Gefen 4x2 DVI Switcher Manuel utilisateur

4x2 DVI Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen, Inc.

c/o Customer Service

20600 Nordhoff Street

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

The 4x2 DVI Switcher is a trademark of Gefen Inc.

Macintosh is a trademark of Apple Computer Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Front Panel Descriptions

Back Panel Descriptions

How To Connect The 4x2 DVI Switcher

RMT-4IR

System Speciﬁcations

Warranty

READ THESE NOTES BEFORE INSTALLING

OR OPERATING THE 4X2 DVI SWITCHER

• If two monitors are connected to the switcher, both monitors must have the same na-

tive resolution.

• The 4x2 DVI Switcher is housed in a metal box for better RF shielding.

OPERATION NOTES

INTRODUCTION

ThankyouforpurchasingGefen’sex•tend•it4x2DVISwitcherseries.The4x2DVISwitcher

switches DVI, USB and audio between any combination of four computers. Now you can

switcheasilyand reliably betweenany combination offourcomputers using oneortwo DVI

display, USB keyboard and mouse. The 4x2 DVI Switcher is switched using the RMT-4IR.

The 4x2 DVI Switcher saves space – there’s no need to work on a desk crowded with four

monitors,keyboards and mousedevices. It savestime –there’snoneed to movefrom one

monitor to another to access different computers. And it saves money – there’s no need

to purchase additional monitors, mouse devices, keyboards etc. The 4x2 DVI Switcher

allows you to choose between any combination of Macintosh or PC computers.

CONTENTS

The 4x2 DVI Switcher system consists of:

--- (1) 4x2 DVI Switcher

--- (1) RMT4-IR remote control

--- (1) 5 VDC power supply

--- (4) DVI cables (6FT)

--- (4) USB cables (6FT)

--- (4) Audio cables (6FT)

--- (1) User Manual

1-4Indicator LED

Power LED

Infrared Eye

FRONT PANEL DESCRIPTIONS

BACK PANEL DESCRIPTIONS

POWER

INPUT DVI IN 1 DVI IN 2 DVI OUT DVI OUT 1 DVI IN 4 USB OUT

4 USB INPUTS

REMOTE -

RJ-45 Connecter

For RMT-4 Wired

Remote

AUDIO IN 1 AUDIO IN 2 AUDIO IN 3 AUDIO IN 4 AUDIO OUT

DVI OUT 2

Connect your computers DVI, USB, and audio to the 4x2 DVI Switcher inputs using

the supplied cables.

Connect one or two DVI monitor to the DVI Out. If only one monitor is connect you

must use DVI Out 1.

Connect your USB and audio devices to the USB and audio outputs.

Connect the RMT-4 remote control (if applicable).

Plug the 5VDC power supply into the 4x2 DVI Switcher.

Your computers must be turned on one at a time and the switcher must be selected

to the computer that is booting up.After one computer completes the startup process,

you can boot up the second computer and repeat the process with the remaining

computers.

HOW TO CONNECT THE 4X2 DVI SWITCHER

RMT-4IR

1. Remove battery cover from the back of the RMT4-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT4-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

4X1 DVI/ADC WIRING DIAGRAM
