GEA VARIVENT N Manuel utilisateur

Hygienic valves

GEA VARIVENT® Shut-off valve type N and U, U_R, N_V and U_V

Operating instruction (Translation from the original language)

430BAL008302EN_10

These Operating Instructions are the English translation of the original operating

instructions in the sense of the EU Machinery Directive. This document is

part, be copied, reproduced, translated or reduced to an electronic medium of

machine-readable form without the express permission of GEA Tuchenhagen

GmbH.

LEGAL NOTICE

Wordmarks

The designations VARIVENT® and T.VIS® are protected trademarks of GEA

Tuchenhagen GmbH. The TEFASEP® gold designation is a trademark of GEA

Tuchenhagen GmbH registered in Switzerland.

We kindly request that you answer a few short questions about these Operating

Instructions. Use the following QR code or link to access the questionnaire:

https://www.ntgt.de/ra/s.aspx?s=367112X57707125X58087

430BAL008302EN_10

2 16.03.2023

TABLE OF CONTENTS

1 General Information 5

1.1 Information on the Document 5

1.1.1 Binding Character of These Operating Instructions 5

1.1.2 Notes on the Illustrations 5

1.1.3 Symbols and Highlighting 5

1.2 Manufacturer address 6

1.3 Contact 6

1.4 EU Declaration of Conformity in accordance with the EC Machinery Directive 2006/42/EC 7

2 Safety 8

2.1 Intended use 8

2.1.1 Requirements for operation 8

2.1.2 Pressure equipment directive 8

2.1.3 ATEX directive 8

2.1.4 Improper operating conditions 8

2.2 Operator’s Duty of Care 9

2.3 Subsequent changes 10

2.4 General safety instructions and dangers 10

2.4.1 Principles for safe operation 10

2.4.2 Environmental Protection 10

2.4.3 Electrical Equipment 11

2.5 Supplementary Regulations 11

2.6 Qualification of personnel 11

2.7 Safety equipment 12

2.7.1 Signage 12

2.8 Residual dangers 13

2.9 Danger zones 14

3 Description 16

3.1 Design 16

3.2 Functional description 18

3.2.1 Valve N 18

3.2.2 Valve U 18

4 Transport and storage 20

4.1 Storage conditions 20

4.2 Transport 20

4.2.1 Scope of supply 21

5 Technical data 22

5.1 Type plate 22

5.2 Technical data 22

5.3 Resistance and permitted operating temperature of the sealing materials 25

5.4 Pipe ends - General table of measurements 26

5.5 Tool 27

5.6 Lubricants 27

5.7 Weights 27

6 Assembly and installation 29

6.1 Safety instructions 29

6.2 Notes on installation 29

6.3 Control head 29

6.4 Valve with Detachable Pipe Connection Elements 29

6.5 Valve with Welded Ends 30

6.6 Pneumatic connections 31

6.6.1 Air Requirement 31

6.6.2 Establishing Hose Connections 31

6.7 Electrical connection with T.VIS control top 32

7 Start-up 33

7.1 Safety instructions 33

7.2 Notes on commissioning 33

8 Operation and control 34

8.1 Safety instructions 34

9 Cleaning 35

430BAL008302EN_10

16.03.2023 3

9.1 Cleaning 35

9.1.1 Cleaning Process Examples 35

9.1.2 Cleaning results 35

9.2 Passivation 36

10 Maintenance 37

10.1 Safety instructions 37

10.2 Inspections 38

10.2.1 Product contact seals 38

10.2.2 Pneumatic connections 38

10.2.3 Electrical connections 38

10.3 Maintenance intervals 39

10.4 Prior to disassembly 39

10.5 Disassembling Valve N 40

10.5.1 Detaching the Clamp Connection (43.1) 40

10.5.2 Removing the Control Top 42

10.5.3 Disconnecting the Valve from the Housing 43

10.5.4 Removing the Valve Disk 44

10.6 Disassembling Valve U 45

10.6.1 Detaching the Clamp Connection (46) 45

Removing the Valve Disk 49

10.7 Maintenance 51

10.7.1 Cleaning the Valve 51

10.7.2 Replacing the V-Ring 51

10.7.3 Exchanging the O-ring (TEFASEP gold) 53

10.7.4 Lubricating Seals and Threads 55

10.8 Installation 56

