GE VersaMax IC754TAN001 Manuel utilisateur
QuickPanel* Control
Communication Module
Quick Install Guide
VersaMax* Expansion I/O Interface Card
IC754TAN001
April 2010
________________________________________
GFK-2299
GFL-002
Warnings, Cautions, and Notes as Used in this Publication
Warning
Warning notices are used in this publication to emphasize that hazardous voltages,
currents, temperatures, or other conditions that could cause personal injury exist in
this equipment or may be associated with its use.
In situations where inattention could cause either personal injury or damage to
equipment, a Warning notice is used.
Caution
Caution notices are used where equipment might be damaged if care is not taken.
Note: Notes merely call attention to information that is especially significant to
understanding and operating the equipment.
This document is based on information available at the time of its publication. While efforts
have been made to be accurate, the information contained herein does not purport to cover
all details or variations in hardware or software, nor to provide for every possible contingency
in connection with installation, operation, or maintenance. Features may be described herein
which are not present in all hardware and software systems. GE Intelligent Platforms
assumes no obligation of notice to holders of this document with respect to changes
subsequently made.
GE Intelligent Platforms makes no representation or warranty, expressed, implied, or
statutory with respect to, and assumes no responsibility for the accuracy, completeness,
sufficiency, or usefulness of the information contained herein. No warranties of
merchantability or fitness for purpose shall apply.
* Indicates a trademark of GE Intelligent Platforms, Inc. and/or its affiliates. All other
trademarks are the property of their respective owners.
©Copyright 2010 GE Intelligent Platforms North America, Inc.
All Rights Reserved
Contact Information
If you purchased this product through an Authorized Channel Partner, please contact the
seller directly.
General Contact Information
Online technical support and GlobalCare http://www.ge-ip.com/support
Additional information http://www.ge-ip.com/
Technical Support
If you have technical problems that cannot be resolved with the information in this guide,
please contact us by telephone or email, or on the web at www.ge-ip.com/support
Americas
Online Technical Support www.ge-ip.com/support
Phone 1-800-433-2682
International Americas Direct Dial 1-780-420-2010 (if toll free 800 option is
unavailable)
Technical Support Email support.ip@ge.com
Customer Care Email customercare.ip@ge.com
Primary language of support English
Contact Information
Europe, the Middle East, and Africa
Online Technical Support www.ge-ip.com/support
Phone +800-1-433-2682
EMEA Direct Dial +352-26-722-780 (if toll free 800 option is
unavailable or if dialing from a mobile telephone)
Technical Support Email support.emea.ip@ge.com
Primary languages of support English, French, German, Italian, Czech, Spanish
Asia Pacific
Online Technical Support www.ge-ip.com/support
Phone +86-400-820-8208
+86-21-3217-4826 (India, Indonesia, and Pakistan)
Technical Support Email support.cn.ip@ge.com (China)
support.jp.ip@ge.com (Japan)
support.in.ip@ge.com (remaining Asia customers)
Customer Care Email customercare.apo.ip@ge.com
customercare.cn.ip@ge.com (China)
The Interface Card has been tested and found to meet or exceed the requirements of U.S.
(47 CFR 15), Canadian (ICES-003), Australian (AS/NZS 3548) and European (EN55022)
regulations for Class A digital devices when installed in accordance with guidelines noted in
this manual.
Note: This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference that
may cause undesired operation.
Note: This Class A digital apparatus complies with Canadian ICES-003.
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Note: Any changes or modifications to the product or installation that are not expressly
approved by GE Intelligent Platforms could void the user's authority to operate the
equipment under FCC rules.
The following statements are required to appear for Class 1, Div 2 Hazardous Locations.
1. EQUIPMENT LABELED WITH REFERENCE TO CLASS 1, GROUPS A, B, C, AND D,
DIV 2 HAZARDOUS LOCATIONS IS SUITABLE FOR USE IN CLASS 1, DIVISION 2,
GROUPS A, B, C, D, OR NON-HAZARDOUS LOCATIONS ONLY.
2. WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR
SUITABILITY FOR CLASS 1, DIVISION 2.
3. WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS
POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE
NONHAZARDOUS.
GFK-2299 VersaMax Expansion I/O Interface Card
Table of Contents
Table of contents………………………………………..…...….7
Introduction............................................................................1
Related Documents ......................................................................1
Description....................................................................................2
Indicators......................................................................................3
Expansion Bus Connector ............................................................3
Installing a Communication Module....................................4
Connecting the Expansion Cable.........................................6
Terminator Plug ............................................................................7
Differential Inter-Rack Connection (IC200CBL601, 602, 615) ......7
General Specifications..........................................................9
Product Certification ...........................................................10
Description and Features
GFK-2299 VersaMax Expansion I/O Interface Card
1
Introduction
The VersaMax Expansion I/O Interface Card allows the QuickPanel
Control operator interface to control VersaMax remote expansion
rack(s). The VersaMax Expansion I/O Interface Card is used to
connect the QuickPanel Control operator interface to up to seven
VersaMax remote expansion module racks. Each expansion rack
can include up to eight I/O modules.
The communication path consists of a VersaMax Expansion I/O
Interface Card installed in a QuickPanel Control, a GE or user-
supplied cable and mating connectors, and an Expansion receiver
module installed at the head end of each VersaMax remote
expansion module rack.
Configuration of the VersaMax Expansion I/O interface card in the
QuickPanel Control is accomplished using Proficy™ Machine
Edition. For a complete description of the features and capabilities
of the VersaMax Expansion I/O interface card, please refer to the
Proficy Machine Edition on-line help for the card.
A termination plug, IC200ACC201, is included with the card.
Related Documents
VersaMax Modules, Power Supplies, and Carriers User's
Manual, GFK-1504
Description and Features
GFK-2299 VersaMax Expansion I/O Interface Card
2
Description
The top side of the VersaMax Expansion I/O Interface Card is
shown below. It provides a host connector that connects the
Interface Card with your QuickPanel Control operator interface. The
expansion bus cable is connected to the VersaMax Expansion I/O
Interface Card through the Expansion connector. An LED indicator
displays the status of the Interface Card.
Description and Features
GFK-2299 VersaMax Expansion I/O Interface Card
3
Indicators
The EXP TX LED on the front of the VersaMax Expansion I/O
Interface Card indicates expansion bus communication status.
LED LED
Status Description
ON
(Blinking) Interface Card is communicating with the Expansion
Rack.
EXP TX
OFF
Interface Card is not communicating with the Expansion
Rack.
Expansion Bus Connector
The 26-pin female D-shell connector on the front of the VersaMax
Expansion I/O Interface Card is the expansion port for connecting to
an Expansion Receiver Module. There are two types of Expansion
Receiver Modules:
Isolated (IC200ERM001)
Non-Isolated (IC200ERM002).
