ENGLISH USER MANUAL
GHDVR85W
gatordriverassist.com
For more information
on the Gator range
go to our website
INCLUSIONS:
Dash Cam, GPS Power Cable, Adhesive Surface Mount,
12/24V In-Car Charger, USB Power Cable, 16GB Micro SD Card
Table of contents
Table of contents...................................................2
Intoductory video user guide.................................3
Product overview..................................................4
Product features....................................................4
System contents...................................................5
Optional accessories.............................................6
Product structure...................................................7
Fixing the Dash Cam.............................................8
Installation of Dash Cam.......................................8
Downloading the Dash Cam WiFi App................10
First time pairing procedure (iPhone)..................11
First time pairing procedure (Android).................13
Successful pairing of your device.......................14
Dash Cam App main screen................................15
Time and date settings........................................16
Formating SD card..............................................17
Download to your phone.....................................17
Info setting..........................................................18
Factory reset.......................................................18
GPS logger.........................................................18
Product specifications.........................................19
Trouble shooting guide........................................20
Safety information & warnings............................26
Infringement of copyright warning.......................27
Technical assistance...........................................27
2
3
Intoductory video user guide
Scan this QR Code to see an introductory video user guide.
Alternatively you can search YouTube for “Gator
Instructional presentation”
https://www.youtube.com/watch?v=q213vb2EIMw
Please note that whilst the instructional video has good
information on pairing and is often enough for most clients
to get started, it does not cover some of the more complex
details that we have added to this manual recently due to
the iPhone and Android operating system changes that
have altered the behaviour of some phones recently.
Please ensure that you have read the product manual and
instructions prior to installation and use. Failure to do so
may result in the product incorrectly operating or an
installation that renders the device unusable.
4
Product overview
The Gator GHDVR85W Dash Cam has been designed to
provide high definition recordings of your road trips for
security and evidence in the case of an accident. This
Dash Cam mounts to the windscreen and records footage
onto a memory card. It has a built-in WiFi interface that
connects it wirelessly to your smartphone. This device
operates through a user interface on your smart phone via
the Gator Dash Cam App. (downloaded from the Apple App
Store or Google Play Store).
Product features
FULL HD 1920x1080 @ 30FPS
152 Degree HD wide angle lens
WiFi enabled (2.4Ghz)
WiFi Via free App to Smartphone
Hand gesture photo / video function
Time and date stamp
G-Sensor function
Parking Mode (optional GHWCUSB2 req)
GPS data recording
Super capacitor
Multi language support
Seamless cycle loop recording
Mini USB interface/ 12V in-car USB charger
Adhesive car mount
Built-in MIC
16GB Memory card
(Supports Micro SD card class10 up to 256GB)
5
Dash Cam GPS
power cable
!
System contents
Gator Dash Cam
USB Power cable
Car Charger/ USB
Power adapter
Memory card
Gator Dash Cam
Mounting Bracket
!
6
Hardwire Kit. (GHWCUSB2) Needed for Park Mode
operation and to free up the vehicles 12V socket for
other usage.
Optional accessories
Product structure
1) Power socket
2) Micro SD card slot
3) Reset
4) Fixing point for
mounting bracket
5) Camera lens
6) Speaker
7) Hand gesture sensor
8) Red light indicator
(Recording)
9) Green light indicator
(WiFi connected)
5
6
1
2
3
4
7
8
9
7
Suggested
Fixing the Dash Cam
Installation of Dash Cam
1. Place mounting bracket onto the Dash Cam by sliding
on fixing point. Orientate the device so the when you attach
it to the wind screen, the USB socket is on the right hand
side (looking from inside the car) and its lens is on the left.
The the Hand Gesture Sensor faces down.
2. Fix the device onto a clean part of the windscreen
toward the centre where the vision is not obstructed. (Make
sure its VERY clean to ensure proper adhesion).
8
9
A place close to the rear-view mirror is ideal in most cases.
Do not install the device near an airbag. (Airbags are often
installed along the outer left- and right-hand sides of the
windscreen).
3. Insert the included Micro SD card into the Dash Cam
4. Insert the Micro USB end of the
GPS power cable
into
the Micro USB socket of the Dash Cam. Remove backing
off 3M tape of GPS cable and fix to window. Connect the
full-size USB plug into the USB socket of the power
adapter, insert the power adapter into a free 12V power
socket in the vehicle. The power cable is long enough to
run along the head lining, down the A pillar, under and
across the Dash to the transmission tunnel where it should
be in range of the vehicles 12V accessory power socket as
shown in the diagram above.
5. Rotate the Camera direction so that it is facing forward
and slightly down from horizontal. Later, using the App, you
can align it exactly so that 1⁄4 of the vehicles bonnet is
visible at the bottom of the Cameras image.
6. Turn the vehicles ignition to accessories, the Dash Cam
should automatically power ON, you will hear an audible
tone once powered. (Some 12V sockets require ignition on).
7. A red LED will start flashing and recording will start. The
unit records footage in small blocks. When the card is full,
the unit will replace the oldest recordings with the newest
footage as it is recorded. The available history is
dependent on the size of the SD cards capacity.
10
Downloading the Dash Cam WiFi App
8. The Dash Cam starts recording automatically when it
receives power from the power adapter.
Once power is turned off (when you turn the car off), the
Dash Cam will use its on-board super capacitor to save the
current file and then turn itself off.
On your Android based Smartphone, search the Google
Play store. For iPhones search the App Store. Search for
“GHDVR85W”
After downloading the App don’t run the App just yet.
Gator has a number of different Apps for different
devices. You MUST download the correct App for your
device. The model number of your device is mentioned
in the App description.