10.8.1 Reversing the resting position 56

10.8.2 Installing the Valve 57

10.8.3 Torques for the Clamps and Clamp Connections 58

10.8.4 Checking the function 59

11 Alarms 60

11.1 Malfunctions and remedies 60

12 Decommissioning 61

12.1 Safety instructions 61

12.2 Disposal 61

12.2.1 General notes 61

12.2.2 Valve Actuator Disposal 61

13 Parts list - shut-off valve N 62

14 Parts list - shut-off valve N_V 70

15 Parts list - shut-off valve U 75

16 Parts list - shut-off valve U_V 83

17 Parts list - shut-off valve U_R 86

18 Dimension sheet - shut-off valve N 94

19 Dimension sheet - shut-off valve U 96

20 Dimensional sheet - shut-off valve U_R 98

21 Appendix 100

21.1 Lists 100

21.1.1 Abbreviations and terms 100

430BAL008302EN_10

4 16.03.2023

1 General Information

1.1 Information on the Document

The present Operating Instructions are part of the user information for the

product. The Operating Instructions contain all the information you need to

transport, install, commission, operate and carry out maintenance for the product.

1.1.1 Binding Character of These Operating Instructions

These Operating Instructions contain the manufacturer's instructions to the

operator of the product and to all persons who work on or use the product

regarding the procedures to follow.

Carefully read these Operating Instructions before starting any work on or using

the product. Your personal safety and the safety of the product can only be

ensured if you act as described in the Operating Instructions.

Store the Operating Instructions in such a way that they are accessible to the

operator and the operating staff during the entire life cycle of the product. When

the location is changed or the product is sold make sure you also provide the

Operating Instructions.

1.1.2 Notes on the Illustrations

The illustrations in these Operating Instructions show the product in a simplified

form. The actual design of the product can differ from the illustration. For detailed

views and dimensions of the product please refer to the design documents.

1.1.3 Symbols and Highlighting

In these Operating Instructions, important information is highlighted by symbols

or special formatting. The following examples illustrate the most important types

of highlighting.

Danger

Warning: Fatal Injuries

Failure to observe the warning can result in serious damage to health, or

even death.

► The arrow identifies a precautionary measure you have to take to avoid

the hazard.

Warning: Explosions

Failure to observe the warning can result in severe explosions.

► The arrow identifies a precautionary measure you have to take to avoid

the hazard.

General Information

Information on the Document

430BAL008302EN_10

16.03.2023 5

Warning!

Warning: Serious Injuries

Failure to observe the warning can result in serious damage to health.

► The arrow identifies a precautionary measure you have to take to avoid

the hazard.

Caution!

Warning: Injuries

Failure to observe the warning can result in minor or moderate damage to

health.

► The arrow identifies a precautionary measure you have to take to avoid

the hazard.

Notice

Warning: Damage to Property

Failure to observe the warning can result in serious damage to the

component or in the vicinity of the component.

► The arrow identifies a precautionary measure you have to take to avoid

the hazard.

Carry out the following steps: = Start of a set of instructions.

1. First step in a sequence of operations.

2. Second step in a sequence of operations.

®Result of the previous operation.

®The operation is complete, the goal has been achieved.

Hint!

Further useful information.

