JKP25SH – GE® 27" Built-In Single Oven

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

27" Built-In Single Oven Dimensions (in inches)

Specification Revised 7/05

320431

2" x 4"

or equiv.

runners

B MIN.

C MIN.

Conduit 48-1/2" long

6015 Built-in Single Oven

(Pub. 1-G003 pg. 107) April 28, 1993

32-1/2

AAllow 3/4"

for overlap

over all edges

of cutout

Locate

junction box

either 5" MIN.

below cutout

floor or 44"

MIN. above

cutout floor

Minimum

cutout location

from floor

(Minimum 15-5/8"

from floor when

installed below built-in

microwave oven)

Note: These ovens are not

approved for stackable or

side-by-side installations.

Note: These ovens can be

installed side-by-side with no

less than 30" distance between

center-to-center of each oven.

Note: Cabinets installed adjacent to wall ovens

must have an adhesion spec of at least a 194°F

temperature rating.

Note: For 27" built-in single ovens, if marks,

blemishes or the cutout opening is visible

above the installed oven, it may be necessary

to add wood shims under the runners and front

trim until the marks or openings are covered.

Cabinet 27"

A – Cabinet Width Required 27" min.

B – Minimum Cabinet Depth 23-5/8"

C – Opening Width 25" min. - 25-1/4 max.

D – Opening Height 27-5/8" min. - 28-1/8 max.

Oven

E – Overall Depth 23-5/8"

w/o trim 28-1/4"

F – Overall Height with trim 29"

G – Overall Width 26-5/8"

Suitable

bracing

to support

runners 18"

Over centerline

of cabinet

2" x 4" or

equivalent

runners

(Must support 275 lbs.)

Listed by

Underwriters

Laboratories

For answers to your Monogram,

® GE Profile™ or

GE® appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center® service, 800.626.2000.

KW Rating

240V 3.4

208V 2.6

Breaker Size

240V 20 Amps

208V 20 Amps

Electric wall ovens are not approved for installation with a plug and receptacle.

They must be hard wired in accordance with installation instructions.

GE Appliances

JKP25SH – GE® 27" Built-In Single Oven

Undercounter Installation Dimensions (in inches)

Specification Revised 7/05

320431

Listed by

Underwriters

Laboratories

For answers to your Monogram,

® GE Profile™

or GE® appliance questions, visit our website

GEAppliances.com or call

Sealed Burner Gas Cooktop

Installation Dimensions (in inches)

Standard Burner Gas Cooktop

Installation Dimensions (in inches)

Gas or electric cooktops may be installed over this

oven. See cooktop installation instructions for cutout size.

See label on top of oven for approved cooktop models.

Gas or electric connections

for gas cooktop must be

located in an adjacent

accessible location to the right

240V / 208V

Junction Box

Location

36"

Typical

Countertop

Height

Allow 1"

unit overlap

all edges

25" MIN.

25 1/4" MAX.

27 5/8" MIN.

28 1/8" MAX.

3/4" Support

Platform Required

Must Support 150 Lbs.

22" MIN.

Above

Support

Platform

Note: Oven is rated for use only under 30" standard or sealed burner gas and

selected 30" CleanDesign and Calrod® electric cooktops.

Installation Information: Before installing, consult installation instructions

packed with product for current dimensional data.

90° Street el

45° Elbow

Cabinet sides

2" Diameter hole (20-7/8"

from front of countertop

to hole center)

Sealed Burner Gas Cooktop Installation

(Pub. 1-G003 pg. 107) May 11, 1993

5" To center of 2" diameter

hole from countertop

90° Street el

45° Elbow

To center of 2" diameter

hole from countertop

Cabinet sides

3-7/16"

2" MIN. diameter hole

(23-1/4" from front

surface of countertop)

Standard Burner Gas Cooktop Installation

(Pub. 1-G003 pg. 107) May 11, 1993

Note: Cabinets installed adjacent to wall ovens

must have an adhesion spec of at least a 194°F

temperature rating.

Electric wall ovens are not approved for installation with a plug and receptacle.

They must be hard wired in accordance with installation instructions.

GE Appliances

JKP25SH – GE® 27" Built-In Single Oven

JKP25SHSS

Features and Benefits

• Self-clean oven – Conveniently cleans oven cavity without the need for scrubbing.

• Extra-large oven capacity – Provides a large oven interior ideal for cooking more items

at once.

• Electorinc oven controls – One-touch electronic pads are easy-to-use and allow for simple

oven operation.

• TrueTemp™ system – Delivers even heat distribution and maximum oven control.

• BIg ClearView™ window – An extra large clear window makes monitoring the progress of

the food easy.

• Interior oven light – Supplies light to make viewing progress of cooking easy and convenient.

• Dual element bake – Alternates the upper broiling element and the lower baking elements

for even heating and optimal baking results.

• Model JKP25SHSS – Stainless steel

Specification Revised 7/05

320431
