Genius VIDEOCAM EYE Manuel utilisateur

English

-1-

1. Please install the driver first and then connect VideoCAM

Eye to the USB port.

2. Installing the VideoCAM Eye driver

Windows Environment

a. Insert the VideoCAM Eye Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install DirectX from the CD.

Notice: If theAutorun screen doesn’t start, please follow these

steps:

zClick on “Start Menu”

zType D：\SETUP.EXE , then click Enter key.

(Assume your CD-ROM is in Drive D)

Mac Environment

a. Insert the VideoCAM Eye Installation CD into the CD-ROM

drive.

1 SnapShot Button

2 LED Indicator

3 Lens

4 Swivel Base

VideoCAM Eye Features

Installing the VideoCAM Eye

English

-2-

b. Double click on the CD-ROM drive

c. Click on the file folder of “VideoCAm Eye Driver OSX 1.0”

d. Click on “VideoCAM Eye Driver Install” then simply follow

the on-screen instructions.

3. Insert the VideoCAM Eye’s USB cable to your desktop’s or

laptop’s USB port.

4. Complete software and hardware installation. You can

install the software you would like to use for video

conferencing or chat with your friends.

NOTE

To remove the driver installation:

Windows Environment:

Please go to the taskbar and follow “Start ÆProgram ÆVideoCAM Eye

ÆClick “Uninstall”, then follow the on-screen instructions to remove the

driver.

Mac OSX Environment:

Please put the VideoCAM Eye installation CD into CD-ROM drive Ægo to

the file folder of “VideoCAM Eye Driver OSX 1.0” ÆClick on “VideoCAM

Eye Uninstall” ÆFollow the on-screen instructions to remove the driver.

English

-3-

You can use our software to capture the real-time image, record or

execute the simply security function.

To run the software, please go to the taskbar and follow “Start”ÆClick

“Program”ÆChoose “VideoCAM Eye”ÆClick “VideoCAM Eye. Or

you may execute the software by simply clicking the shortcut of

“VideoCAM Eye”

NOTE

After installing the driver of VideoCAM Eye, the system will automatically

create a file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images

you take using the Genius Application.

1. Description for the major icon

Preview mode

Snapshot mode

Video Clip Mode

Security monitoring system

Exit the Genius VideoCAM Series UI

Genius Application (Windows Only)

English

-4-

Camera Control

NOTE

In the camera control section, you can personalize your camera

settings for different circumstances.

Camera Control:

You can set different values for

different circumstances and

environment

-Press “Default” to return to

the manufacturer’s settings.

Video Proc Amp:

In the section, you can adjust

different values toward image

itself.

-Press “Default” to return to

the manufacturer’s settings.

English

-5-

Advanced setting:

Select the correct frequency

according to the country where

you are using the web camera.

Also, you can have different

compression choices for your

images.

-Press “Default” to return to

the manufacturer’s settings.

2. Preview Mode

You can use the function buttons on the control panel to zoom in/out and

move upward/downward/left/right.

English

-6-

Zoom in the image

Zoom Out the image

Move the image upward

Move the image downward

Move the image to the left

Move the image to the right

Resolution Selection

There are 2 categories of resolution: RGB24 and

I420. You can select 5 different image resolutions for

each of them. The file size of I420 will be smaller than

RGB24. So, I420 may be the better choice for

transmission.

3. SnapShot Mode

You can press the Snapshot button in the right of the circle to take a

picture right away and share with your friends.

English

-7-

Send photo by e-mail

Shoot Continuously

Zoom in the image

Zoom Out the image

Move the image upward

Move the image downward

Move the image to the left

English

-8-

Move the image to the right

Resolution selection

This section shows the resolution you selected in

the “Preview Mode”. If you want to change the

resolution, please click “ “to go back to the

“Preview Mode” to make the changes.

NOTE

You can zoom in/out or move the image to the position you would like,

and then take pictures.

4. Video Clip Mode

You can record real-time image in this section.

Send photo by e-mail

English

-9-

Convert AVI files into MEPG-1 format

Start recording

Stop recording

Exit the Video Clip Mode

To Create animation

Press to start; Press to stop

Press to return to the video recording mode

This function has to be under the resolution of RGB320 x 240

or I420 320 x 240. Please make sure the resolution is correct

before executing this function.

Resolution selection

This section shows the resolution you selected in the “Preview

Mode”. If you want to change the resolution, please click

““to go back to the “Preview Mode” to make the changes.

5. Security Monitoring System

This Function records any movements that appear in front of your monitor

automatically. It can also record anytime until the HD is full. If there’s no

movement, it will shut down automatically after four seconds or until it

detects new movement. It’s a great security monitoring system and you can

English

-10-

set the software so it works at times when you’re not around.

A. Start recording

B. Stop recording

C. Setup time of the security monitoring system

Set up the degree of the variance for every

second of recording image. When the differences

are over the setup degree, the system will alert

you.

E. Set up the different alerting sound effects

NOTE

In “Security Monitoring System” section, you can record in any size of

image resolution. If you want to change the resolution, please click
