use or store the

product if the ambient temperature reads over 50℃. Please charge the product with

specialized charger and correctly operate it within the defined voltage and working

temperate according to the instruction manual.

Observe precautions when handling batteries the defined voltage and working

temperate according to the instruction manual.

- Do not put batteries into a fire or apply direct heat to them.

- Batteries are prone to leakage when fully discharged. To avoid damage to the

product, be sure to remove batteries when the product is not used for a long time or

when batteries run out of charge.

- Should liquid from the batteries come into contact with skin or clothing, rinse

immediately with fresh water.

- 08 -

主机

0603

Body

01. Main Body

02. Power Switch

03. Select Dial for Light Brightness

04. Select Dial for Color Temperature

05. LCD Panel

06. Lock Buttons of Lights

07. Lithium Battery Compartment

08. DC Power Jack

09. Mounting Bracket

10. Heat Dissipation Slot

11. Smartphone Holder/

Mirror Installation Slot

12. Mounting Hole for Camera

Bracket

Light Brightness

Battery Level Indicator

Color Temperature

LCD Panel

- 07 -

(1) (2) (4)(3)

Included Items

1. LED ring light 2. Mirror 3. Adapter 4.Smartphone holder

Note:

* When using lithium battery, the Battery Level Indicator is displayed on the LCD panel. When the

indicator blinks, the lithium battery power is low. Please recharge it or replace the battery

immediately before usage in order to avoid forceful auto off.

Power Management

1. Power Supply

Two power supply modes are available:

(1) Using lithium battery: install two SONY NP-F970 model lithium batteries

(purchased separately) in the battery compartment.

(2) Using DC power jack: This light can be powered by DC power supply. Use a

charger to connect the light with the DC power supply.

- 08 -

主机

0603

Body

01. Main Body

02. Power Switch

03. Select Dial for Light Brightness

04. Select Dial for Color Temperature

05. LCD Panel

06. Lock Buttons of Lights

07. Lithium Battery Compartment

08. DC Power Jack

09. Mounting Bracket

10. Heat Dissipation Slot

11. Smartphone Holder/

Mirror Installation Slot

12. Mounting Hole for Camera

Bracket

Light Brightness

Battery Level Indicator

Color Temperature

LCD Panel

- 07 -

(1) (2) (4)(3)

Included Items

1. LED ring light 2. Mirror 3. Adapter 4.Smartphone holder

Note:

* When using lithium battery, the Battery Level Indicator is displayed on the LCD panel. When the

indicator blinks, the lithium battery power is low. Please recharge it or replace the battery

immediately before usage in order to avoid forceful auto off.

Power Management

1. Power Supply

Two power supply modes are available:

(1) Using lithium battery: install two SONY NP-F970 model lithium batteries

(purchased separately) in the battery compartment.

(2) Using DC power jack: This light can be powered by DC power supply. Use a

charger to connect the light with the DC power supply.

- 09 - - 10 -

Operation

1. Before Usage

Insert the lithium batteries or connect the light with the DC power supply.

2. Power ON/OFF

Long press the power switch to power the LED ring light on or off.

3. Light Brightness/Color Temperature Adjustment

Adjusting Light Brightness

* Turn the Select Dial for Light Adjustment to adjust the light brightness from 10% to

100%.

Battery Level Indication

(using lithium batteries)

3 grids

2 grids

1 grid

Battery icon

Blinking

LED Ring Light

Lithium Battery

DC Power Supply

Power

Color Temperature

100% Brightness (LUX)

Light Brightness Range

LED Beads Quantity

Operation Temperature

Dimension

Net Weight

LR160

2*7.4V Lithium battery(NP-F970)(separately sold)

16V/1.5A

Approx. 18W

3300K-8000K

Below 400 (1 meter)

10%~100%

160

-10~50°C

49.2*59*4cm

1.21Kg

4. Lock Buttons of Lights

There are four lock buttons for the four lights of the LED ring light. When the ring light

is powered on, press the lock button, and the corresponding light will be lightened.

5. LED Display

Light Brightness: from 10% to 100%.

