Gefen HDMI Switcher Manuel utilisateur

HDMI Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 884-6294

(800) 545-6900

Fax (818) 884-3108

Technical Support Hours:

9:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

C/O Customer Service

6265 Variel Ave.

Woodland Hills, CA91367-9897

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

HDMI Switcher is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the HDMI Switcher

RMT2-IR Installation

IR Conﬂict Codes

IR Extender Installation

Speciﬁcations

Warranty

Congratulations on your purchase of the ex•tend•it HDMI Switcher. Your complete satis-

faction is very important to us.

Gefen’s line of HDMI switches, extenders, and splitters are designed to make yourA/V

equipment use more comfortable, more productive and less expensive.

The HDMI Switcher allow access to multiple HDMI devices, using a single HDMI display

while the HDTV extender product line can extend HD video signal up to 1640 feet (500

meters).

The ex•tend•it line offers solutions for noise, space and security concerns, data center

control, information distribution, conference room presentation, school and corporate

training environments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime of support from a team of outstanding engineers.

The ex•tend•it HDMI Switcher allows two HDMI devices to be switched easily in to one

HDMI compatible monitor or projector. The HDMI Switcher can also be placed at the

end of a long HDMI cable to regenerate the HDMI signal.

INTRODUCTION

FEATURES

Features

• Switches easily between any two HDMI sources

• Maintains 480i, 480p, 720p, 720i, and 1080i, 1080p resolutions

• Extends any HDMI compliant device by regenerating the HDMI signal

• Maintains high resolution video—beautiful, sharp HDTV resolutions up to 1080P

are easily achieved. For computer users, the 2x1 HDMI Switcher conforms with HDMI

speciﬁcations for resolutions up to 1920 x 1200.

• Supports DDWG standard for HDMI compliant monitors

• Supports HDCP compliant devices

• Optional RMT-2 remote control

• Installs in seconds

Includes:

2x 6’ HDMI cables (m-m)

5VDC Power Supply

RMT2-IR

The HDMI Switcher

PANEL DESCRIPTIONS

Connects to

5VDC power supply

Connects to IR

extender IR eye Indicates if port 1 or

port 2 is selected Selects port 1

or port 2

HDMI In 2

HDMI In 1 HDMI Out

CONNECTING AND OPERATING THE HDMI Switcher

How to Connect the HDMI Switcher to your devices

1 Connect the supplied HDMI to HDMI cables from the HDMI sources into the HDMI

Switcher Input.

2Connect the cable from your display (monitor or projector) into the HDMI Out of the

HDMI Switcher.

3Plug the 5VDC power supply into the HDMI Switcher.

How to Operate the HDMI Switcher

1 Use the front panel push button to switch between sources.

2 Alternatively, use the RMT2-IR remote control port to remotely toggle between sources.

RMT2-IR INSTALLATION

1. Remove battery cover from the back of the RMT2-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT2-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT2-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

The optional IR extender allows you to re-

locate your HDMI Switcher and still have IR

control of the HDMI Switcher

IR Code Conﬂicts

How to Resolve IR Code Conﬂicts

There are matching pairs of dip switches underneath the Switcher unit (outlined below)

and under the remote battery cover. Each has two switches which need to be matched for

the remote to work. There are 4 possible sets of IR codes and at least one of these sets

should be able to resolve any IR conﬂicts with other home theater devices.

IR Extender Installation

How to Connect the IR Extender

1 Plug the IR extender into the Remote port on the front of the Switcher Unit

2Flip the Dip Switch #1 underneath the unit from the set that is not outlined on the

previous page to the ON position
