Godox Witstro ad360II-c Manuel utilisateur

GODOX PHOTO EQUIPMENT CO.LTD

WITSTRO

TTL Powerful & Portable Flash

AD360II-C

Instruction Manual

Foreword

Before using this product

Please read this user manual carefully in order to ensure your safety and the proper operation of

this product. Keep for future reference.

Thank you for purchasing a GODOX product.

WITSTRO TTL Powerful & Portable Flash AD360II-C applies to Canon EOS series cameras and is

compatible with E-TTL II autoflash. With this E-TTL II compatible flash, your shooting will become

simpler. You can easily achieve a correct flash exposure even in complex light-changing

environments.

WITSTRO AD360II-C flash system is an AD360II-C flash with a bare tube, external power pack,

wireless manual power control, and a range of dedicated light shaping accessories. AD360II-C is 5

to 7 times powerful as typical hotshoe flashes with the size and weight alike. It offers studio

quality light for outdoor and live shooting. The AD360II-C offers:

Compatible with Canon E-TTL II: Fully support Canon E-TTL II camera flash. Workable as

Master or Slave unit in a wireless flash group.

Dot-matrix LCD panel: with clear and convenient operation.

Built-in 2.4G wireless transmission: with all-in-one functions and 100 meters further

transmission

Studio quality light: up to 360Ws, GN 80 (m ISO 100, with AD-S2 standard reflector).

Approx. 28mm flash coverage when operating on a camera with the standard reflector.

One AD360 can overpower the sun.

External battery pack: PB960 (lithium, 11.1V/4500mAh), 0.05-4.5s recycling and 450

full power flashes.

Lightweight and portable even with power and accessories

Wireless control on power levels and triggering (with FT-16 trigger)

Wide-range accessories: softbox, beauty dish, snoots, color gels, etc. All lighting

accessories fit for barebulb flashes from most brands.

Power adjusts from full power to 1/128 in 1/3 stop increments

Stable color temperature at 5600±200K over the entire power range

Multi flash, Focus-assist beam on/off & Hi-Speed sync triggering

The powerful and portable AD360II-C meets the demands of freelance commercial photographers,

photojournalists, wedding and beach portraiture shooters, event and backpack photographers,

photograph enthusiasts, etc. It is compatible with market-available cameras from Canon, Nikon,

Pentax, and Olympus, etc and fits for almost any flash trigger.

For Your Safety

1. Always keep this product dry. Do not use in rain or in damp conditions.

2. This product contains high-voltage electronic parts. Touching the high-voltage circuit inside it

may result in electric shock. Do not disassemble. Should repairs become necessary, this

product must be sent to an authorized maintenance center.

3. Stop using this product if it breaks open due to extrusion, falling or strong hit. Otherwise,

electric shock may occur if you touch the electronic parts inside it.

4. Do not fire the flash directly into the eyes (especially those of babies) within short distances.

Otherwise visual impairment may occur. When taking pictures for babies, keep the flash unit at

least 1 meter (3.3 feet) away from them. Using bounce flash to reduce light intensity is also

recommended.

5. Do not use the flash unit in the presence of flammable gases, chemicals and other similar

materials. In certain circumstances, these materials may be sensitive to the strong light

emitting from this flash unit and fire or electromagnetic interference may result.

6. Do not leave or store the flash unit if the ambient temperature reads over 50°C (e.g. in

automobile). Otherwise the electronic parts may be damaged.

7. Be cautious when using the AD360II-C on your camera. AD360II-C is slightly heavy so that an

AD360II-C on your camera may damage the camera hotshoe.

Contents

Foreword

For your safety

Name of Parts

Body

Control Panel

Included Accessories

Separately Sold Accessories

Installing Reflector (Other Accessories)

Attaching Flash Tube

Connecting to a Power Pack

Connecting the Flash to a Camera

Replacing the Off-Camera Adapter

Power Management

Flash Mode— E-TTL Autoflash

FEC (Flash Exposure Compensation)

FEB (Flash Exposure Bracketing)

FEL: Flash Exposure Lock

High-Speed Sync

Second-Curtain Sync

Flash Mode—M: Manual Flash

Flash Mode—Multi/Stroboscopic Flash

Wireless Flash Shooting: Optic Transmission

Wireless Settings

Master Unit’s Flash OFF

Setting the Communication Channel

ETTL: Fully Automatic Wireless Flash Shooting

ETTL: Use the Wireless Shooting of Flash Ratio

M: Wireless Flash Shooting with Manual Flash

Multi: Wireless Flash Shooting with Manual Flash

Wireless Flash Shooting: Ratio (2.4G) Transmission

Other Applications

Wireless Control Function

Modeling Flash

Auto Focus Assist Beam

Assist Beam Setting

Bounce Flash

Sync Triggering

PC Sync Socket Triggering

C.Fn: Setting Custom Functions

Control with the Camera’s Menu Screen

Protection Function

Technical Data

Troubleshooting

Firmware Upgrade

Compatible Camera Models

Maintenance

Conventions used in this Manual

This manual is based on the assumption that both the camera and camera flash’s power

switches are powered on.