1.2 Manufacturer address

GEA Tuchenhagen GmbH

Am Industriepark 2-10

21514 Büchen

1.3 Contact

Tel.:+49 4155 49-0

Fax:+49 4155 49-2035

[email protected]

www.gea.com

General Information

Manufacturer address

430BAL008302EN_10

6 16.03.2023

1.4 EU Declaration of Conformity in accordance with the EC Machinery Directive

2006/42/EC

Manufacturer: GEA Tuchenhagen GmbH

Am Industriepark 2-10

21514 Büchen

We hereby declare that the machine named below

Designation: Valve with actuator

Type: VARIVENT®

due to its design and construction as well as in the versions sold by us, meet the basic safety and health

requirements of the following guideline:

Relevant EC directives: 2006/42/EC EC Machinery Directive

Applicable harmonized standards,

in particular:

EN ISO 12100: 2010

Remarks: •This declaration will become invalid if any

alterations are made to the machine which have

not been agreed with us

•We also declare that the relevant technical

documentation for this machine has been

prepared in accordance with Annex VII, Part A,

and agree to submit the documentation on

justified request of national authorities on a data

carrier

Person authorised for compilation and handover of

technical documentation:

GEA Tuchenhagen GmbH

CE Documentation Officer

Am Industriepark 2-10

21514 Büchen, Germany

Büchen, 24 January 2020

Franz Bürmann

Managing Director i.V. Matthias Südel

Head of Engineering

General Information

EU Declaration of Conformity in accordance with the EC Machinery Directive 2006/42/EC

430BAL008302EN_10

16.03.2023 7

2 Safety

2.1 Intended use

The shut-off valve N and U are used to open and close pipe sections.

The medium should preferably flow in the opening direction of the valve disk to

avoid pipe hammers when the valve is opened or closed.

Hint!

The manufacturer will not accept any liability for damage resulting

from any use of the valve which is not in accordance with the

designated use of the valve. The risk of such misuse lies entirely with

the operator of the facility.

2.1.1 Requirements for operation

The prerequisite for reliable and safe operation of the component is proper

transportation and storage as well as professional installation and assembly.

Operating the unit within the limits of its designated use also involves adhering to

the operating, inspection and maintenance instructions.

2.1.2 Pressure equipment directive

The valve is a piece of pressure equipment (without safety function) in the sense

of the pressure equipment directive 2014/68/EU: Classified according to Annex II

in category 1.

According to the scope of directive 2014/34/EC, article 1, paragraph 2, f, the

exception of the directive applies, due to conformity with the machine directive

2006/42/EU.

The nominal diameters smaller than DN 25 are subject to article 4, paragraph 3

of the Pressure Equipment Directive which specifies sound engineering practice.

Nominal diameters ≥ IPS 4“; DN 125 valid for the fluid group II.

In the event of any deviations, GEA Tuchenhagen GmbH will supply a specific

Declaration of Conformity.

2.1.3 ATEX directive

In areas with an explosive atmosphere, only valves suitable for use in such areas

may be used.

Refer to and observe the additional operating instructions “ATEX version valves”.

For details regarding the marking of valves for potentially hazardous areas also

refer to the additional operating instructions “ATEX version valves”.

If these valves are used in areas with a potentially explosive atmosphere, you

must absolutely comply with directive 2014/34/EC with respect to all ignition

hazards.

2.1.4 Improper operating conditions

The operational safety of the component can not be guaranteed under improper

operating conditions. Therefore avoid improper operating conditions.

Safety

Intended use

430BAL008302EN_10

8 16.03.2023

The operation of the component is not permitted if:

•Persons or objects are in the danger zone.

•Safety devices are not working or were removed.

•Malfunctions have been detected on the component.

•Damage to the component has been detected.

•Maintenance intervals have been exceeded.

2.2 Operator’s Duty of Care

The operating company of the component has a special responsibility for the

proper and safe handling of the component within their company. Only use the

component when it is in perfect operating condition in order to prevent danger to

persons and property.

This operating manual contains information that you and your employees need

for safe operation over the life of the component. Be sure to read these Operating

Instructions carefully and ensure that the measures described here are observed.

The operator's duty of care includes planning the necessary safety measures and

monitoring that these measures are observed. The following principles apply:

•Only qualified personnel may work on the component.

•The operating company must authorize personnel to carry out the relevant

tasks.

•Order and cleanliness must be maintained at the work stations and in the

entire area surrounding the component.

•Personnel must wear suitable work clothing and personal protective

equipment. As the operating company must ensure that work clothing and

personal protective equipment are used.

