Garmin 295W Manuel d'instructions

nüvi®295W

quick start manual

2 nüvi 295W Quick Start Manual

Device Features

‹

WARNING

See the Important Safety and Product Information guide in the product box for

product warnings and other important information.

➊

microSD™card slot (under cap)

➋

Contacts (for the cradle)

➌

Mini-USB connector

➍

Power key

➎

Headphone/audio out

connector

NOTE: The connector must

be used with the Garmin

2.5 mm to 3.5 mm adapter

or the Garmin stereo headset

with microphone.

➏

Volume up/down keys

➐

Camera key

➍

➎

➏

➐

➌

➊

➋

➍

➎

➏

➐

➌

➊

➋

nüvi 295W Quick Start Manual 3

Installing the Battery

1. Pressdownrmlyonthebattery

cover, and slide it off the back of the

device.

Battery cover

2. Locate the lithium-ion battery that

came in the product box.

3. Locate the metal contacts on the end

of the lithium-ion battery.

4. Insert the battery so that the metal

contacts on the battery match up with

the metal contacts inside the battery

compartment.

Battery

5. Slide the battery cover onto the back

of the device.

Charging the Battery

Notice

Your device will not charge if the

temperature has exceeded 113°F

(45°C). If the device is mounted in the

windshield, remove it from the mount

and place it somewhere out of direct

sunlight to allow the battery to charge.

Beforeusingthedeviceforthersttime,

you must charge the battery for at least

four hours.

TIP: If you completely discharge the

battery, charge it for at least 20 minutes

before turning on your device.

Use the vehicle power cable

connected to the cradle, with the

device in the cradle (preferred)

(page 4).

Use the vehicle power cable

connected directly to the device.

Use the USB cable connected to a

computer.

Use the battery charger accessory.

Use the AC power adapter accessory.

TIP: For more information about

accessories, go to www.garmin.com.

Mounting the Device

Notice

Before mounting the device, see

the Important Safety and Product

Information guide for information about

laws pertaining to windshield mounting.

•

1. Plug the vehicle power cable into the

power connector.

Vehicle

power

cable

Cradle

2. Remove the clear plastic from the

suction cup.

3. Clean and dry your windshield and

the suction cup with a lint-free cloth.

4. Place the suction cup on the

windshield.

5. Flip the lever back, toward the

windshield.

4 nüvi 295W Quick Start Manual4 nüvi 295W Quick Start Manual

nüvi 295W Quick Start Manual 5

6. Snap the cradle onto the suction cup

arm.

Lever

Suction cup arm

Cradle

7. Fit the gold contacts on the side of

your device into the cradle.

8. Tilt the device back until it snaps into

the cradle.

9. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

Using the Home Screen

➊

➋

➌

➊

Touch a shortcut icon in the

scrolling menu to start an application

(page 6). Touch and drag the menu

to scroll through all of the shortcuts.

➋

Touchtondandnavigatetoa

location.

➌

Touch to view the map.

6 nüvi 295W Quick Start Manual

Tips and Shortcuts

Touch to return to the previous

screen.

Touch and hold from any screen

to quickly return to the Home screen.

Touch and to see more choices.

Quickly tap these buttons to scroll

faster.

Using the Touchscreen

Touchanddragyourngertoslowly

scroll the screen.

Touch, drag, and quickly remove

yournger(ickthescreen)to

quickly scroll the screen.

Touch the screen to stop scrolling.

Orienting the Screen

Rotate the device to view in

horizontal (wide-screen) or vertical

(portrait) mode.

•

Turning the Device On and

Off

Press and release the Power key.

About the Automatic

Screen Lock

The device automatically locks if you do

notuseitforaspeciedamountoftime.

If the device is in the mount with

external power, the screen will not

automatically lock.

Manually Locking the Device

Press the Power key.

nüvi 295W Quick Start Manual 7

Unlocking the Device

1. Quickly press the Power key, if

necessary.

