Magnum ST80 Stackable

Personal Hub

Installation and User Guide

$5.00 USD

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

MagnumStackable

Personal Hub 

Installation and User Guide

Part #: 84-00029 (Rev B 04/01)

Trademarks

Ethernet is a trademark of Xerox Corporation

NEBS is a trademark of Telcordia Technologies

UL is a registered trademark of Underwriters Laboratories

GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a

registered trademark of GarrettCom, Inc.

Important: The Magnum ST80 Stackable Personal Hub family contains no

user serviceable parts. Attempted service by unauthorized personnel shall

render all warranties null and void. If problems are experienced with

Magnum ST80 Stackable Personal Hub products, consult Section 6,

Troubleshooting, of this User Guide.

of this publication may be reproduced without prior written permission from

GarrettCom, Inc.

Printed in the United States of America.

Stackable Personal Hubs Installation and User Guide (04/01)

iii

www GarrettCom com

Contacting GarrettCom, Inc

Please use the mailing address, phone and fax numbers and email address listed below:

GarrettCom, Inc.

47823 Westinghouse Dr.

Fremont, CA 94539

Phone (510) 438-9071

Fax (510) 438-9072

Website: http://www.GarrettCom.com

email [email protected]

Federal Communications Commission

Radio Frequency Interference Statement

This equipment generates, uses and can radiate frequency energy and if not

installed and used properly, that is in strict accordance with the manufacturer's

instructions, may cause interference to radio communication. It has been tested and

found to comply with the limits for a Class A computing device in accordance with the

specifications in Subpart J of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause

interference, in which case the user at his own expense will be required to take

whatever measures may be required to correct the interference.

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

TABLE OF CONTENTS Page

1.0 SPECIFICATIONS...................................................................................... 1

1.1. Technical Specifications.................................................................................. 1

1.2 ORDERING INFORMATION......................................................................... 3

2.0 INTRODUCTION ....................................................................................... 4

2.1 Inspecting the Package and Product.................................................................. 4

2.2 Product Description ......................................................................................... 5

2.3 Features and Benefits........................................................................................ 8

2.4 Applications...................................................................................................... 9

3.0 INSTALLATION ............................................................................................ 11

3.1 Table-Top or Shelf Mounting........................................................................ 11

3.2 Wall (or Vertical Surface) Mounting (for non-stacked units only)................. 12

3.3 Combining and Mounting Stacked Units........................................................ 12

3.4 Twisted Pair Segment Connections ................................................................ 13

3.5 AUI Connection.............................................................................................. 13

3.6 BNC Connection (Model ST80-B only)......................................................... 15

3.7 Fiber Optic Connection (Model ST80-F only)................................................ 15

3.8 Switchable Up-Link Option............................................................................ 16

3.9 Stacking the ST80 Personal Hubs................................................................... 16

3.10 Cascading ST80 Personal Hubs with the Up-Link port ................................ 18

4.0 OPERATION............................................................................................. 19

4.1 Functional Operation, Use of LED Indicators ................................................ 19

4.2 Using the Up-Link switch............................................................................... 20

4.3 Using the BNC internal termination switch (Model ST80-B only) ................ 20

4.4 Using the Stack Enable switch........................................................................ 21

5.0 TROUBLESHOOTING............................................................................. 22

5.1 Before Calling for Assistance......................................................................... 22

5.2 When Calling for Assistance .......................................................................... 23

5.3 Return Material Authorization (RMA) Procedure .......................................... 23

5.4 Return Shipping and Packaging Information.................................................. 24

APPENDIX A: WARRANTY INFORMATION .................................................... 24

Revisions

Rev B 04/01 : Change the company name to GarrettCom, Inc. (Formerly it

was Garrett Communications). There are no changes to the content of the

material at this time

Rev A 06/95 : This revision is the initial release of the Magnum ST80 Stackable

Personal Hub user manual.

