Gigabyte GA-6JIEV2-RH Manuel utilisateur
USER’S MANUAL
GA-6JIEV2-RH
Intel®mini-ITX Motherboard
Intel® mini-ITXMotherboard
Rev.1001
* The WEEE marking on the product indicates this product must not be disposed of with
user's other household waste and must be handed over to a designated collection point
for the recycling of waste electrical and electronic equipment!!
* The WEEE marking applies only in European Union's member states.
Copyright
©2007 GIGA-BYTE TECHNOLOGYCO., LTD.All rights reserved.
Thetrademarksmentionedinthemanualarelegallyregisteredtotheirrespectivecompanies.
Notice
ThewrittencontentprovidedwiththisproductisthepropertyofGigabyte.
Nopart of thismanual may bereproduced, copied, translated,or transmitted inany form orby any
meanswithoutGigabyte'spriorwrittenpermission.Specificationsandfeaturesaresubjecttochange
withoutpriornotice.
Product Manual Classification
Inordertoassistintheuseofthisproduct,Gigabytehascategorizedtheusermanualinthe
following:
Fordetailedproductinformationandspecifications,pleasecarefullyreadthe
"Product User Manual".
FordetailedinformationrelatedtoGigabyte'suniquefeatures,pleasegoto"Technology
Guide"sectiononGigabyte'swebsitetoreadordownloadtheinformationyouneed.
Formoreproductdetails,please click onto Gigabyte'swebsiteatwww.gigabyte.com.tw
3
GA-6JIEV2-RH Motherboard Table of Content
Item Checklist .........................................................................................4
Chapter 1Introduction.............................................................................5
1-1Considerations Prior to Installation........................................................ 5
1.2Features Summary................................................................................. 6
1.3Motherboard Components.....................................................................8
Chapter 2Hardware Installation Process................................................9
2-1: Installing Memory Module....................................................................9
2-2: Connect ribbon cables, cabinet wires, and power supply................10
2-2-1 : I/O Back Panel Introduction................................................................................ 10
2-3: Connectors Introduction & Jumper Setting........................................13
2-4: Block Diagram...................................................................................24
Chapter 3 BIOS Setup ..........................................................................25
The Main Menu (For example: BIOS Ver. : F1).......................................................... 26
3-1 Standard CMOS Features........................................................................................ 28
3-2 Advanced BIOS Features ........................................................................................ 30
3-3 Integrated Peripherals ............................................................................................... 32
3-4 Power Management Setup ...................................................................................... 34
3-5 PC Health Status ....................................................................................................... 35
3-6 Frequency/Voltage Control ...................................................................................... 36
3-7 Load Fail-Safe Defaults............................................................................................. 37
3-8 Load Optimized Defaults........................................................................................... 37
3-9 Set Supervisor/User Password .............................................................................. 38
3-10 Save & Exit Setup .................................................................................................. 39
3-11 Exit Without Saving................................................................................................. 39
3-12 Flash BIOS Method Introduction ............................................................................ 40
4
Introduction
TheGA-6JIEV2-RHmotherboard
I/O Shield Kit
CDformotherboarddriver&utility
GA-6JIEV2-RHQuickReference Guide
Power cable x 1
B4P/S4P Cable x 1
OptionalPowerAdapterx 1
Item Checklist
*Theitemslistedaboveareforreferenceonly,andaresubjecttochangewithoutnotice.
5
GA-6JIEV2-RH Motherboard
Chapter 1 Introduction
1-1 Considerations Prior to Installation
Preparing Your Computer
The motherboard contains numerous delicate electronic circuits and components which can become
damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please follow the
instructions below:
1. Please turn off the computer and unplug its power cord.
2. When handling the motherboard, avoid touching any metal leads or connectors.
3. It is best to wear an electrostatic discharge (ESD) cuff when handling electronic components
(CPU, RAM).
4. Prior to installing the electronic components, please have these items on top of an antistatic pad or
within a electrostatic shielding container.
5. Please verify that the power supply is switched off before unplugging the power supply connector
from the motherboard.
Installation Notices
1. Prior to installation, please do not remove the stickers on the motherboard. These stickers are
required for warranty validation.
2. Prior to the installation of the motherboard or any hardware, please first carefully read the
information in the provided manual.
3. Before using the product, please verify that all cables and power connectors are connected.
4. To prevent damage to the motherboard, please do not allow screws to come in contact with the
motherboard circuit or its components.
5. Please make sure there are no leftover screws or metal components placed on the motherboard
or within the computer casing.
