Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Created 5/07 230588

PGB928TEM

GE Profile™ 30" Free-Standing Double Oven Range

Note: Dimension from the wall to the front

of the closed door handle is 29". Depth to

front edge of cooktop 25-1/4".

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

Depth with door closed

(includes handle)

14-1/2 2-1/2

Recommended area

for thru the floor

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

Recommended

area for 120V outlet

on rear wall and

area for thru the

wall connection

of pipe stub and

shut-off valve

47-3/16 36-1/4 ±1/4

Depth varies

depending on model.

See specifications

sheet for your model.

29"

46-3/4"

Depth with

door open

Depth with door closed

(includes handle)

14-1/2 2-1/2

Recommended area

for thru the floor

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

Recommended

area for 120V outlet

on rear wall and

area for thru the

wall connection

of pipe stub and

shut-off valve

47-3/16 36-1/4 ±1/4

Depth varies

depending on model.

See specifications

sheet for your model.

29"

46-3/4"

Depth with

door open

PGB928TEM/DEM

LowerOven

LITE

FRONT

654

LOHI

LITE

REAR

654

LITE

RECISESIMMER

REAR

654

LITE

POWER

BOIL

FRONT

POWERBOIL

SETTINGINTENDEDFOR

USEWITHLARGERPOTS

WARM

ZONE

200

250

300350400

450

LOWEROVEN

HEATING

ONVECTION

AKE

ROBE

ONVECTION

OAST

LEAR

OOKING

IME

ELAY

TART

VEN

IGHT

ELF

LEAN

LOCK

ITCHEN

IMER

AKE

ROIL

TART

DoubleOven

IME

ONTROLS

VEN

ONTROLS

ONTROL

OCKOUT

12345

67890

ROASTBROILPROBELOCKEDCOOK DELA

YTIMER

CLEAN

CLOCK

START

WARMER

HOTON

BAKE

MULTI

CONV

WARM

Convection

Features and Benefits

• Gas Convection Oven - Circulates air throughout the oven cavity ensuring better

baking and roasting results

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Gas On Glass Cooktop - Features a flat one-piece ceramic glass surface that is sleek

and easy-to-clean

• Lower Oven - Offers an additional 1.0 cu. ft. of capacity for convenient baking from

150 degrees to 450 degrees

• QuickSet VI Glass Touch Oven Controls - A smooth glass design that

is easy-to-operate and easy-to-clean

• PowerBoil™ Burner - Delivers 15,000 BTUs of forceful heat for rapid boiling

• Precise Simmer Burner - Delivers a low setting of 140 degrees, ideal for delicate

foods and sauces

• Stainless Appearance Knobs - Deliver the sleek metallic color of stainless steel

for a universally appealing look

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement

of pans between burners

• Model PGB928TEMWW - White on white

• Model PGB928TEMCC - Bisque on bisque

• Model PGB928TEMBB - Black on black

Specification Created 5/07 230588

PGB928TEM

GE Profile™ 30" Free-Standing Double Oven Range