•Inform personnel regarding any properties of the product which might pose a

health risk and the preventative measures to be taken.

•Have a qualified first-aid representative on call during the operation. This

person must be able to initiate any necessary first-aid measures in case of an

emergency.

•Clearly define procedures, competences and responsibilities for those

working in the area of the component. Everybody must know what to do in

case of an emergency. Instruct the staff in this respect at regular intervals.

•The signs on the component must always be complete and easy to read.

Check, clean and replace the signs as necessary at regular intervals.

•Observe the Technical Data specified and the limits of use!

Hint!

Carry out regular checks. This way you can ensure that these

measures are actually observed.

Safety

Operator’s Duty of Care

430BAL008302EN_10

16.03.2023 9

2.3 Subsequent changes

No technical modifications should ever be made to this component. Otherwise

you will have to undergo a new conformity process in accordance with the EC

Machinery Directive on your own.

In general, only original spare parts supplied by GEA Tuchenhagen GmbH

should be fitted. This ensures that the component is always operating properly

and efficiently.

2.4 General safety instructions and dangers

The component is safe to operate. It was built according to state-of-the-art

science and technology.

Nevertheless, dangers can arise from the component, if:

•the component is not used as intended

•the component is used improperly

•the component is operated under impermissible conditions

2.4.1 Principles for safe operation

Dangerous situations during operation can be avoided by safety-conscious and

proactive behaviour of the staff.

To ensure safe operation of the valve the following principles apply:

•The Operating Instructions must be kept ready to hand at the valve's place of

use. They must be complete and in clearly legible form.

•Only use the valve for its intended use.

•The valve must be functional and in good working order. Check the condition

of the valve before starting work and at regular intervals.

•Wear tight-fitting work clothing for all work on the valve.

•Ensure that nobody can get hurt on the parts of the valve.

•Immediately report any faults or noticeable changes on the valve to the

person responsible.

•Never touch the pipes and the valve when these components are hot! Avoid

opening the valve unless the process plants have been emptied and

depressurised.

•Observe the accident prevention regulations and all local regulations.

2.4.2 Environmental Protection

Harm to the environment can be avoided by safety-conscious and proactive

behaviour of the staff.

For environmental protection the following principles apply:

•Substances harmful to the environment must not be discharged into the

ground or the sewage system.

•Always observe the pertinent regulations relating to waste avoidance,

disposal and utilization.

Safety

Subsequent changes

430BAL008302EN_10

10 16.03.2023

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GEA Unité de contrôle

GEA

GEA ECOVENT Manuel utilisateur

GEA

GEA VARIVENT T R Series Manuel utilisateur

GEA

GEA VARIVENT T R Manuel utilisateur

GEA

GEA VARIVENT 24/7 PMO Manuel utilisateur

GEA

GEA AVR Series Manuel utilisateur

GEA

GEA Aseptomag AMV Manuel utilisateur

GEA

GEA Aseptomag AV Manuel utilisateur

GEA

GEA VARIVENT TSVN Manuel utilisateur

GEA

GEA VARIVENT Series Manuel utilisateur

GEA

GEA VARIVENT T R Manuel utilisateur

GEA

GEA VARIVENT T R Manuel utilisateur

GEA

GEA VARIVENT K Manuel utilisateur

GEA

GEA VARIVENT T R Series Manuel utilisateur

GEA

GEA VARIVENT MT/T R 08 Manuel utilisateur

GEA

GEA D-tec D Manuel utilisateur

GEA

GEA VARIVENT K Manuel utilisateur

GEA

GEA VARIVENT D Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

GEA

GEA ECOspace Manuel utilisateur

GEA

GEA DHV Manuel utilisateur

GEA

GEA VARIVENT Mixproof T R Series Manuel utilisateur

GEA

GEA HRAB Manuel utilisateur

GEA

GEA VARIVENT X Manuel utilisateur

GEA

GEA DHV DN65/50 KVS 16 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

Flyron

Flyron FN-BC04 Manuel utilisateur