6. Please do not place the computer system on an uneven surface.
7. Turning on the computer power during the installation process can lead to damage to system
components as well as physical harm to the user.
8. If you are uncertain about any installation steps or have a problem related to the use of the product,
please consult a certified computer technician.
Instances of Non-Warranty
1. Damage due to natural disaster, accident or human cause.
2. Damage as a result of violating the conditions recommended in the user manual.
3. Damage due to improper installation.
4. Damage due to use of uncertified components.
5. Damage due to use exceeding the permitted parameters.
6. Product determined to be an unofficial Gigabyte product.
6
Hardware Installation Process
1.2 Features Summary
FormFactor 170mmx 170mm MiniITX formfactor, 8 layers PCB.
CPU SupportssingleIntel®ULV CeleronM processor
Supports1GHz
Chipset Intel®910GMLE MCH
Intel®ICH6M
Memory 1 x DDR2 DIMM SO-DIMM socket
Supportsupto2GB 400 memory
Supports 1.8V DDR2 DIMMs
I/O Control ITEIT8781F Super I/O
ExpansionSlots Supports 1 PCI slot 32-Bit/33MHz
Supports 1 mini card slot (PCI-E x1/ USB 2.0)
SATAController Intel®ICH6M
On-BoardGraphic BuildinIntel®910GMLEchipset
Sharedsystem memoryup to128MB
On-BoardSound Relteak®ALC883chipset
InternalConnector 2xSATA connectors
1 x IDE connector
1 x Serial connectors (COM)
1xfrontaudioconnector
1x USB 2.0connectors for additional2ports by cable
1xfrontpanelconnecctor
1x System fancableconnector
1 x CPU fan cable connector
RearPanel I/O 1 x DC power jack
1 x VGA port
3 x COM port
4 x USB 2.0 ports
1 x LAN RJ45 ports
1 HDAudio jacks (Line-out / MIC-in )
HardwareMonitor EnhancedfeatureswithCPUVcore,1.5Vreference,
VCC3 (3.3V) , VBAT3V, +5VSB, CPUA/B Temperature, and
SystemTemperatureValuesviewing
CPU/SystemFan RevolutionDetect
CPUshutdown whenoverheat
On-BoardLAN RealtekRTL8111CGbELANcontroller
Supports WOL, PXE
7
GA-6JIEV2-RH Motherboard
BIOS AWARD BIOS on 4Mb Flash ROM
AdditionalFeatures ExternalModem wake up
SupportsS1,S3, S4, S5underWindows Operating System
Wakeon LAN(WOL)
SupportsConsoleRedirection
Supports3-pinFancontroller
8
Introduction
1.3 Motherboard Components
LPT1
LVDS_CTL1
ITE
IT8781F
Intel
ICH6M
SATA2
SJ2
CPU
Intel
910GMLE
Relteak
ALC883
GPIO connector
F_USB1
IDE1
BIOS
PWR1
DC
Power
Jack
KB_MS1
VGA
COM
COM2
USB_LAN1USB
AUDIO1
DDR1
Realtek RTL8111C
SJ1
SATA1
Mini PCI-E
LVDS_CTL2
BAT1
F_PANEL1
COM4
9
GA-6JIEV2-RH Motherboard
2-1: Installing Memory Module
ThemotherboardsupportsDDR2memorymodule,wherebyBIOSwillautomaticallydetectmemory
capacityandspecifications.Thememorymoduleonlycanbeinsertedinonedirection.
Beforeinstallingthememorymodules,pleasecomplywiththefollowingconditions:
1. Pleasemakesurethecomputerpowerisswitchedoffbeforeinstallingorremoving
memorymodules.
Installation Steps:
Step1. AlignthememorywiththeDIMMmoduleandinserttheDIMMmemorymoduleintotheDIMM
slot.Pleasenotethatmemorymodulehasafoolproof insertiondesign.Amemorymodulecan
beinstalledInonlyonedirection.
Step2. Push down thememorytoseatitfirmly.
Table 1. Supported DIMM Module Type
Size Organization RAM Chips/DIMM
256MB 8MB x 8 x 4 bks 8
16MB x 16 x 4bks 16
512MB 16MB x 8 x 4bks 8
32MB x 16 x 4bks 16
1GB 32MB x 8 x 4bks 8
64MB x 16 x 4bks 16
2GB 32MB x 8 x 4bks 8
64MB x 16 x 4bks 16
Chapter 2 Hardware Installation Process
10
Hardware Installation Process
2-2: Connect ribbon cables, cabinet wires, and power
supply
2-2-1 : I/O Back Panel Introduction
