Gigabyte 6BXS Manuel utilisateur

R-01-03-080604

6BXS

USER'S MANUAL

1. System power on by PS/2 Mouse: First, enable this function

in CMOS Setup, then you can power on the system by

double clicking the right or left button of your PS/2 Mouse.

2. System power on by Keyboard: If your ATX power supply

supports larger than 720 mA 5V Stand-By current, you can

power on your system by entering password from the

Keyboard after setting the “Keyboard power on”jumper (JP1)

and password in CMOS Setup.

3. Modem Ring-On on COM B.

4. Wake-up on LAN supports(on JP7): Your ATX power supply

must support larger than 600 mA 5V Stand-By current.

5. Support 3 steps ACPI LED.

6. Support LDCM



Pentium



II Processor MAINBOARD

REV. 1.0 Third Edition

6BXS

The author assumes no responsibility for any errors or omissions that may

appear in this document nor does it make a commitment to update the

information contained herein.

Third-party brands and names are the property of their respective owners.

Sound Blaster is a registered trademark of Creative Technology Ltd in the

United States and certain other countries. Sound Blaster-LINK and SB-LINK

are trademarks of Creative Technology Ltd.

May 7, 1998 Taipei, Taiwan

Quick Installation Guide

I. Quick Installation Guide :

CPU SPEED SETUP

The system bus speed can be selectable between 66.6MHz and 100MHz. The

user can select the system bus speed (JP5) and change the DIP SWITCH

(SW) selection to set up the CPU speed for 200 - 633MHz processor.

The CPU speed must match with the frequency RATIO. It will cause

system hanging up if the frequency RATIO is higher than CPU's.

DIP SWITCH (SW)

FREQ. RATIO 1234

X 3 ON OFF ON ON

X 3.5 OFF OFF ON ON

X 4 ON ON OFF ON

X 4.5 OFF ON OFF ON

X 5 ON OFF OFF ON

X 5.5 OFF OFF OFF ON

MJP5 (Select the system speed between 66.6MHz and 100MHz)

1-2 Close Set system speed to 66MHz

−

system always

run at 66MHz FSB (Front Side Bus).

2-3 Close Set system speed to Auto

−

auto detect

system speed (66/ 100MHz FSB)

1-2-3 Open Set system speed to 100MHz

−

system always

run at 100MHz FSB (Front Side Bus).

1 2

6BXS

MThere are two ways to set system speed

A. 66MHz forced (JP5 1-2 short) or Auto detect (2-3 short)

B. 100MHz forced (JP5 1-2-3 open) or Auto detect (2-3 short)

1. PentiumII 300 / 100MHz FSB

6BXS 1

BIOS

INTEL

443BX

PIIX4

adaptec

AIC-7880P

1 2 3 4

JP5

1 2 3

JP5

1 2 3

2. PentiumII 350 / 100 MHz FSB

3. PentiumII 400 / 100 MHz FSB

1 2

JP5

Quick Installation Guide

4. PentiumII 450 / 100 MHz FSB

5. PentiumII 233 / 66 MHz FSB

6. PentiumII 266 / 66 MHz FSB

7. PentiumII 300 / 66 MHz FSB

1 2

JP5

6BXS

II. Jumper setting :

SPK : Speaker Connector

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Pin No. Function

VCC

3NC

Data

RST : Reset Switch

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Open :

Normal operation.

For Hardware

Reset System

Close :

Quick Installation Guide

PWR : Power LED Connector

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Pin No. Function

LED (+)

LED (-)

HD : IDE Hard Disk Active LED

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Pin No. Function

LED (+)

LED (-)

6BXS

IR : Infrared Connector (Optional)

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Pin No.

Function

IR Data Output

IR Data Input

GND

Signal

POWER (+)

GN : Green Function Switch

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Open :

Normal operation.

Close :

Entering Green Mode

Quick Installation Guide

SOFT PWR : Soft Power Connector

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4

Pin No. Function

2GND

Ctrl-signal

ATX POWER : ATX Power Connector

Pin No. Function

3,5,7,13,15-17

4,6,19,2

GND

+12V

-12V

-5V

VCC (+5V)

Power Good

5V SB

(Stand by +5V)

PS-ON

(Soft ON/OFF)

6BXS 1

BIOS

INTEL

443BX

adaptec

AIC-7880P

PIIX4
