Gefen CAT5-5500HD Manuel utilisateur
CAT-5 Cables
DVI Cables
Optional
Accessories
CAT5•5500HD
Extends two DVI and USB up to 200 feet (60 meters) away
The Professional Series CAT5•5500HD extends your dual DVI displays and USB up to 200 feet
away from your DVI or HDMI™ source. The CAT5•5500HD is now available with a built in 4 port
USB hub on the receiver unit.
How It Works
The CAT5•5500HD sender unit sits next to your computer. The cables supplied with the
CAT5•5500HD connects your DVI source(s) and USB to the sender unit. The CAT5•5500HD
receiver unit sits next to your DVI displays - up to 200 feet away. The displays and USB plug into
the back of the CAT5•5000HD receiver unit. Four CAT-5 cables connect the CAT5•5500HD-S and
the CAT5•5500HD-R units to each other.
Note: The CAT5•5500HD is HDCP compliant.
DVI, HDCP & HDMI Defined
Features:
zExtends any DVI compliant device up to 150 feet (45 meters) from the computer at
1920x1200
zExtends any DVI compliant device up to 200 feet (60 meters) from the computer at
1280x1024
zExtends USB 1.1 compliant devices up to 200 feet
zUses CAT-5e cable for DDC and control signals
zVideo is transmitted digitally for zero signal loss
zSupports resolutions up to 1080p, 2K, and 1920 x 1200
zSupports DDWG standard for DVI compliant monitors
zIncludes rack ears
zHDCP compliant
Specifications:
zVideo Amplifier Bandwidth: 165 MHz
zSingle Link Range: 1080P/1920 x 1200
zInput Video Signal: 1.2 volts p-p
zInput DDC Signal: 5 volts p-p (TTL)
zDVI Connector: DVI-I (29 pin) female (digital only)
zUSB Input: USB type "B" connector
zUSB Output: two USB type "A" connectors
zLink Connector: RJ-45 Shielded
zPower Supply: 5V DC
zPower Consumption: 20 watts (max)
zDimensions: 17" W x 1.75"H x 4.375" D
zShipping Weight: 10 lbs.
Package Includes:
zCAT5•5500HD-S
zCAT5•5500HD-R
zTwo 6 foot DVI cables
zOne 6 foot USB cable
zTwo 5V Power Supply
zUser's Manual
EXT-CAT5-5500HD
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl e-mail: [email protected]
Cat5 • 5500HD
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
The CAT5 5500HD is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
Introduction and Operation Notes
Features
How It Works
CAT5•5500HDS Back Panel Layout
CAT5•5500HDS Back Panel Function Descriptions
CAT5•5500HDR Back Panel Layout
CAT5•5500HDR Back Panel Functions Descriptions
Link Cable Wiring Diagrams
CAT5•5500HD - Wiring Diagram
Service Switch Usage Guide
Frequently Asked Questions
Terminology
System Specifications
Warranty
1
2
3
4
5
6
7
8
9
10
11
12
13
14
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE CAT5•5500HD SYSTEM
* The CAT5•5500HD units are housed in a metal box for better RF shielding.
* Your CAT-5 cable should not exceed 200 feet.
OPERATION NOTES
INTRODUCTION
Thank you for purchasing the new ex•tend•it CAT5•5500HD series by Gefen, Inc.
The ex•tend•it CAT5•5500HD by Gefen allows users the benefits of extending dual DVI
displays and USB beyond the desktop. In a growing number of applications, broadcast
stations and production facilities need to locate a computer remotely from the keyboard,
mouse, and video monitor. A CPU may need to be shared between several users, for ex-
ample, or moved to another room because of annoying fan noise.
The CAT5•5500HD series can be used to extend computers with noisy fans, printers, hard
drives, scanners, cameras, keyboards, mouse, and any other USB. With the potential to
cover the distance of 150 feet, industry standard Category 5 (CAT-5) cables are used for
the extension of all the devices.
1
2
FEATURES
Features
• Uses CAT-5 cable for DDC and control signals
• Extends any DVI (Digital Video Interface) compliant device up to 200 ft from the
computer
• 200 ft extension at 1280x1024
• 150 ft extension at 1920x1200
• Saves space on your desktop
• Increases productivity
• Eliminates computer noise where you work
• Supports VESA Standard resolutions and HDTV resolutions
• Supports DDWG standard for DVI compliant monitors
• HDCP Compliant
3
CONTENTS
The CAT5•5500HD system consists of:
--- (1) CAT5•5500HDS sender unit
--- (1) CAT5•5500HDR receiver unit
--- (2) 5 VDC power supplies
--- (2) DVI cable M-M (6FT)
--- (1) USB cable (6FT)
--- (1) User Manual
HOW IT WORKS
The CAT5•5500HD sender unit sits next to your computer. The cables supplied with the
CAT5•5500HDconnects yourDVI source(s)and USBto thesend unit.The CAT5•5500HD
receiver unit sits next to your DVI displays - up to 200 feet away. The displays and USB
plug into the back of the CAT5•5500HD receiver unit. Four CAT-5 cables connect the
CAT5•5500HD-S and the CAT5•5500HD-R units to each other.
HOW IT WORKS
4
CAT5•5500HDS BACK PANEL LAYOUT
12 3 4 56 7 8
5
CAT5•5500HDS BACK PANEL FUNCTIONS
POWER - 5 VDC external power supply
CAT5 Video 1 - RJ-45 input extends DVI input 1 with CAT-5 cable
CAT5 USB/DDC1 - RJ-45 input extends USB and DDC1 signals with CAT-5 cable
DVI IN 1 - DVI Input connects to your computer
CAT5 Video 2 - RJ-45 input extends DVI input 2 with CAT-5 cable
CAT5 USB/DDC2 - RJ-45 input extends USB and DDC2 signals with CAT-5 cable
DVI IN 2 - DVI Input connects to your computer
USB IN - USB Input from computer
1
2
3
4
5
6
7
8
6
CAT5•5500HDR BACK PANEL LAYOUT
12 3 4 5 6 7 8