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

The Magnum Line

ETHERNET CONNECTIVITY PRODUCTS

"DESIGNED AND MANUFACTURED IN THE USA"

OVERVIEW

GarrettCom, Inc.offers the premium-quality Magnumline of Ethernet LAN

connectivity products with industry-standard functionality and built-in fiber

configurability. Magnum products are designed for use in demanding Carrier Class,

Industrial Grade and OEM applications where reliability is a primary consideration.

4K-Series Switches, 100 & 10Mbps, copper ports with optional fiber

port, with auto-negotiating full switching performance

Quad-Series Fiber Switches, 100 & 10Mbps, fiber and copper

ports, mixed-speed and mixed-media types, full switching

performance

“Outdoor” Ethernet Switch, for temperature uncontrolled locations

6 10/100 and 2 100Mb fiber ports, can be connected in strings

Mixed-Media Fiber Hub, 16-port Stackable, 10/100 auto-sensing

Dual Speed 8-port and 16-port Stackables, 10/100 auto-sensing

Stackable Hubs, SNMP Optional

10Mb series and 100Mb series, both w/ optional port modules

Personal Switches, 10/100Mb

8 port dual speed, Auto-negotiable with fiber option

Personal Hubs, 100Mb or 10/100Mb

8-port, with two switched ports (1 fiber built in)

Personal Hubs, 10Mb series

8-port + AUI, stackable to 5 high, + optional BNC of fiber port

8 or 9-port and 4 or 5-Port Personal Hubs, w/ man. up-link sw.

Media Converters, 10Mb and 100Mb series

All media combinations, incl. fiber ST, SC, mm., single mode

The “X-line” of configurable MiXed Media products:

Stackable Concentrators, SNMP optional, 13-Ports

Mini-Concentrators, 7 Ports, Repeaters, 2-Ports

Repeater Port Modules (RPMs),6 types for Ethernet media

Bridge Port Modules (BPMs), 4 types, for segment isolation

Fan-Outs, 10Mb series

2, 4 and 8 Port Models

Transceivers, 10Mb and 100Mb series 10Mb Mini-Transceivers

and Coax Models, All Types - Apr, 01

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

1.0 SPECIFICATIONS

1.1. Technical Specifications

Performance:

Data Rate: 10 Mbps

Partitioning: Enforced after 32 consecutive collisions.

Reconnect: Occurs after 512 bits error-free transmission.

Maximum Ethernet Segment Lengths:

10BASE-T (Unshielded twisted pair) - 100 m (328 ft)

10BASE-T (Shielded twisted pair)- 150m (492 ft)

AUI Drop Cable - 50 m (164 ft)

10BASE2 ThinNet (BNC) - 185 m (607 ft)

10BASE5 - 500 m (1,640 ft)

10BASE-FL multi-mode Fiber optic - 2 km (6562 ft)

Network Standards:

Ethernet V1.0/2.0 IEEE 802.3: 10BASE-T, 10BASE5, 10BASE2,

10BASE-FL, FOIRL.

(Magnum Stackable Personal Hubs are physical layer standard Ethernet

products, and operate in networks independently of all software.)

Operating Environment:

Ambient Temperature: 32ºF to 122ºF (0ºC to 50ºC)

Storage Temperature: -20ºC to 60ºC

Ambient Relative Humidity: 10% to 95% (non-condensing)

Power Supply (External):

Input: 95 - 125 vac at 60 Hz for "-d" Models,

200 - 250 vac at 50 Hz for "-i" Models, which have

IEC power cable connector in the external power unit.

Output: 12 VDC, 1 A

Polarity: center positive, shell negative

Power Consumption: 12 watts max.

Connectors:

ST80: Eight shielded RJ-45 ports (one with up-link switch); one rear AUI,

female, with slide lock; two Inter-Repeater-Bus connectors on the side.

ST80-B: Same as ST80, plus one rear BNC with internal termination switch.

ST80-F: Same as ST80, plus one rear Fiber ST-type.

(Shielded 10BASE-T connectors accept either unshielded or shielded wiring

plugs for standard twisted pair media wiring.)

