Specification Created 6/03

GE Appliances

JGBC20BEH – GE®30" Free-Standing Continuous Clean Gas Range

Dimensions (in inches) and Installation Information

30

46-7/8

26-1/4*

46-3/8

36±1/4

Factory set for Natural gas. A set of

LP orifices is included with each

range for LP conversion.

Gas Self-Clean Range

Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before

installing, consult installation

instructions packed with product

for current dimensional data.

24

30

8

4

9

2

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

*Dimension from wall to front of closed door handle is 29".

Depth to front top edge of cooktop – 25-1/4".

CERTIFIED

For answers to your Monogram,

® GE Profile™or

GE®appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

All GE ranges are equipped

with an Anti-Tip device.

The installation of this

device is an important,

required step in the

installation of the range.

Specification Created 6/03

GE Appliances

JGBC20BEH – GE®30" Free-Standing Continuous Clean Gas Range

CLOCK

SET

TIMER

ON OFF

Features and Benefits

• Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more

items at once.

• All Purpose Burners – Deliver a wide range of heat output ideal for most

cooking requirements.

• Electronic Clock and Timer – Features a convenient digital clock and easy-to-use

timer with an audible signal to help coordinate cooking times in the kitchen.

• Standard Grates – Provide a sturdy and convenient cookware surface for

everyday cooking.

• Frameless Glass Oven Door – Offers an easy-to-clean and stylish design that

blends seamlessly into existing cabinetry.

• ClearView™Window – Features a convenient viewing area to check the progress

of food.

• Two Oven Racks – Feature a durable construction to help accommodate any size or

type of cookware.

•Model JGBC20WEHWW – White on white (white door and white cooktop)

• Model JGBC20CEHCC – Bisque on bisque (bisque door and bisque cooktop)

• Model JGBC20BEHWH – White (black door and white cooktop)

• Model JGBC20BEHCT – Bisque (black door and bisque cooktop)
