Gefen Firewire 800 Manuel utilisateur

Firewire 800

Extender

USER MANUAL

www.gefen.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone (818) 884-6294

(800) 545-6900

Fax (818) 884-3108

Technical Support Hours:

8:00am to 5:00pm

Monday thru Friday

Write To:

Gefen, Inc.

C/O Customer Service

6265 Variel Avenue

Woodland Hills, CA 91367-9897

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

Firewire 800 Extender is a trademark of Gefen Inc.

Macintosh is a trademark of Apple Computer Inc.

TABLE OF CONTENTS

Introduction

Features

Firewire 800 Series Installation

Firewire 800 Extender Panel Layout

Firewire 800 Extender Function Description

Wiring Diagram

 Specications

Warranty

Thank you for purchasing the ex•tend•it Firewire Extender Series. Extending

your Firewire peripherals (i.e. camcorders or hard drives) up to 1640 feet away from

the location of your Macintosh or PC computer are done easily with the Firewire 800

Extender.

The Firewire 800 Extender system consists of two units. The Firewire 800 Extender

sender resides next to the host computer, and the Firewire 800 Extender receiver is

linkedtothesendervia2-strandLC-LCberopticcableandresidesatthedesired

location away from the computer.

FiberopticscablesareusedtoconnectoneFirewireExtenderunittoanother

Firewire Extender unit. The Firewire Extender keeps your desk clutter-free, allowing the

relocation of your computer to a safe and secure area, while allowing you to work in a

quieter environment.

You can connect additional Firewire 800 Extender systems to the same computer,

allowing you to access the computer from multiple locations up to 1640 feet apart.

INTRODUCTION

FEATURES

* ExtendsFirewire1394bupto1640feet

*Fiberopticcablesused

* Allows remote devices to operate in real-time, connected to the source

*Backwardscompatiblewith1394a-2000&1995

*Offers800(S800),400(S400),200(S200),and100(S100)Mbpsinfullduplexdata

rate.

*OfferstwoelectricalbilingualportsandanopticalduplexLCreceptacle,mostpopular

standardconnectorinber-opticindustries.

* Low power consumption: less 6W

*FreeRFnoisesandEMIfromber

* Installs in seconds, no software to install

Includes:

2x6'Firewire400to800cable(M-M)

1x6'Firewire800to800cable(M-M)

1x 12 VDC Powersupply

1x Firewire 800 Extender

HOW TO CONNECT THE FIREWIRE 800

1.ConnectthesuppliedFirewirecablefromthecomputersFirewireportintooneof

Firewire 800 Extender unit. (Either unit will work as a sender or a receiver.)

2.ConnecttheberopticscablefromoneFirewire800Extenderunittotheother

Firewire 800 Extender unit.

3. Connect your Firewire devices into the Firewire 800 Extender at the remote location

(unit).

4. Plug the 12 volt power supply into the Firewire 800 Extender unit at the remote loca-

tion only.

5. Restart your computer only after you’ve made all the connections.

FIREWIRE 800 EXTENDER PANELS LAYOUT

1 2

654

DC IN - Power plug for 12VDC Wallmount power supply.

Firewire 1 - ConnectstoFirewireHub,orFirewireDevice.

Firewire 2 - ConnectstoFirewireHub,orFirewireDevice.

Power LED - Indicates the unit is plugged in and powered up.

Status LED - Indicates Sender and Reciever are connected

Tx/Rx - LC-LC Optical Jack which connects to the Firewire 800 Extender send

and the Firewire 800 Extender Receive units.

*CableRequirement-50or62.5micronmultimodeberopticscable

FIREWIRE 800 EXTENDER FUNCTION DESCRIPTION

WIRING DIAGRAM

CPU

Firewire Extender

Sender

Firewire Extender

Receiver

Digital Video

Camrecorder

Fiber Optics

Cable