The regular RJ-45 ports support the standard for hubs-to-users twisted

pair wiring: pin 1= receive+, 2 = receive-, 3 = transmit+, 6 = transmit-,

other pins not used. The RJ-45 port with the up-link switch is normally

the same, but when switched it supports the standard for up-links using

twisted pair wiring, i.e., the transmit and the receive pairs are exchanged:

pin 1 = transmit+, 2 = transmit-, 3 = receive+, 6 = receive- , other pins

not used.

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

Switches:

Up-Link: MDI-X (Media Dependent Interface - Crossover) manual slide

switch, converts RJ-45 port #8 from a regular (=) user segment port to a

crossover (X) up-link port for on-off connection to a backbone or another

cascaded hub.

Stack Enable Switch: Manual slide switch to specify which Stackable

Personal Hub is the base of the stack. Exactly one hub should have its Stack

Enable switch in the “OFF” position (left). All other hubs in the stack should

have their Stack Enable switches set to the “ON” position (right).

Internal Termination Switch (ST80-B only): When switched to the right

position, allows BNC connection without a “tee” connector and a 50 ohm

terminator. When switched to left position, a “tee” connector is required.

LEDs:

PWR: GREEN when Proper DC power supplied to ST80.

COL: YELLOW when a transmit collision occurs on the hub.

LINK/TX (per port): GREEN when link established on port. Flickers as

port transmits packets.

POL/RX (per port): Flickers GREEN as port receives packets. Steady

GREEN when reversed polarity detected.

Packaging:

Enclosure: Rugged, high strength steel enclosure.

Suitable for vertical or horizontal mounting.

Any unit may be used stand-alone, or as either the base unit or an additional

unit in a stack (two stacking / mounting clips and one IRB cable are

included with each unit)

Recessed LEDs to avoid damage, located with the RJ-45 ports for convenience.

Dimensions:

All models: 6.75 in x 4.0 in x 1.0 in (17.1 cm x 10.1 cm x 2.5 cm)

Weight:

All models: 1.3 lb. (600 gr.)

Power Supply: 1.0 lb. (455 gr.)

Cooling method:

Convection

Agency Approvals:

Magnum ST80 is UL Listed (UL1950), CSA certified

115v 60 Hz Power Supply is UL Listed, CSA certified.

230v 50 Hz Power Supply is same, also GS approved.

Emissions: Meets FCC Part 15, Class A

Warranty:

Three years (see also Appendix A) Made in USA

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

1.2 Ordering Information

Magnum Stackable Personal Hubs

MODEL DESCRIPTION

Magnum ST80-d Stackable Personal Hub with eight standard RJ-45 ports, one

with up-link switch, plus one rear AUI port; external 115 vac

60 Hz power supply.

Magnum ST80-i Same as ST80-d, but with external 230 vac 50 Hz power

supply.

Magnum ST80-B-d Stackable Personal Hub with eight standard RJ-45 ports, one

with up-link switch; one AUI plus 1 BNC port with internal

termination switch; external 115 vac 60 Hz power supply.

Magnum ST80-B-i Same as ST80-B-d except with external 230 vac 50 Hz

power supply.

Magnum ST80-F-d Stackable Personal Hub with eight standard RJ-45 ports, one

with up-link switch; one AUI plus one Fiber-ST port with

LINK LED; external 115 vac 60 Hz power supply.

Magnum ST80-F-i Same as ST80-F-d except with external 230 vac 50 Hz

power supply.

GarrettCom, Inc. reserves the right to change specifications, performance

characteristics and/or model offerings without notice.

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

2.0 INTRODUCTION

This section describes the ST80 Stackable Personal Hub, including appearance,

features and possible applications.

2.1 Inspecting the Package and Product

Examine the shipping container for obvious damage prior to installing this

product; notify the carrier of any damage which you believe occurred during shipment or

delivery. Inspect the contents of this package for any signs of damage and ensure that

the items listed below are included.

This package should contain:

1 Magnum ST80-series Stackable Personal Hub

1 External Power Supply, either 115v 60 Hz or 230v 50 Hz

1 Velcro® Tape section, approximately 3 inches in length

2 L-shaped stacking /mounting brackets

4 Metal screws for optional use with stacking/mounting brackets

1 Installation and User Guide

1 Product Registration Card

Remove the Magnum Stackable Personal Hub from the shipping container. Be

sure to keep the shipping container should you need to ship the unit at a later date. To

validate the product warranty please complete and return the enclosed Product

Registration Card to GarrettCom, Inc. as soon as possible.

