Genie HDED2812IR Manuel utilisateur

HDED2812IR

HDED2812IRW

HD-SDI Eyeball Dome Camera

User Manual

HD SDI Eyeball Dome Camera User Manual

Getting To Know The Camera

Mounting

Contents

HD SDI Eyeball Dome Camera User Manual

To access the OSD Menu, press the SET button and the SET UP menu appears as shown on the screen.

Move the arrow to select functions by using the UP/DOWN & LEFT/RIGHT buttons.

OSD Menu Function

1.0 EXPOSURE:

LENS: ALC / ELC

BRIGHTNESS: 0~20

SHUTTER: AUTO / FLICKER / MANUAL

SENS-UP: X2 / X3 / X4 / X5 / X6 / X7 / X8 / OFF

DEFOG: OFF / ON

AGC: 0~20

RETURN

1.1 LENS: ALC

MODE: OUTDOOR / INDOOR / DEBLUR

RETURN

1.2 LENS: ELC

MODE: NORMAL / DEBLUR

RETURN

1.3 SHUTTER: MANUAL

SPEED: 1/30 / 1/60 / 1/120 / 1/240 / 1/500 /

1/1000/ 1/2000 / 1/4000 / 1/8000 / 1/16000 /

1/30000 / 1/60000

RETURN

1.4 DEFOG: ON

MODE: AUTO / MANUAL

LEVEL: MIDDLE / LOW / HIGH

RETURN

HD SDI Eyeball Dome Camera User Manual

2.0 BACKLIGHT: OFF / WDR / BLC / HLC

WEIGHT: MIDDLE / LOW / HIGH

RETURN

2.1 BLC:

H-POS: 0~20

V-POS: 0~20

H-SIZE: 0~20

V-SIZE: 0~20

RETURN

2.2 HLC:

LEVEL: 0~20

MODE: ALL DAY / NIGHT ONLY

RETURN

3.0 DAY&NIGHT:

MODE: B&W / COLOR / AUTO / EXTERN

ANTI-SAT.: 0~20

AGC THRES: 0~20

AGC MARGIN: 0~20

DELAY: LOW / MIDDLE / HIGH

RETURN

4.0 WHITE BAL: AUTO / MANUAL /

PRESET / AUTOext

KELVIN: MIDDLE / LOW / HIGH

R-GAIN: 0~20

B-GAIN: 0~20

RETURN

5.0 DNR: MIDDLE / LOW / OFF / HIGH

6.0 IMAGE:

6.1 SHADING: ON

WEIGHT: 1%~100%

RETURN

HD SDI Eyeball Dome Camera User Manual

6.2 PRIYACY: ON

ZONE NUH: 0~5

ZONE DISP: ON / OFF

H-POS: 0~60

V-POS: 0~40

H-SIZE: 0~40

V-SIZE: 0~40

Y LEVEL: 0~20

CR LEVEL: 0~20

CB LEVEL: 0~20

RETURN

6.3 MOTION: ON

MOTION

SENSITIVITY: 0~20

WINDOW: 0~6

DET H-POS: 0~60

DET V-POS: 0~40

DET H-SIZE: 0~60

DET V-SIZE: 0~40

MOTION OSD: OFF / ON

ALARM: OFF / ON

RETURN

7.0 SYSTEM:

COM:

OUTPUT MODE: 1080P / 720P / 720P CROP

FRAME RATE: 30 FPS / 25 FPS / 50 FPS / 60FPS

CVBS: PAL / NTSC

LANGUAGE: ENG / CHN / ITA / GER / FRA / SPA /

HOL / JPN

RESET: ON

RETURN

8.0 COM:

CAM ID: 0~255

BAUDRATE: 115200 / 9600 / 4800 / 2400

RETURN

8.1 EXIT

HD SDI Eyeball Dome Camera User Manual

Specication

Model Number HDED2812IR HDED2812IRW

Image Sensor 1/3” Panasonic 2MP CMOS

Lens 2.8 - 12mm 3MP DC Lens

Minimum Illumination Colour: 1.0 Lux, B&W: 0.5 Lux,

Colour DSS: 0.002 Lux, B&W DSS: 0.001 Lux

S/N Ratio More Than 50dB (AGC Off)

Shutter Speed N: 1/30 ~ 1/60000 Sec, P: 1/25 ~ 1/60000 Sec

CVBS PAL

Sensitivity 0 ~ 20 Steps

Sharpness 0 ~ 10 Steps

White Balance AUTO / MANUAL / PRESET / AUTOext

ALC OUTDOOR / INDOOR / DEBLUR

DNR MIDDLE / LOW / OFF / HIGH

Defog OFF / ON

Delay LOW / MIDDLE / HIGH

Sync. System Internal / External (V-Lock)

Resolution 1080p / 720p

Exposure AUTO / MANUAL

Digital Slow Shutter OFF / MAX. x2 ~ x8

Lens Control ALC / ELC

Privacy Day & Night

Shutter AUTO / MANUAL

Sens-Up OFF / x2 ~ x8

Flip ON / OFF

Mirror ON / OFF

Gamma 0.55 / 0.6 / 0.65 / 0.45 / 0.5

Image Range FULL / COMP / USER

DIS OFF / ON

System COM / IMAGE RANGE / OUTPUT MODE / FRAME RATE /

CVBS / LANGUAGE / RESET

Setup Status Setup Status List

IR-Cut Filter Available

IR Range 25 - 35m (In Ideal Conditions)

LED Quantity 36 Pcs

Phase N: 0 ~ 131 Steps, P: 0 ~ 156 Steps

Defect Detection One Push

Baudrate 115200 / 9600 / 4800 / 2400

Display Settings ID / Title / Zoom Ratio

OSD Text 0 ~ 9, A ~ Z, a ~ z

Language ENG / CHN / ITA / GER / FRA / SPA / HOL / JPN

Power Consumption DC12V / MAX: 240mA

IP Rating IP66

Operating Conditions Temperature: -10°C ~ +50°C, Humidity: 0 ~ 86 % (Non-Condensing)

Storage Temperature -20°C ~ +60°C

Dimensions (W x D) 120 x 120 x 96mm

Weight 800g

HD SDI Eyeball Dome Camera User Manual

GENIE CCTV LTD.

CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT

Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543

www.geniecctv.com

Edition. GN-November 2013