Color Temperature: from 3300K to 8000K.

Battery Level Indicator(using lithium batteries):

Meaning

100%

75%

50%

25%

The battery level is going to be used out immediately.

And the flash will auto power off in 1 minute.

Technical Data

Adjusting Color Temperature

*Turn the Select Dial for Color Temperature to adjust color temperature from 3300K

to 8000K.

- 09 - - 10 -

Operation

1. Before Usage

Insert the lithium batteries or connect the light with the DC power supply.

2. Power ON/OFF

Long press the power switch to power the LED ring light on or off.

3. Light Brightness/Color Temperature Adjustment

Adjusting Light Brightness

* Turn the Select Dial for Light Adjustment to adjust the light brightness from 10% to

100%.

Battery Level Indication

(using lithium batteries)

3 grids

2 grids

1 grid

Battery icon

Blinking

LED Ring Light

Lithium Battery

DC Power Supply

Power

Color Temperature

100% Brightness (LUX)

Light Brightness Range

LED Beads Quantity

Operation Temperature

Dimension

Net Weight

LR160

2*7.4V Lithium battery(NP-F970)(separately sold)

16V/1.5A

Approx. 18W

3300K-8000K

Below 400 (1 meter)

10%~100%

160

-10~50°C

49.2*59*4cm

1.21Kg

4. Lock Buttons of Lights

There are four lock buttons for the four lights of the LED ring light. When the ring light

is powered on, press the lock button, and the corresponding light will be lightened.

5. LED Display

Light Brightness: from 10% to 100%.

Color Temperature: from 3300K to 8000K.

Battery Level Indicator(using lithium batteries):

Meaning

100%

75%

50%

25%

The battery level is going to be used out immediately.

And the flash will auto power off in 1 minute.

Technical Data

Adjusting Color Temperature

*Turn the Select Dial for Color Temperature to adjust color temperature from 3300K

to 8000K.

- 11 - - 12 -

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Any Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Instruction Manual | 说明手册Chinese English Bilingual | 中英文双语

705-LR1600-00

地址/Add: 深圳市宝安区福永镇福洲大道西新和村华发工业园A4栋

Building A4, Xinhe Huafa Industrial Zone, Fuzhou RD West, Fuyong

Town, Baoan District, Shenzhen 518103, China

电话/Tel: +86-755-29609320(8062) 传真/Fax: +86-755-25723423

邮箱/E-mail: [email protected]

http://www.godox.com

深圳市神牛摄影器材有限公司

GODOX Photo Equipment Co., Ltd.

Made In China

LED Ring Light

LED环形灯

LR160

Autres manuels pour LR160

Table des matières

Autres manuels Godox Équipement d'éclairage

Godox

Godox LED1000 Manuel utilisateur

Godox

Godox KNOWLED M600 Bi Manuel utilisateur

Godox

Godox Knowled M600D Manuel utilisateur

Godox

Godox ML30Bi Manuel utilisateur

Godox

Godox Knowled M300Bi Manuel utilisateur

Godox

Godox UL150II Manuel utilisateur

Godox

Godox AD200 Pro Manuel utilisateur

Godox

Godox SL Series Manuel utilisateur

Godox

Godox LED 36 Manuel utilisateur

Godox

Godox DS300II Manuel utilisateur

Godox

Godox Quicker600IIM Manuel utilisateur

Godox

Godox LR180 Manuel utilisateur

Godox

Godox ML60Bi Manuel utilisateur

Godox

Godox ML30 Manuel utilisateur

Godox

Godox SL150II Manuel utilisateur

Godox

Godox SL60II Bi Manuel utilisateur

Godox

Godox ST250 Manuel utilisateur

Godox

Godox LEDP260C Manuel utilisateur

Godox

Godox LEDM150 Manuel utilisateur

Godox

Godox Lux Junior Manuel utilisateur

Godox

Godox MG2400Bi Manuel utilisateur

Godox

Godox UL150 Manuel utilisateur

Godox

Godox LC500 Manuel utilisateur

Godox

Godox SZ200Bi Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