In the event there are items missing or damaged, contact your supplier. If you

need to return the unit, try to use the original shipping container. Refer to Section 5,

Troubleshooting, for specific return procedures.

Stackable Personal Hubs Installation and User Guide (04/01)

www GarrettCom com

2.2 Product Description

The Stackable Personal Hub is an eight-port + workplace hub in a very

compact package. It is simple to install and use in an office or lab environment,

requiring no special rack cabinets or wiring closet apparatus. Up to five Stackable

Personal Hubs may be stacked to form a single logical repeater. Personal Hubs are

standard physical layer Ethernet products and operate independently of all software.

ST80 Personal Hubs are well suited for small- to-medium-size office or lab

environments (up to eight users without stacking) that need an independent Ethernet

network. They can operate as self-sufficient units to provide 10BASE-T Ethernet

connectivity for local users and devices. Small independent networks built using

Stackable Personal Hubs are easily expanded by stacking additional ST80s via the IRB

connectors. The AUI port provides backbone or other connectivity if required. (The

ST80-B and ST80-F models are also equipped with a BNC or a Fiber-ST connector for

convenient media connections.)

Stackable Personal Hubs provide a simple and inexpensive solution for

networking a multi-system office using 10BASE-T twisted pair cabling. They can

expand an existing single-network-port outlet to provide up to seven additional RJ-45

ports in the immediate office or lab area. Once installed, a Stackable Personal Hub is

easily expanded by stacking additional units to support larger numbers of users.

The Magnum ST80s’ small size makes them very useful for demonstration

situations in conference rooms and in exhibitions where a temporary network or network

expansion is needed. They are handy as a piece of test equipment that can be easily

inserted into a network to provide a test port, and then removed after the testing is done.

Stackable Personal Hubs take up minimal space, use minimal power, and are rugged

enough to be carried in a coat pocket for possible emergencies.

Magnum ST80 Stackable Personal Hub

Ports 1 2 3 4 5 6 7 8

PWR AUI

IRB1IRB2

Stack Enable

OFF ON

UP-LINK

Network

Port

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GarrettCom Changer

GarrettCom

GarrettCom Magnum CSG14 Manuel utilisateur

GarrettCom

GarrettCom MAGNUM 6KM Manuel utilisateur

GarrettCom

GarrettCom Magnum CS14 Series Manuel utilisateur

GarrettCom

GarrettCom Hardened Ethernet Switches P62F Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K25e Manuel utilisateur

GarrettCom

GarrettCom Magnum 4K220 Manuel utilisateur

GarrettCom

GarrettCom Magnum DS80 Manuel utilisateur

GarrettCom

GarrettCom Magnum ITS Blade Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K32F Manuel utilisateur

GarrettCom

GarrettCom Magnum S14 Manuel utilisateur

GarrettCom

GarrettCom Magnum 6KQ Manuel utilisateur

GarrettCom

GarrettCom Magnum DS 880 Manuel utilisateur

GarrettCom

GarrettCom Magnum 10KG Manuel utilisateur

GarrettCom

GarrettCom Hubs Manuel utilisateur

GarrettCom

GarrettCom Magnum 1016 Manuel utilisateur

GarrettCom

GarrettCom PS14H-48VDC Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K25 Manuel utilisateur

GarrettCom

GarrettCom Ethernet Networks and Web Management Manuel utilisateur

GarrettCom

GarrettCom Magnum 6K32T Instructions d'utilisation

GarrettCom

GarrettCom Quad Manuel utilisateur

GarrettCom

GarrettCom Magnum CS14 Series Manuel utilisateur

GarrettCom

GarrettCom Magnum 4K24F Manuel utilisateur

GarrettCom

GarrettCom DS8016 Manuel utilisateur

GarrettCom

GarrettCom Magnum 6KQE Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
