Gigabyte GA-6VX7-1394 Manuel utilisateur

FCC Compliance Statement:

This equipment has been tested and found to

comply with limits for a Class B digital device,

pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable

protection against harmful interference in

residential installations. This equipment

generates, uses, and can radiate radio frequency

energy, and if not installed and used in

accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference

will not occur in a particular installation. If this

equipment does cause interference to radio or

television equipment reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna

-Move the equipment away from the receiver

-Plug the equipment into an outlet on a circuit different from that to which the

receiver is connected

-Consult the dealer or an experienced radio/television technician for

additional suggestions

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void Your

authority to operate such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to

the following two conditions 1) this device may not cause harmful interference

and 2) this device must accept any interference received, including interference

that may cause undesired operation.

DECLARATION OF CONFORMITY

Per FCC Part 2 Section 2. 1077(a)

Responsible PartyName: G.B.T. INC.

Address: 18305 Valley Blvd., Suite#A

LA Puent, CA 91744

Phone/Fax No: (818) 854-9338/ (818) 854-9339

hereby declares that the product

Product Name:

Model Number:

Mother Board

Conforms to the following specifications:

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),

Class B Digital Device

Supplementary Information:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful

and (2) this device must accept any inference received, including

that may cause undesired operation.

Representative Person's Name: ERIC LU

Signature:

Date: Mar. 30, 2000

Eric Lu

GA-6VX7-1394

Declaration of Conformity

We, Manufacturer/Importer

(full address)

G.B.T. Technology Träding GMbH

Ausschlager Weg 41, 1F, 20537 Hamburg, Germany

declare that the product

( description of the apparatus, system, installation to which it refers)

Mother Board

GA-6VX7-1394

is in conformity with

(reference to the specification under which conformity is declared)

in accordance with 89/336 EEC-EMC Directive

EN 55011 Limits and methods of measurement EN 61000-3-2* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-2 by household appliances and similar

industrial, scientific and medical (ISM electrical equipment “Harmonics”

high frequency equipment

EN55013 Limits and methods of measurement EN61000-3-3* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-3 by household appliances and similar

broadcast receivers and associated electrical equipment “Voltage fluctuations”

equipment

EN 55014 Limits and methods of measurement EN 50081-1 Generic emission standard Part 1:

of radio disturbance characteristics of Residual, commercial and light industry

household electrical appliances,

portable tools and similar electrical EN 50082-1 Generic immunity standard Part 1:

apparatus Residual, commercial and light industry

EN 55015 Limits and methods of measurement EN 55081-2 Generic emission standard Part 2:

of radio disturbance characteristics of Industrial environment

fluorescent lamps and luminaries

EN 55020 Immunity from radio interference of EN 55082-2 Generic immunity standard Part 2:

broadcast receivers and associated Industrial environment

equipment

EN 55022 Limits and methods of measurement ENV 55104 Immunity requirements for household

of radio disturbance characteristics of appliances tools and similar apparatus

information technology equipment

DIN VDE 0855 Cabled distribution systems; Equipment EN 50091- 2 EMC requirements for uninterruptible

part 10 for receiving and/or distribution from power systems (UPS)

part 12 sound and television signals

CE marking (EC conformity marking)

The manufacturer also declares the conformity of above mentioned product

with the actual required safety standards in accordance with LVD 73/23 EEC

EN 60065 Safety requirements for mains operated EN 60950 Safety for information technology equipment

electronic and related apparatus for including electrical business equipment

household and similar general use

EN 60335 Safety of household and similar EN 50091-1 General and Safety requirements for

electrical appliances uninterruptible power systems (UPS)

Manufacturer/Importer

Signature : Rex Lin

(Stamp) Date: Mar.30, 2000 Name : Rex Lin

6VX7-1394

Socket 370 Processor Motherboard

USER'S MANUAL

Socket 370 Processor Motherboard

REV. 1.1 First Edition

R-11-01-000328

How This Manual Is Organized

This manual is divided into the following sections:

1) Revision History Manual revision information

2) Item Checklist Product item list

3) Features Product information & specification

4) Hardware Setup Instructions on setting up the motherboard

5) Performance & Block Diagram Product performance & block diagram

6) Suspend to RAM Instructions STR installation

7) BIOS Setup Instructions on setting up the BIOS

software

8) Appendix General reference

Table Of Content

Revision History P.1

Item Checklist P.2

Summary of Features P.3

6VX7-1394 Motherboard Layout P.5

Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition P.6

Performance List P.30

Block Diagram P.31

Suspend to RAM Installation P.32

Memory Installation P.38

Page Index for BIOS Setup P.39

Appendix P.67

6VX7-1394 Motherboard

Revision History

Revision Revision Note Date

1.1 Initialreleaseofthe6VX7-1394motherboarduser’smanual. Mar.2000

The author assumes no responsibility for any errors or omissions that may appear in this

document nor does the author make a commitment to update the information contained herein.

Third-party brands and names are the property of their respective owners.

Mar. 28, 2000 Taipei, Taiwan, R.O.C

Item Checklist

;The 6VX7-1394 motherboard

;Cable for IDE / floppy device

;Diskettes or CD (TUCD) for motherboard driver & utility

Internal COM B Cable (Optional)

Internal USB Cable (Optional)

Cable for SCSI device

;6VX7-1394 user’s manual

6VX7-1394 Motherboard

Summary Of Features

Form Factor y30.4 cm x 20.3 cm ATX SIZE form factor, 4 layers PCB.

CPU ySocket 370 processor

y2nd cache in CPU(Depend on CPU)

Chipset yVT82C694X (VIA Apollo Pro 133A)

yVT82C686A

Clock Generator yICS 9248DF-39

y66/100/133 MHz system bus speeds (PCI 33MHz)

y112/124/140/150 MHz system bus speeds

(PCI 44MHz) (reserved)

Memory y3 168-pin DIMM sockets.

ySupports PC-100 / PC-133 SDRAM and VCM SDRAM

ySupports up to 1.5GB(Max)

ySupports only 3.3V SDRAM DIMM

ySupports 72bit ECC type DRAM integrity mode.

I/O Control yVT82C686A

Slots y1 AGP Slot Supports 4X mode & AGP 2.0 compliant

y5 PCI Slot Supports 33MHz & PCI 2.2 compliant

y1 ISA Slot

y1 AMR(Audio Modem Riser)Slot

On-Board IDE y2 IDE bus master (DMA 33/ ATA 66) IDE ports for up

to 4 ATAPI devices

ySupports PIO mode 3, 4 (UDMA33/ATA66) IDE &

ATAPI

CD-ROM

On-Board

Peripherals y1 floppy port supports 2 FDD with 360K, 720K,1.2M,

1.44M and 2.88M bytes

y1 parallel ports supports SPP/EPP/ECP mode

y2 serial ports (COM A & COM B)

y4 USB ports

y3 IEEE 1394 port

y1 IrDA connector for IR

Hardware Monitor yCPU / System fan revolution detect

yCPU / System temperature detect

ySystem voltage detect (Vcore,+3V,+5V,+12V)

yCPU overheat shutdown detect

PS/2 Connector yPS/2 keyboard interface and PS/2 mouse interface

To be continued…
