SCB2000F – Advantium™Wall Oven

Dimensions (in inches)

Listed by

Underwriters

Laboratories

For answers to your Monogram,

® GE Profile™or

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Specification Revised 11/03

240428

Most 30" Wall Cabinets can be used with this unit.

Cutout width

28-1/2

Required

cutout location

36-3/4"

minimum

from floor

Junction

box

location

A=Allow 1" overlap of oven over top and bottom edges of cutout.

B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.

4-3/16

Cutout height

Cutout depth

29-25/32

21-7/8

15-27/32

Excluding

Handle

Construct Solid

Bottom Min.

3/8" Plywood

Supported by

2 x 4 or 1 x 2

Runners, all

Four Sides.

(Must Support

150 lbs.)

Note: Cabinets installed adjacent to wall ovens must have an adhesion

spec of at least 194°F temperature rating.

Note: 2" minimum between cutouts when installed above warming

drawer or single wall oven.

SCB2000F –Advantium™Wall Oven

36-3/4" Min.

Required

30" 19"

Min

Construct Solid

Bottom Min. 3/8"

Plywood

Supported by

2 x 4 or 1 x 2

Runners, all

Four Sides

28-1/2"

21"

36-3/4" Min.

30" 24"

Min. Construct Solid

Bottom Min. 3/8"

Plywood

Supported by

2 x 4 or 1 x 2

Runners, all

Four Sides

2" Min.

Install 2 x 4

or 2 x 2

Runners or

Solid Bottom,

Must Support

100 lbs.

28-1/2"

21"

9-1/4"

*45-1/4"

30" 24"

Min. Construct Solid

Bottom Min. 3/8"

Plywood

Supported by

2 x 4 or 1 x 2

Runners, all

Four Sides

2" Min.

Per Oven

Requirement

28-1/2"

21"

Single Speedcook Installation

Order a 30" wide single oven cabinet or cut the opening

in a wall to dimensions shown.

The rough opening must be:

• Depth – 19" Min.

• Width – 28-1/2" Min.

• Height – 21" Min.

• 36-3/4" from the floor to the cutout is required.

• These ovens require 3/4" overlap on each side, top and

bottom of the cutout.

• Oven overlaps will conceal cut edges on all sides of

the opening.

Specification Revised 11/03

240428

Note: Additional clearance between the cutouts may be

required. Check to be sure the oven supports above

the Warming Drawer location does not obstruct the

required interior 23-1/2”depth and 9-1/4”height.

See installation instructions for details.

Speedcook Oven Installation above a single

GE Built-In Wall Oven

Speedcook Oven Installation above a

GE Warming Drawer

Listed by

Underwriters

Laboratories

For answers to your Monogram,

®GE Profile™or

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Specification Revised 11/03

240428

SCB2000F –Advantium™Wall Oven

Features and Benefits

•Revolutionary Speedcook Technology Cooks Oven-Quality Food

Up to Eight Times Faster Than a Conventional Oven

•Over 100 Pre-Programmed Menu Items, Repeat Last, Help and Demo Modes

•Electronic Scrolling Display with Variable Scroll Speed

•Bakes, Browns, Broils, Grills and Roasts –All with No Preheating

•Converts to Fully Functional 950 Watt Sensor Microwave Oven

•Family-Size Oven with Stainless Steel Interior

•Microwave Oven Features Humidity Sensor and Auto Defrost/Time Defrost

•Cooking Complete Reminder with Beeper Sound Level Control

•Interior Oven Light

•Child Lock Out

•Sculptured Handle

•Frameless Glass Oven Door with Window

•Cookbook and Pan Set Included

•Model SCB2000FWW –White on white

•Model SCB2000FBB –Black on black

•Model SCB2000FCC –Bisque on bisque

•Model SCB2001FSS –Stainless steel

SPEED

COOKPOWER

LEVELTIMERMICRO

WAVE

BACK

MICRO

EXPRESS

HELP

OPTIONS

MANUAL

COOK

REPEATLASTOVENLIGHT

RECIPE

START

PAUSE

CLEAR

OFF
