Garmin Nuvi 1100 Manuel d'instructions

nüvi®1100 series

quick start manual

2 nüvi 1100 Series Quick Start Manual

‹

WARNING

See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

Looking at Your nüvi

Mini-USB

connector

Speaker

microSD

™

card slot

Power button:

Press to turn the nüvi on and off.

Using the Main Menu

➊➋ ➌ ➍

➎ ➏

➐ ➑

➊

GPS satellite strength.

➋

Touch to select a usage mode.

➌

Current time. Touch to change

time settings.

➍

Battery status.

➎

 Touchtondadestination.

➏

Touch to view the map.

➐

Touch to adjust the volume.

➑

Touch to use the tools such as

settings and Help.

nüvi 1100 Series Quick Start Manual 3

Setting Up Your nüvi

‹

WARNING

This product contains a lithium-ion battery. To prevent injury or damage to the

device, remove the unit from the vehicle when exiting or store it out of direct

sunlight.

Notice

Before mounting the nüvi, see the Important Safety and Product Information

guide for information about laws pertaining to windshield mounting.

Mounting your nüvi

1. Remove the clear plastic from the suction

cup. Place the suction cup on the windshield.

2. Flip the lever back toward the windshield.

3. Snap the cradle onto the suction cup arm.

4. Plug the vehicle power cable into the back of

your nüvi.

5. Plug the other end of the vehicle power cable

into a power outlet in your vehicle. Your unit

should turn on automatically if it is plugged

in and the vehicle is running. Follow the on-

screen instructions.

6. Fit the bottom of your nüvi into the cradle.

7. Tilt your nüvi back until it snaps into place.

Suction cup mount

Cradle

Suction cup mount

Cradle

Vehicle power

cable

Vehicle power

cable

4 nüvi 1100 Series Quick Start Manual

Acquiring Satellites

1. Go outdoors to an open area,

away from tall buildings and trees.

2. Turn on your nüvi.

Acquiring satellite signals can take a

few minutes. The bars indicate

satellite strength. When at least one

of the bars is green, your nüvi has

acquired satellite signals.

Charging Your nüvi

Charge your nüvi for at least 4 hours

before using on battery power.

Connect the vehicle power cable.

Connect the USB cable.

Connect an AC adapter (optional

accessory).

•

Using the Power Button

Press and quickly release the Power

button to view additional options:

Touch and to adjust the

screen brightness.

Touch Lock Screen to prevent

accidental screen touches.

Touch Turn Off to turn off your

nüvi. You can also turn off the

nüvi by holding the Power button

for 8 seconds.

Resetting Your nüvi

If your nüvi stops functioning, reset

your nüvi by pressing and holding the

Power button for 10 seconds.

Finding Points of Interest

1. Touch Where To? > Points of

Interest.

2. Select a category and a

subcategory.

•

nüvi 1100 Series Quick Start Manual 5

3. Select a destination, and touch

Go!.

4. If necessary, touch Start to

navigate the route.

To enter letters contained in the

name, touch Where To? > Points of

Interest > Spell Name.

To search for a location in a different

area, touch Where To? > Near.

Following Your Route

Your route is marked with a magenta

line. As you travel, your nüvi guides

you to your destination with voice

prompts, arrows on the map, and

directions at the top of the map. If you

depart from the original route, your

nüvi recalculates the route.

Touch and drag the map to view a

different area of the map.

➊ ➋

➌

➍

➎➏➐

➊ 

Touch to view the Next Turn

page.

➋ 

Touch to view the Turn List

page.

➌

Touch to view the Where Am I?

page.



➍

Touch and to zoom in

and out.

➎

Touch to return to the Main

menu.

➏

 Touchtochangedataeld.

➐

Touch to view the Trip

Computer.

6 nüvi 1100 Series Quick Start Manual

Adding a Stop

1. While navigating a route, touch

> Where To?.

2. Search for the extra stop.

3. Touch Go!.

4. Touch Add as Via Point to

add this stop before your nal

destination.

Taking a Detour

1. While navigating a route, touch .

2. Touch Detour.

Using FM TMC Trafc

Notice

Garmin is not responsible for the

accuracyofthetrafcinformation.

Heated (metallized) windows could

degradetheperformanceofthetrafc

receiver.

TheFMTrafcMessageChannel

(TMC)trafcreceiverisoptional.

Thetrafcreceiverandthenüvimust

be in data range of an FM station

transmitting TMC data to receive

trafcinformation.Youdonotneed

to activate the subscription included

withyourFMtrafcreceiver.The

subscription activates automatically

after your nüvi acquires satellite

signalswhilereceivingtrafcsignals

from the pay service provider. Go to

www.garmin.com/trafcor www

.garmin.com for more information.

Ifaseveretrafcdelayoccurson

your route while you are navigating,

the nüvi automatically recalculates

the route. The trafcicon changes

colortoindicatetheseverityoftrafc

conditions on your route or on the

road you are currently traveling.

nüvi 1100 Series Quick Start Manual 7

Securing Your nüvi

Notice

If you forget your PIN and your

security location, you must send your

nüvi to Garmin to get it unlocked.

You must also send a valid product

registration or proof of purchase.

1. Ensure that you are at your

security location and that your nüvi

is receiving satellite signals.

2. Touch Tools > Settings >

Security.

3. Touch the button below Garmin

Lock.

4. Enter a four-digit PIN.

5. Touch Set.

nüMaps Guarantee™

To receive one free map update

(if available), register your nüvi at

http://my.garmin.com within 60 days

of acquiring satellites and driving

with your nüvi. You are not eligible

for the free map update if you register

by phone or wait longer than 60 days

afterthersttimeyoudrivewithyour

nüvi.

More Information

For more information about your

nüvi, select Tools > Help. Download

the latest version of the owner’s

manual from www.garmin.com. For

information on accessories, go to

http://buy.garmin.com or contact your

Garmin dealer.

Garmin

, the Garmin logo, and nüvi

are trademarks of Garmin Ltd. or its subsidiaries, registered in the

USA and other countries. Garmin Lock

™

and nüMaps Guarantee

™

are trademarks of Garmin Ltd. or its

subsidiaries. These trademarks may not be used without the express permission of Garmin. microSD

™

a trademark of SanDisk or its subsidiaries.

Garmin International, Inc.

1200 East 151st Street, Olathe, Kansas 66062, USA

Garmin (Europe) Ltd.

Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK

Garmin Corporation

No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan

www.garmin.com

Octoboer 2009 190-01041-02 Rev. A Printed in Taiwan