2. Double-tap .

Adjusting the Screen Timeout

Length

1. From the scrolling menu, touch

Settings > Display > Auto Lock.

2. Select an option.

3. Touch OK.

Searching for Locations

The Where To? menu provides several

different categories you can use to

search for locations and destinations.

Acquiring Satellites

Before you can navigate with your

device, you must acquire satellites.

1. Turn on your device.

2. If necessary, go outdoors to an open

area, away from tall buildings and

trees.

Acquiring satellite signals can take a

few minutes.

Finding an Address

NOTE: Depending on the version of

the built-in map data on your device,

the button names and the order of steps

could be different from the steps below.

1. From the Home screen, touch Where

To? > Address.

2. If necessary, change the state, the

country, or the province.

3. Touch Spell City, enter the city or

postal code, and touch Done.

TIP: If you do not know the city or

postal code, touch Search All.

4. If necessary, select the city or postal

code in the list.

NOTE: Not all map data provides

postal code searching.

5. Enter the number of the address.

6. Touch Done.

7. Enter the street name.

8 nüvi 295W Quick Start Manual

8. Touch Done.

9. Select a street in the list, if necessary.

10. Touch the address, if necessary.

About Points of Interest

The detailed maps loaded in your

device contain points of interest, such as

restaurants, hotels, and auto services.

Finding by Category

1. From the Home screen, touch Where

To? > Points of Interest.

2. Touch a category.

3. Touch a subcategory, if necessary.

TIP: To narrow the search, touch

Spell, enter the text, and touch Done.

A list of items near your current

location appears.

4. Touch an item.

Finding by Spelling the Name

1. From the Home screen, touch Where

To? > Points of Interest > Spell

Name.

2. Enter all or part of the name.

3. Touch an item.

Finding with Local Search

A Wi-Fi®connection is required to use

this service. Businesses listed with Local

Search may include ratings based on user

reviews. Local Search is not available in

all areas.

1. From the Home screen, touch Where

To? > Local Search.

2. Select a category.

3. Select a location.

Setting a Home Location

You can save a home location and

quickly generate a route to it.

1. From the Home screen, touch Where

To? > Home.

2. Select an option.

nüvi 295W Quick Start Manual 9

Working with Found

Locations

➊➋

➌

Afteryoundalocation,severaloptions

appear.

➊

Touch to view the location on the

map.

➋

Touch to save the location or to send

the location in a location e-mail.

➌

Touch to create a route to the

location.

Following Your Route

Before you can navigate with your

device, you must acquire satellites

(page 7).

Afteryoundalocation(page 7),

touch Go!.

The device creates a route to the

location and opens the map. Your

route is marked with a magenta line.

Using the Map

As you travel, your device guides you

to your destination with voice prompts,

arrows on the map, and directions at the

top of the map.

If you deviate from the original route,

your device recalculates the route and

provides new directions.

NOTE: You can see detailed map

information only for areas for which you

have maps loaded on your device.

10 nüvi 295W Quick Start Manual

➊

➎

➍

➌

➋

➎

➊

Touch to view the route details.

➋

Touch to zoom in and zoom out.

➌

Touch for current location

information.

➍

Touch to return to the Home screen.

➎

Touch to view the trip computer.

Adding Via Points to the Active

Route

1. While navigating a route, touch >

Where To?.

2. Search for the extra via point.

3. Touch Go! > Add As a Via Point.

Taking a Detour

While navigating a route, touch

> Detour.

Transferring Files

Youcantransferles,suchasMP3sand

JPEGs, to your device.

1. If necessary, insert a microSD card

into the memory card slot.

2. Connect the mini-USB cable to the

device.

3. Connect the other end of the cable to

your computer.

4. Touch Yes to change to mass storage

mode.

Two additional drives (volumes)

appear in the list of drives on your

computer. One is the available

storage in the internal memory of the

device. The other is the memory card

inserted into the device.

5. Double-click the My Computer

icon (Windows®computers) or

the mounted-volume icon (Mac®

computers) on your computer.