Reference page numbers are indicated by “p.**”.

The following alert symbols are used in this manual:

The Caution symbol indicates a warning to prevent shooting problem.

The Note symbol gives supplemental information.

Name of Parts

Body:

01. Accessory Mount

02. Accessory Locking Ring

03. Flash Tube

04. Tube Socket

05. Umbrella Mounting Hole

06. Release Button

07. Power Socket

08. Wireless Control Port

09. Sync Cord Jack

10. PC Sync Socket

11. MF-Assist Beam

12. Light Sensor

13. Control Panel

14. Hotshoe Stand

15. Mini USB Port

Control Panel:

15 < MODE > Mode Selection Button

16. < > Wireless Selection Button

17. Select Dial

18. <SET > Set Button

19. ON/OFF Power Switch

20. < > Test Button / Flash Ready Indicator

21. Function Button 1

22. Function Button 2

23. Function Button 3

24. Function Button 4

LCD Panel

(1) E-TTL Autoflash

(2) M Manual Flash

(3) Multi Flash

(4)Radio Transmission Shooting/Optic Transmission Shooting

Master Unit

Slave Unit

The flash unit is not powered by itself, but draws power from Godox power pack PB960

(sold separately).

Included Accessories

1-Flash tube

1-Protecting bag

1-Mini stand

1-Off-camera adapter

1-Reflector

1-Power cable

The display will only show the settings currently applied.

The functions displayed above function buttons 1 to 4, such as and

, change according to settings’ status.

When a button or dial is operated, the LCD panel illuminated. (Page **)



2-Reflector diffuser

1-Instruction manual

Separately Sold Accessories

The product can be used in combination with the following accessories sold separately, so as to

achieve best photography effects:

X1C Wireless Flash Trigger, FT-16 Remote Control, Softbox, Beauty Dish, Fold up umbrella，

Snoots, Light stand, etc.

Installing Reflector (Other Accessories)

1. Rotate Accessory Locking Ring (2) counter-clockwise until it is loosen.

2. Insert the reflector into the Accessory Mount (1).

3. Rotate Accessory Locking Ring (2) clockwise to lock it up. Do not over-tighten.

Attaching Flash Tube

1. Remove the reflector or other accessories from the flash head.

2. Match the red dot on the base of the flash tube with the red dot in the Tube Socket (4). Push the

flash tube in until it is securely seated into the socket.

Connecting to a Power Pack

1. Before connecting, make sure that the power pack is turned off.

2. Plug one end of Power Cable into Power Socket (7) of the flash unit, and insert the other end

into the output socket of the power pack.

3. Turn on the power pack. Normally the flash unit will be fully charged and ready to work.

*The flash unit is not powered by itself, but draws power from Godox power pack PB960 (sold

separately).

*For the instructions of the power pack, see the related user manual.

Connecting the Flash to a Camera

1. Loosen the locking ring on the mounting foot.

2. Slip the mounting foot of the flash unit into the camera hotshoe.

3. Secure the flash unit by rotating the locking ring the direction of the row.

Replacing the Off-Camera Adapter

The off-camera adapter is useful when using the product as an off-camera flash. There is a 1/4″

mounting hole at the bottom of the off-camera adapter. To install the off-camera adapter,

1. Use a screwdriver (not included) to remove the four screws at the bottom of this product. Then

take out the bottom part carefully as illustrated.

2. Install the off-camera adapter at the bottom of this product.

3. Tighten all the screws.

Power Management

ON/OFF Power Switch (19) controls the on/off of the flash unit. Turn off the power pack if the flash

unit will not be used for an extended period (approx. 1 hour).

Flash Mode— E-TTL Autoflash



Disabling Auto Power Off function is recommended when the flash is used off camera.

(C.Fn-APO, Page 22)



This flash has three flash modes: E-TTL, Manual (M), and Multi (Stroboscopic). In E-TTL mode, the

camera and the flash will work together to calculate the correct exposure for the subject and the

background. In this mode, multiple TTL functions are available: FEC, FEB, FEL, HSS, second

curtain sync, modeling flash, control with the camera’s menu screen.

* Press <MODE> Mode Selection Button and three flash modes will display on the LCD panel one

by one with each pressing.

ETTL Mode

Press <MODE > Mode Selection Button to enter E-TTL mode. The LCD panel will display

<>.

● Press the camera release button halfway to focus. The aperture will be displayed in the

viewfinder.

● When the shutter button is fully pressed, the flash will fire a pre-flash that the camera will

use to calculate exposure and flash output the instant before the photo is taken.

FEC: Flash Exposure Compensation

With FEC function, this flash can adjust from -3 to +3 in 1/3rd stops. It is useful in situations where

minor adjusting of the TTL system is needed based on the environment.

Setting FEC:

1. Press Function Button 2 < >. The icon < > and flash exposure compensation

amount will be highlighted on the LCD panel.

2. Set the flash exposure compensation amount.

● Turn the Select Dial to set the amount.

● “0.3”means 1/3 step, “0.7”means 2/3 step.

● To cancel the flash exposure compensation, set the amount to “+0”.
