GamesterGear Cruiser XB210 Manuel utilisateur
Cruiser XB210
Gaming Headset Manual
1
TECHNICAL SPECIFICATIONS
Acoustic Design:
Frequency Response:
Driver:
Bass Enhance Driver:
Sensitivity:
Mic Type:
Mic Frequency Response:
Cable Length:
Connector Type:
Closed Back
20hz - 20khz
50 mm @ 32 ohms
30 mm @ 16 ohms
112dB SPL, 1mW @ 1khz
Detachable Boom Mic
70hz - 15khz
15.7 ft (4.8 m)
Dual RCA for Game Audio
USB for Power
2.5mm for Voice Chat Input
Padded Headband
Dual Drivers Setup
Detachable Mic
Cloth Ear Pads
Feature
1
1. Chat Input
2. Bass Level
3. Mic Mute Switch
4. Game Volume
5. Chat Volume
6. Mic Mute LED
23
46
5
Package Contents
Detachable Mic
2
Cruiser XB210
Headset
2.5mm Voice Chat Cable
Control Dongle
3
Voice Volume 10
Voice
Mute Kinect
Voice Output
Play Through Headset
Play Through Speakers
Voice Output
Game Volume 10
Chat Setup
2. In the XBOX 360 System Settings, select [Preferences] - [Voice] -
[Play Through Headset]
1. Connect your voice chat cable to the 360 controller then connect
it to the XB210 dongle
Red/White
HDMI
USB
TV HDMI Setup
4
TV input/output set up may vary
Red/White
*XBOX 360 AV adapter cable required (sold separately)
(Refer to page 7)
XBOX 360 Audio Adapter Cable*
HDMI
USB
5
Monitor HDMI Setup
6
RCA Setup
Xbox 360 AV Cable
Red/White
Yellow
USB
7
AV Adapter Cable
The AV Xbox adapter cable allows you to use the RCA jacks to
connect your new Cruiser headset while still providing an HDMI
video output to your TV/monitor. Some TV/Monitors are not
equipped with RCA audio outputs. Should your TV/monitor not
have RCA audio output, and you are using an HDMI cable to
connect your Xbox to your TV/monitor you will need to use an Xbox
AV adapter cable. The Xbox AV adapter cable can be purchased at
any online retailer, as it may have not been included with your Xbox
system.
Q: Why do I have no sound coming out of my new Cruiser
Headset?
A: Be sure to plug in both the USB and the RCA plugs into the
correct slot of your system.
Q: Why is the mic not picking up my voice?
A: Make sure that the microphone has been properly locked into
place, as it will not work if it has not been.
Q: I followed the steps required to mic set up, but I still don't have
my mic working.
A: Be sure that you don't accidentally have the mic set to Mute on
the dongle.
Q: I have misplaced/damaged my detachable microphone how
can I request a replacement?
A: Simply visit the GamesterGear website and send us an email
request for a new detachable microphone. Please do note that
there will be a fee for a replacement microphone.
FAQ
Maintenance
Do not expose headphones to extreme temperatures. Wipe the
headphones and head-band with mild antiseptic to avoid infections.
Do not use alcohol-based disinfectants.
8
Safety Notice
To avoid potential damage to the device, always disconnect all cables
before transporting it.
WARNING: Permanent hearing damage can occur if a headset is used
at high volumes for extended periods of time, so it is important to
keep the volume at a safe level. Over time, your ears adapt to loud
volume levels, so a level that may not cause initial discomfort can still
damage your hearing. If you experience ringing in your ears after
listening with the headset, it means the volume is set too loud. The
louder the volume is set the less time it takes to aect your hearing.
Sure to listen at moderate levels.
• Before placing a headset on your ears, turn the volume
down completely, then slowly increase it to a comfortable
level.
• Turn down the volume if you can’t hear people
speaking near you.
• Avoid turning up the volume to block out noisy
surroundings.
Tips:
9
Limited 1 Year Warranty
GamesterGear hereby warrants that this product will be free from
defects in materials and workmanship for a period of one year from
the date of purchase. At its option GamesterGear will repair or replace
the defective product and promptly return it to you. You should retain
proof of purchase to validate the purchase date and return it with any
warranty claim.
If you believe this product is defective within the warranty period,
carefully repack the unit, insure it, and return it postage prepaid.
For return RMA and address, please visit www.gamestergear.com.
Do not make any modication to the system or accessories.
Unauthorized alterations may compromise safety, regulatory
compliance, system performance, and may void the warranty
Operate this product within the temperature range of -4°F to 113°F
(-20°C to 45°C) only. Damage caused by use outside of that range may
not be covered by the warranty
Check and follow local laws regarding use of a mobile phone and
headset/headphones while operating any vehicle or using equipment
that requires your full attention. If you use the headset/headphones
while engaging in any such activity, be sure to focus on safety.
Cautions
