Genie IR3040 Manuel utilisateur
IR3040 | IR5070 | IR80100
Night Vision Lamps with Super Infra-Red LED’s
User Manual
Night Vision Lamps
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE
Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference
at their own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
This Infra-Red illuminator should only be installed by qualified personnel.
There are no user serviceable parts inside.
Do not disassemble this illuminator other than to make initial adjustments.
Only use a CE approved regulated AC24V (Genie PSU24/2) or DC12V (Genie
PSU35SM) power supply
Use appropriate low voltage power cable to prevent fire or electrical shock
Ensure your chosen installation location is able to support the weight of the illuminator,
and that adequate fixing screws are used.
CAUTION : To prevent electric shock and risk of fire hazards:
• Do NOT use power sources other than those specified.
Night Vision Lamps
3
Key Features
Technical Specication
• Standalone LED Illuminator
• Three Different Models
• Weatherproof Enclosure
• Extremely Adaptable Bracket – Three Axis Movement
• Easy to Install
• Compact Footprint
• Can be Switched to Permanently ON for Applications Requiring Continuous IR
• External 0V Relay Output
• Adjustable IR Level
• Dual Voltage, AC24V/DC12V
Model Number IR3040 IR5070 IR80100
Sensor CDS Photocell
Light Level (IR LED’s On) 5-10 Lux
IR Range (Optimum) 30-40m 50-70m 80-100m
IR LED’s 210x 5mm 144x 8mm 60x 10mm
IR Wavelength 850nm
IR Intensity Adjustable
External Trigger 2-Wire Relay Output, 0V
Power Supply AC24V/DC12V
Power Consumption AC24V: 620mA
DC12V: 1300mA
AC24V: 450mA
DC12V: 900mA
AC24V: 500mA
DC12V: 950mA
Temperature Range -20°C ~ +60°C
Environmental IP67
Dimensions 190 (W) x 133 (H) x 254 (D) mm
Weight 1.66Kg 1.68Kg 1.68Kg
GENIE CCTV LTD.
CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT
Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543
www.geniecctv.com
Edition. GN-July 2013
